TONNEAU FITTING INSTRUCTION
Ford PX Ranger Single Cab (with head board)
Package includes
1 X Tonneau cover
2 x Tonneau Support Bar (300516)
3 x Aluminium Rope Track-403mm long ea.
1 x Support Bar Sheath
1 x Fitting Instructions
1 x Warranty Card
Nov 2011-May 2013
Part number: 144
4 x Bar Brackets (300474)
40 x Rivets (300482)
1 x Lock Bracket
24 x Rope Buttons (300473)
4 x Dowel
2 x 100mm angle pieces (S-0047)
Advertisement
Table of Contents
Related Manuals for Tuff Tonneaus 144
Summary of Contents for Tuff Tonneaus 144
- Page 1 TONNEAU FITTING INSTRUCTION Ford PX Ranger Single Cab (with head board) Nov 2011-May 2013 Part number: 144 Package includes 1 X Tonneau cover 4 x Bar Brackets (300474) 2 x Tonneau Support Bar (300516) 40 x Rivets (300482) 3 x Aluminium Rope Track-403mm long ea.
- Page 2 Table of Contents TONNEAU COVER FITTING ......................3 1.1 BASIC TOOL REQUIRED ......................... 3 1.2 TONNEAU COVER INSTALLATION PROCEDURE ................3 TONNO LOCK ........................... 5 2.1 BASIC TOOL REQUIRED ......................... 5 2.2 TONNO LOCK CONTENTS ......................5 2.3 FITTING TONNO LOCK ........................5 MULTI-FIT SUPPORT BAR ........................
- Page 3 1. 1. 1. 1. TONNEAU COVER FITTING TONNEAU COVER FITTING TONNEAU COVER FITTING TONNEAU COVER FITTING NOTE Read entire instructions prior to start. 1.1 BASIC TOOL REQUIRED 1.1 BASIC TOOL REQUIRED 1.1 BASIC TOOL REQUIRED 1.1 BASIC TOOL REQUIRED Drill, 4mm Drill Bit, Rivet Gun, Marking Pencil / Pen 1.2 TONNEAU COVER INSTALLATION PROCEDURE 1.2 TONNEAU COVER INSTALLATION PROCEDURE...
- Page 4 Figure 1: Placement of aluminium rope track. Ensure channel is above the tub’s top edge. 750mm & 1500mm Figure 2: Placement of bar bracket P a g e...
- Page 5 TONNO LOCK TONNO LOCK The Tonno Lock is now a standard feature included with all Tuff Tonneaus. The Tonno Lock is situated at the front of the tonneau cover, so as not to impede the accessibility of the Tuff Tonneau.
- Page 6 3. 3. 3. 3. MULTI MULTI MULTI- - - - FIT SUPPORT BAR MULTI FIT SUPPORT BAR FIT SUPPORT BAR FIT SUPPORT BAR The Tuff Tonneau Multi - Fit Support Bar is designed to fit almost all Utes on the Market, from Suburu Brumbys to Cab Chassis aluminium trays.
