Summary of Contents for Tuff Tonneaus 11303
- Page 1 TONNEAU FITTING INSTRUCTION Isuzu D-Max Space Cab September 2020 - Current Part number: 11303 Package includes 1 X Tonneau cover 4 x Bar Brackets 2 x Tonneau Support Bar 32 x Rivets 2 x Support Bar Sheath 1 x Lock Bracket...
- Page 2 1. TONNEAU COVER FITTING NOTE Read entire instructions prior to start. 1.1 BASIC TOOL REQUIRED Drill, 4mm Drill Bit, Rivet Gun, Marking Pencil / Pen 1.2 TONNEAU COVER INSTALLATION PROCEDURE 1. Fit The Bar Brackets and Support Bars (a) Measure 600mm and 1200mm from the front inside Figure 1 edge back along the driver’s side.
- Page 3 3. Fit The Buttons To Tub Sides Figure 3 (a) Measure down 170mm from the inside edge of the tub, in line with the Front Bunji on the Cover, and mark. This is the position of the front button. See Figure 3 Figure 4 (b) Measure down 140mm from the inside edge of the tub, in line with the Rear-Side Bunji and mark.
- Page 4 Figure 6 (e) Work from the rearmost bunjis towards the front, alternating from side to side. (f) Line up the rearmost bunji loop (#1) on the driver’s side of the vehicle and make a mark on the line drawn in step 4 (c).
- Page 5 The Tonno Lock is designed to suit all utes and prevent thieves stealing your Tuff Tonneau, so you can continue to rely on the Tuff Tonneaus’ name to give you what you want in a tonneau cover.
- Page 6 3.2 MULTI-FIT SUPPORT BAR CONTENTS 1 x hollow bar centrepiece 2 x grub screws 2 x solid bar end piece 1 x Tonneau bar sheath 3.3 FITTING MULTI-FIT BAR 1. Insert solid bar pieces into either end of hollow tube. Adjust bar so it fits between bar bracket holders with the holes facing to the ground (so the grub screws don’t rub against the tonneau), as shown above and then with a white pencil make a mark through the small holes of the hollow bar onto the solid ends.
