Okina USA MD-T04CAM Quick Start Manual

MD-T04CAM
Anti-Vibration 4CH DVR for Public Transportation

Features

4-ch input externally and 1-ch input internally swap-
able as channel 1
Total frame up to 60fps(NTSC)/ 50fps(PAL) selectable
Hi-resolution recording at D1 for each channel
Anti-vibration design of SD card and SATA HDD
storage
Wide range working voltage from DC11V~36V and
supply DC12V for cameras when power input is above
16V
Power surge protection up to 40VDC
Motion detection/ schedule / trigger
Single cable design for powering camera, video, audio
& triggering signal making installation easier,
expenses lesser yet tidy and neat
User friendly software for 4ch playback simultaneously
by versatile bundled PC software

How to Use

a. Connect DVR with cameras. (4-ch input externally
and 1-ch input internally swab-able as channel 1 )
b. Insert your high capacity SD card or SATA HDD.
a. Remove the SD card or SATA HDD and
insert into any computer to playback video.
International : 1-510-279-9980
a. Remote controllable DVR and OSD.
b. Record onto removable high capacity SD card
or SATA HDD.
a. 4ch playback simultaneously. b. File quick search
c. Easy Backup
USA: 1-800-872-9907
Website: www.okinausa.com
30010711
d. Manage user authority level
Email: info@okinausa.com
