Summary of Contents for Delta Children Big Steps 2-in-1 Activity Walker
Page 1
Big Steps 2-in-1 Activity Walker INSTRUCTION MANUAL ADULT ASSEMBLY REQUIRED STYLES AND COLORS MAY VARY 32201/ LF10223 REQUIRED: 2 x AA Batteries (not included) Screwdriver (not included) WARNING: CHOKING HAZARD Adult assembly required because of small parts. Keep assembly parts out of reach of children under 3 years.
Failure to follow these warnings and instructions could result in serious injury or death. Read all instructions before assembling unit. KEEP INSTRUCTIONS FOR FUTURE USE. DO NOT USE THIS UNIT IF THE INSTRUCTIONS CANNOT BE STRICTLY FOLLOWED. WARNING: • NEVER LEAVE CHILD UNATTENDED! •...
Page 4
Parts IMPORTANT! Please remove all parts from the package and identify them before assembly. Top Tray Seat Part # Walker Base 2030 (Exploration) - 50326 2031 (Orbit) - 50326 Toy Tray Part # Anti Slip Blocks x6 2030 (Exploration) - 50327 Part # 50323 2031 (Orbit) - 50327 Front Swivel Wheels x2...
Page 5
Walker Assembly Rear Wheels Front Swivel Wheels Anti Slip Blocks • Locate 2x front swivel wheels and walker base. • Locate the walker base and 6x anti slip blocks. • Place the walker on a solid flat surface with the bottom facing •...
Page 6
Walker Assembly REAR PINS *Assembly directions on page 7 FRONT PINS *Assembly directions on page 7 Customer Service Email: gcs@DeltaChildren.com www.DeltaChildren.com...
Page 7
Walker Assembly VIEW UNDERNEATH TOY TRAY FRONT ASSEMBLY Fig.3 Fig.1 SEAT PINS Fig.2 • Once the seat is installed, inspect underneath the tray to ensure that the seat pins are firmly in place and locked-in tightly (Fig. 3). REAR ASSEMBLY Attaching seat pad FRONT pins to the top tray: •...
Battery Safety Information In exceptional circumstances, batteries may leak fluids that can cause a chemical burn injury or ruin your product. To avoid battery leakage: • Do no mix old and new batteries or batteries of different types: Alkaline, standard (carbon zinc) or rechargeable (nickel-cadmium).
Page 9
Walker Assembly Adjust the Height and Fold toy tray lock slots toy tray lock tabs top tray lock tabs locked position unlocked position • On the bottom of the toy tray locate the lock slots and lock tabs SAFETY BUTTON on top tray.
Page 10
Customer Service Email: gcs@DeltaChildren.com www.DeltaChildren.com...
Page 11
Customer Service Email: gcs@DeltaChildren.com www.DeltaChildren.com...
Page 12
Customer Service Email: gcs@DeltaChildren.com www.DeltaChildren.com...
