TONNEAU INSTALLATION INSTRUCTION
PROTON JUMBUCK, With Sports Bars
Package includes
1 X Tonneau cover
1 x Tonneau Support Bar (300516)
3 x Aluminium Rope Track-385mm long ea.
1 x Support Bar Sheath
1 x Fitting Instructions
1 x Warranty Card
2003- Current
Part number: 693SB
2 x Bar Brackets (300474)
24 x Rivets (300482)
1 x Lock Bracket
14 x Rope Buttons (300473)
4 x Dowel
Advertisement
Table of Contents
Related Manuals for Tuff Tonneaus 693SB
Summary of Contents for Tuff Tonneaus 693SB
- Page 1 TONNEAU INSTALLATION INSTRUCTION PROTON JUMBUCK, With Sports Bars 2003- Current Part number: 693SB Package includes 1 X Tonneau cover 2 x Bar Brackets (300474) 1 x Tonneau Support Bar (300516) 24 x Rivets (300482) 3 x Aluminium Rope Track-385mm long ea.
- Page 2 Table of Contents TONNEAU COVER FITTING ......................3 1.1 BASIC TOOL REQUIRED ......................... 3 1.2 TONNEAU COVER INSTALLATION PROCEDURE ................3 TONNO LOCK ........................... 5 2.1 BASIC TOOL REQUIRED ......................... 5 2.2 TONNO LOCK CONTENTS ......................5 2.3 FITTING TONNO LOCK ........................5 MULTI-FIT SUPPORT BAR ........................
- Page 3 1. 1. 1. 1. TONNEAU COVER FITTING TONNEAU COVER FITTING TONNEAU COVER FITTING TONNEAU COVER FITTING NOTE Read entire instructions prior to start. 1.1 BASIC TOOL REQUIRED 1.1 BASIC TOOL REQUIRED 1.1 BASIC TOOL REQUIRED 1.1 BASIC TOOL REQUIRED Drill, 4mm Drill Bit, Rivet Gun, Marking Pencil / Pen 1.2 TONNEAU COVER INSTALLATION PROCEDURE 1.2 TONNEAU COVER INSTALLATION PROCEDURE 1.2 TONNEAU COVER INSTALLATION PROCEDURE...
- Page 4 Figure 1 Placement of aluminium rope track. Ensure channel is above the lip’s top edge. Placement of side sealing angles Figure 2 Placement of bar bracket. Figure 3 Placement of rope button Measure145MM down from inside edge and place button on centre of measurement.
- Page 5 TONNO LOCK TONNO LOCK The Tonno Lock is now a standard feature included with all Tuff Tonneaus. The Tonno Lock is situated at the front of the tonneau cover, so as not to impede the accessibility of the Tuff Tonneau.
- Page 6 3. 3. 3. 3. MULTI MULTI MULTI- - - - FIT SUPPORT BAR MULTI FIT SUPPORT BAR FIT SUPPORT BAR FIT SUPPORT BAR The Tuff Tonneau Multi - Fit Support Bar is designed to fit almost all Utes on the Market, from Suburu Brumbys to Cab Chassis aluminium trays.
