TONNEAU FITTING INSTRUCTION
Isuzu D-Max Dual Cab With Head Board
Package includes
1 X Tonneau cover
1 x Tonneau Support Bar (300516)
1 x Rope Track-1253mm (With Shim)
1 x Support Bar Sheath
1 x Fitting Instructions
1 x Warranty Card
Jul 2012 to Current
Part number: 10522
2 x Bar Brackets (300474)
28 x Rivets (300482)
1 x Lock Bracket
16 x Rope Buttons (300473)
2 x Dowel
4 x M8 Bolt (S-0050)
1 x LH Front cnr seal plate - A300118
1 x RH Front cnr seal plate - A300119
Advertisement
Table of Contents
Related Manuals for Tuff Tonneaus 10522
Summary of Contents for Tuff Tonneaus 10522
- Page 1 TONNEAU FITTING INSTRUCTION Isuzu D-Max Dual Cab With Head Board Jul 2012 to Current Part number: 10522 Package includes 1 X Tonneau cover 2 x Bar Brackets (300474) 1 x Tonneau Support Bar (300516) 28 x Rivets (300482) 1 x Rope Track-1253mm (With Shim)
- Page 2 Table of Contents TONNEAU COVER FITTING ......................3 1.1 BASIC TOOL REQUIRED ......................... 3 1.2 TONNEAU COVER INSTALLATION PROCEDURE ................3 TONNO LOCK ........................... 6 2.1 BASIC TOOL REQUIRED ......................... 6 2.2 TONNO LOCK CONTENTS ......................6 2.3 FITTING TONNO LOCK ........................6 MULTI-FIT SUPPORT BAR ........................
- Page 3 1. 1. 1. 1. TONNEAU COVER FITTING TONNEAU COVER FITTING TONNEAU COVER FITTING TONNEAU COVER FITTING NOTE Read entire instructions prior to start. 1.1 BASIC TOOL REQUIRED 1.1 BASIC TOOL REQUIRED 1.1 BASIC TOOL REQUIRED 1.1 BASIC TOOL REQUIRED Drill, 4mm Drill Bit, Rivet Gun, Marking Pencil / Pen 1.2 TONNEAU COVER INSTALLATION PROCEDURE 1.2 TONNEAU COVER INSTALLATION PROCEDURE...
- Page 4 9. Slide the front of the tonneau cover through the aluminium rope track section. 10. Ensure tonneau is centred. To fit the rope buttons to the tub, start with the tailgate, vertically line up each button to each bunji loop starting from the centre bunji loops. The height for the buttons on the tailgate is 410mm UP from the bottom edge of the tailgate.
- Page 5 Figure 1: Placement of aluminium rope track. Ensure channel is above the tub’s top edge. 740mm 10mm down from top edge of tub Figure 2: Placement of bar bracket P a g e...
- Page 6 TONNO LOCK TONNO LOCK The Tonno Lock is now a standard feature included with all Tuff Tonneaus. The Tonno Lock is situated at the front of the tonneau cover, so as not to impede the accessibility of the Tuff Tonneau.
- Page 7 3. 3. 3. 3. MULTI MULTI MULTI- - - - FIT SUPPORT BAR MULTI FIT SUPPORT BAR FIT SUPPORT BAR FIT SUPPORT BAR The Tuff Tonneau Multi - Fit Support Bar is designed to fit almost all Utes on the Market, from Suburu Brumbys to Cab Chassis aluminium trays.
