WRANGLER
3-IN-1 GROW WITH ME
WALKER
22508
WARNING:
CHOKING HAZARD
Adult assembly required because of
small parts. Keep assembly parts out
of reach of children under 3 years.
REQUIRED: (x2) "AA" Batteries (not included)
Phillips Screwdriver (not included)
Read all instructions BEFORE assembly and USE of product
Customer Experience Center
phone: (646) 435-8726
email: gcs@DeltaChildren.com
INSTRUCTION MANUAL
KEEP INSTRUCTIONS FOR FUTURE USE.
www.DeltaChildren.com
ADULT ASSEMBLY REQUIRED
STYLES AND COLORS MAY VARY
DCP-IM-20200525
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Delta Children Jeep WRANGLER 22508
Summary of Contents for Delta Children Jeep WRANGLER 22508
- Page 1 WRANGLER 3-IN-1 GROW WITH ME WALKER INSTRUCTION MANUAL 22508 ADULT ASSEMBLY REQUIRED STYLES AND COLORS MAY VARY WARNING: CHOKING HAZARD Adult assembly required because of small parts. Keep assembly parts out of reach of children under 3 years. REQUIRED: (x2) “AA” Batteries (not included) Phillips Screwdriver (not included) Read all instructions BEFORE assembly and USE of product KEEP INSTRUCTIONS FOR FUTURE USE.
-
Page 2: Care And Maintenance
WARNING Failure to follow these warnings and instructions could result in serious injury or death. Read all instructions before assembling unit. KEEP INSTRUCTIONS FOR FUTURE USE. DO NOT USE THIS UNIT IF THE INSTRUCTIONS CANNOT BE STRICTLY FOLLOWED. WARNING • To reduce chance of child slipping out of seat, WARNING: always check that both feet of child touch floor. • NEVER LEAVE CHILD UNATTENDED! • Use only for children who can sit upright • ALWAYS KEEP CHILD IN VIEW WHILE IN unassisted and weigh no more than 25 lbs. WALKER. • NEVER carry walker or adjust height with child • NEVER use near stairs or thresholds. in it. • Before each use clean friction components to • Walk behind mode is only intended for use by maintain stopping performance. - Page 3 Before returning this product to the store! Let’s see if we can assist you! • Not sure how to assemble our product? Visit our site for easy to follow instructions along with some Tricks and Tips assembly videos https://www.deltachildren.com/pages/instructions • If you are missing a piece or have a damaged part Please contact our Consumer Experience Center for assistance at 646-435-8726 or email gcs@DeltaChildren.com.
-
Page 4: Limited Manufacturer Warranty
LIMITED MANUFACTURER WARRANTY This Delta product is warranted to be free from defects for a period of 90 days from the date of purchase under normal use. If a product is defective during this period, we will at our option repair or replace the defective part or product. - Page 5 Parts IMPORTANT! Please remove all parts from the package and identify them before assembly. Front Bar Toy Tray Walker Top Tray Front Wheels x2 Walker Bottom Base Wheels x4 Rear Wheels x2 Seat Pad Storage Bin Storage Cap www.DeltaChildren.com Customer Service Tel.
-
Page 6: Battery Safety Information
Battery Safety Information BATTERY SAFETY INFORMATION • Never short-circuit the battery terminals. • Use only batteries of the same or equivalent In exceptional circumstances, batteries may type as recommended. leak fluids that can cause a chemical burn • Do not charge non-rechargeable batteries. injury or ruin your product. - Page 7 Walker Assembly Walk Behind WARNING: Walk Behind Mode is only intended for use by children 9 months - 3 years. Walk Behind Bar (For Walk Behind Mode) • Locate the walk behind bar. • Press the two side buttons to adjust height up and down. •...
- Page 8 Walker Assembly Front Bar Seat Pad Bottom Walker Top Tray Adjustable Seat Strap CLICK Attaching Front Bar • Align the two bottom nubs of front bar to top tray recesses and press down until it clicks. •Pull upward on front bar to assure it is in a fully locked position. •...
- Page 9 Walker Top Tray Assembly Wheel Wheel Joint CLICK Walker Bottom Plastic Joint Notches Attaching Wheels to Walker Top Tray • Locate x4 wheels. • Align wheels so plastic notches are facing outward of walker. • Insert the wheel joint into the walker bottom housing and push down until the plastic notches engage. •...
- Page 10 Walker Bottom Base Assembly Rear Wheel Front Wheel Walker Bottom Base Rear Wheel TOP VIEW Align rear wheel pin to Rear Wheel bottom rear wheel groove. Groove Attaching Wheels to Walker Bottom Base • Locate front wheels and walker bottom base. •...
- Page 11 Walker Assembly Bottom Lock Housing ALIGN ALIGN “X” Frame PULL PULL PULL Tubings Bottom Lock Bottom Lock Bottom Lock BACK Housing Tab Housing Tab Housing FRONT RELEASE RELEASE Attaching Walker Top Tray • Align bottom lock housings in between the 2 nubs of “X”Frame Tubing. Make sure walker top tray is facing FRONT position, by aligning the front sticker located on the x frame tubings and the walker top tray.
- Page 12 Storage Bin Assembly WARNING: Floor Toy Car Mode is not to be used as a ride-on toy. Bottom Walker Lip Storage Bin with storage cap attached Side Lock Walker Seat Hole Attaching Storage Bin • Locate Storage Bin and Storage Cap. •...
- Page 13 Seat Height Adjustability FRONT BACK Buckle Inner Strap To Increase Seat Height To increase the height of the seating position, Pull Strap Downwards. FRONT BACK Buckle Inner Strap To Lower Seat Height To lower the height of the seating position, hold buckle with one hand and pull inner strap downward. www.DeltaChildren.com Customer Service Tel.
- Page 14 Notes www.DeltaChildren.com Customer Service Tel. (646) 435-8726...
- Page 15 Notes...
- Page 16 Delta Children's Products Corp. 114 West 26 Street New York, NY 10001 646-435-8726 www.DeltaChildren.com © 2020 Delta Children's Products. All rights reserved.
