User Manual
Full D1 Realtime H.264 DVR – 8 / 16 CH.
Quick Setup Guide
PACKAGE CONTENTS
A.
One (1)
B.
One (1)
C.
Two (2)
D.
One (1)
E.
Two (2)
Two (2)
F.
Eight (8)
G.
Two (2) sets Hard Drive Mounting Bracket set w/ screws
H.
One (1)
I.
Two (2)
J.
Two (2)
K.
One (1)
L.
One (1)
A.
D.
G.
Hard Drive Mounting Brackets
x 2 sets
J.
Inside the DVR
*Note: Any Return Must Include All Components.
Missing Components will be charge.
We highly recommend installing a UPS Battery Backup System to avoid
power failure restore damage to Hard Drive & motherboard.
Please read this Quick Setup Guide before installation.
DDR-08 / DDR-16 DVR
Remote Controller
AAA Battery for Remote Controller
USB Mouse
8 Screw on Terminal Connector - DDR-08 / DDR-16
4 Screw on Terminal Connector - DDR-16
Hard Drive Screws
12V DC / 5Amp w/ Power Cord
Rack Mount Ear w/ Screws
SATA Cable Inside
Quick Set up Guide Book
User's Manual & CMS Software CD
B.
E.
H.
K.
x 2
x 2 (16 CH.)
x 2 (8 / 16 CH.)
DDR-08
DDR-16
C.
F.
I.
L.
MADE IN TAIWAN
x 2
x 8
R201304-V10
Advertisement
Table of Contents
Related Manuals for Okina USA DDR-08
Summary of Contents for Okina USA DDR-08
-
Page 1: Quick Setup Guide
Two (2) AAA Battery for Remote Controller One (1) USB Mouse Two (2) 8 Screw on Terminal Connector - DDR-08 / DDR-16 Two (2) 4 Screw on Terminal Connector - DDR-16 Eight (8) Hard Drive Screws Two (2) sets Hard Drive Mounting Bracket set w/ screws... -
Page 2: Front Panel
DDR-08 / DDR-16 Quick Setup Guide Panel Definition 1. Front Panel Item # Label Name Function Connect USB thumb drive or mouse REC / FOCUS Manual record / focus adjustment(PTZ) PLAY / IRIS Enter Playback/ iris adjustment (PTZ) REW / SPEED Fast rewind on playback mode / speed adjustment (PTZ) FF / P.T.Z. - Page 3 DDR-08 / DDR-16 Quick Setup Guide Item # Label Name Function + 5V and GND +5 V and Grounding ALARM OUT 1-ch relay output. Connect to external alarm. HDMI port Connect to high-definition display device (optional) VGA port VGA output, connect to monitor To connect external USB devices like USB flash, USB HDD or USB mouse.
-
Page 4: Control Option
DDR-08 / DDR-16 Quick Setup Guide Control Option 1. Remote Controller ◆ This remote control uses AAA battery, the definition as following: Item # Label Name Function Record Button To record manually 0-9, -/-- Digital Button Input number or choose camera... -
Page 5: Wizard Setup
DDR-08 / DDR-16 Quick Setup Guide 2.3 Mouse Control: REQUIRED ◆Connection: Recommend to connect the USB mouse to the back panel. ◆Mouse functions： 1）Under LIVE mode： On every channel ， you could double click the left button to switch FULL SCREEN and double click again to switch back to original split mode. - Page 6 DDR-08 / DDR-16 Quick Setup Guide 2.1 Motion Detection Recording: Motion Detection Recording: Enter Main Menu Setup Alarm Motion Enable the Channels to turn on Motion Detect Record. **Motion Schedule Default: is set to Full Time motion recording on all channels.
-
Page 7: Part 1. Static Ip Address
DDR-08 / DDR-16 Quick Setup Guide 3. Wizard for HDD setup You can format HDD by using “Format” function. After HDD format completed, it will show “Normal” label on status. ＊Please make sure to backup all HDD data before you format the HDD. - Page 8 DDR-08 / DDR-16 Quick Setup Guide 6. Uncheck “Obtain an IP address automatically” to turn off this feature and make IP Address stay the same. Then click Apply. Continued For DDNS Set up Part 2 Part 2. DDNS 1. Continue Part 1: Select “Other Setting” from the Tab bar and turn on DDNS.
- Page 9 Step 3 DDR-08 / DDR-16 Quick Setup Guide Tip: When using other DDNS websites you may be required to enter your external IP Address to register your Host Domain Name. - To find your external IP Address use this website: http://www.whatsmyip.net...
- Page 10 DDR-08 / DDR-16 Quick Setup Guide Additional DVR Option Full D1 Realtime H.264 DVR – 4CH. HD SDI H.264 DVR – 4CH. DDR-04 HDRS-04-1U Full D1 Realtime H.264 DVR – 8 / 16 CH. HD SDI H.264 DVR – 8 / 16 CH.
