Summary of Contents for ENS IP-5VP5032VF

  • Page 2 Notes on Safety  Please use the specified power supply to connect.  Do not attempt to disassemble the camera; in order to prevent electric shock, do not remove screws or covers.  There are no user-serviceable parts inside. Please contact the nearest service center as soon as possible if there is any failure.
  • Page 3: Table Of Contents

    Table of Contents Introduction ........................1 IE Remote Access ......................2 LAN ........................2 2.1.1 Access through IP-Tool ................2 2.1.2 Directly Access through IE ............... 3 WAN ........................5 Remote Preview ......................8 The Remote Preview Interface ................8 Playback .........................
  • Page 4 Network Camera User Manual 4.5.8 Mail configuration .................. 25 4.5.9 FTP Setting ..................... 26 Advanced Configuration..................26 4.6.1 User Configuration ................. 26 4.6.2 Security Configuration................28 4.6.3 Configure Backup & Restore ..............28 4.6.4 Reboot ....................29 4.6.5 Upgrade ....................29 Video Search .........................
  • Page 5: Introduction

    Network Camera User Manual 1 Introduction This IP-CAMERA (short for IP-CAM) is designed for high performance CCTV solutions. It adopts state of the art video processing chips. It utilizes most advanced technologies, such as video encoding and decoding technology, complies with the TCP/IP protocol, SoC, etc to ensure this system more stable and reliable.
  • Page 6: Ie Remote Access

    Network Camera User Manual 2 IE Remote Access You may connect IP-Cam via LAN or WAN. Here only take IE browser (6.0) for example. The details are as follows: 2.1 LAN In LAN, there are two ways to access IP-Cam: 1. access through IP-Tool; 2. directly access through IE browser.
  • Page 7: Directly Access Through Ie

    Network Camera User Manual of your device according to the practical situation. For example, the IP address of your computer is 192.168.1.4. So the IP address of the camera shall be changed to 192.168.1.X. After modification, please input the password of the administrator and click “Modify”...
  • Page 8 Network Camera User Manual You may use the above default settings when you log in the camera for the first time. You may directly connect the camera to the computer through network cable. ① Manually set the IP address of the PC and the network segment should be as the same as the default settings of the IP camera.
  • Page 9: Wan

    Network Camera User Manual ② Open the IE browser and input the default address of IP-CAM and confirm. The IE browser will download Active X control automatically. ③ After downloading Active X control, the login dialog box will pop up. ④...
  • Page 10 Network Camera User Manual IP Setup ③ Go to the router’s management interface through IE browser to forward the IP address and port of the camera in the “Virtual Server”. Router Setup ④ Open the IE browser and input its WAN IP and http port to access. ...
  • Page 11 Network Camera User Manual ③ Go to Config Network ConfigDDNS Config menu. Before you configure the DDNS, please apply for a domain name first. Please refer to 4.4.5 DDNS Configuration for detail information. ④ Open the IE browser and input the domain name and http port to access. ...
  • Page 12: Remote Preview

    Network Camera User Manual 3 Remote Preview 3.1 The Remote Preview Interface Icon Description Icon Description Motion alarm Sensor alarm indicator icon indicator icon Fix size Start/Stop record Actual size Playback Zoom in Snap Zoom out Talk Full screen Enable audio When motion detection alarm is triggered, the people icon will ...
  • Page 13: Playback

    Network Camera User Manual view the image from every direction by controlling PTZ panel. The descriptions of the control panel are as follows: Button Description to rotate the dome upwards; to rotate the dome downwards; to rotate the dome towards left; to rotate the dome towards right;...
  • Page 14: Snap Pictures

    Network Camera User Manual 3.3 Snap Pictures Select the picture number, and then click “Snap” icon as shown below: Single Snap Snap multiple pictures: Select the picture number from Frame pull down list box, such as 2, and check “Title” and “Time”...
  • Page 15: Remote Live Surveillance

    Network Camera User Manual 4 Remote Live Surveillance Functions of remote configurations include: System Configuration, Video Configuration, PTZ Configuration, Alarm Configuration, Network Configuration and Advanced Configuration. You should select the menu on the left, and then set up the relative parameters. 4.1 System Configuration The “System configuration”...
  • Page 16: Date & Time

    Network Camera User Manual 4.1.2 Date & Time Setting steps: 1. Go to System ConfigDate & Time menu as shown below. 2. Set time zone. 3. Enable DST mode as required. 4. Set time. You may set time manually or enable NTP. 4.1.3 SD Card 1.
  • Page 17: Camera

    Network Camera User Manual 4.2.1 Camera Setting steps: 1.Go to “Video Configuration”  “Camera” interface as shown below. 2. You may adjust frequency, brightness, contrast, hue and saturation of the picture. 3. Select white balance mode. 4. Wide dynamic, sharpen, and denoise are adjustable. 5.
  • Page 18: Osd Configuration

    Network Camera User Manual video resources. This will help to optimize the network bandwidth. Video Quality: When VBR is selected, you need to choose image quality. The higher the image quality you choose, the more bitrate will be required. Bitrate: Please choose it according to the actual network situation. I Frame interval: It is recommended to use the default value.
  • Page 19: Roi Configuration

    Network Camera User Manual To set up video mask 1. Enable video mask. 2. Click “Draw” button and then drag the mouse to draw the video mask area. 3. Click “Save” button to save the settings. 4. Return to the live to see the following picture. Clear the video mask: Go to video mask menu and then click “Clear”...
  • Page 20: Ptz Configuration

    Network Camera User Manual Now, you will see the selected ROI area is clearer than other areas especially in low bitrate condition. 4.3 PTZ Configuration PTZ Configuration includes two submenus: Protocol and Preset. 4.3.1 Protocol 1. Go to “PTZ Configuration” “Protocol” interface as shown below: 2.
  • Page 21: Preset Configuration

    Network Camera User Manual 4.3.2 Preset Configuration 1. Go to “PTZ Configuration” “Preset” to see an interface as shown below: Button Meanings to rotate the dome upwards; to rotate the dome downwards; to rotate the dome towards left; to rotate the dome towards right; to stop rotating the dome.
  • Page 22: Motion Detection Trigger

    Network Camera User Manual area. Select “Erase” and move the mouse to clear all motion detection area. 4. Press the “Save” button to save the settings. 4.4.2 Motion Detection Trigger 1. Go to “Alarm Configuration” “Motion Detection Trigger” to display an interface as ...
  • Page 23: Motion Detection Schedule

    Network Camera User Manual FTP server address. Please refer to FTP configuration chapter for more details. 5. Press the “Save” button to save the settings. 4.4.3 Motion Detection Schedule Go to “Alarm configuration” “Motion Detection schedule” interface as shown below. Week schedule You can set the alarm time from Monday to Sunday for alarm everyday in one week.
  • Page 24: Alarm Input Schedule

    Network Camera User Manual 2. Select the sensor at the “Sensor” pull down list and set the sensor name and alarm type: NO and NC. 3. Enable alarm and select alarm holding time. 4. Set alarm trigger options. The setting steps are the same as that of motion detection trigger. Please refer to motion detection trigger chapter for details.
  • Page 25: Alarm Out

    Network Camera User Manual 4.4.6 Alarm Out 1. Go to “Alarm configuration” “Alarm output” as shown below: 2. Select alarm holding time and alarm name at the “Alarm out” and “Alarm holding time” pull down list box respectively. 3. Press the “Save” button to save the settings. 4.4.7 Alarm Server Go to “Alarm configuration”...
  • Page 26: Ip Address

    Network Camera User Manual 4.5.2 IP Address 1. Go to “Network Configuration” “IP Address”.  There are two options for IP setup: obtain an IP address auto by DHCP protocol and use the following IP address. You may choose one of options as required. Use the following IP address: display the IP address, subnet mask, gateway and DNS of the device.
  • Page 27: Ip Notify

    Network Camera User Manual 2. Check the IP address and port of the transfer media server in the CMS/NVMS. Then enable the auto report in the CMS/NVMS when adding a new device. Next, self-define the device ID and input the remaining information of the device in the CMS/NVMS. 3.
  • Page 28: Rtsp

    Network Camera User Manual Create domain name. After you successfully request your domain name, you will see your domain in the list. 3. Select the server type and then input the username, password and domain name you apply for in the DDNS configuration interface. 4.
  • Page 29: Upnp

    Network Camera User Manual Select “Enable RTSP server”. RTSP Port: Access Port of the streaming media. The default number is 554. RTSP Address: The RTSP address you need to input in the media player. You can also choose to enable anonymous viewer login. 4.5.7 UPNP Go to “Network Configuration”...
  • Page 30: Ftp Setting

    Network Camera User Manual successful, a “Test Successful” window will pop up, if not, users can try other email addresses or check the setting. Notice: If you change the static IP into PPPoE and select mailbox, there will be an e-mail sent to your mail box for notifying a new IP address.
  • Page 31 Network Camera User Manual User Configuration Add User Note: After binding physical address to the IP-CAM, you can access the device on this PC in network only. If the MAC address is “00:00:00:00:00:00”, it means the camera can be connected to any computers. 2.
  • Page 32: Security Configuration

    Network Camera User Manual Note: The default super administrator cannot be deleted. Parameter Meaning User Name User name to operate the logon client end User Type Type of users, normal user, advanced user and super administrator The MAC addresses of user access the server which should set up Binding MAC address according to actual MAC address of server.
  • Page 33: Reboot

    Network Camera User Manual You can import or export the setting information from PC or to device. 1. Click “Browse” to select save path for import or export information on PC. 2. You can import or export all setting information to PC, but those two settings “User Configuration”...
  • Page 34: Video Search

    Network Camera User Manual 5 Video Search Click “Picture” icon and search the images saved in the SD card. Set time: Select date in the “Calendar” and choose the start and end time. Choose event “Motion” or “Sensor”. Click “Search” button to search the picture. Double click a filename or select a filename and then click “View”...
  • Page 35 Network Camera User Manual Item Buttons Explanations Close: Select certain picture and click this button to close this picture. Close all: Click this button to close all pictures viewing. Save: Click this button to select the save path of the picture file on the PC for saving the current picture.
  • Page 36 Network Camera User Manual 6 Q & A Q: How to find my password if I forget it? A:Reset the device to the default factory settings. Default IP: 192.168.226.201 User name: admin Password: 123456 Q:Fail to connect devices through IE browser, why? A: Network is not well connected.
  • Page 37 Network Camera User Manual ④ Then click OK to finish setup. b. Other plug-ins or anti-virus blocks ActiveX. Please uninstall or close them. Q:No sound can be heard, why? A:Audio input device is not connected. Please connect and try again. B: Audio function is not enabled at the corresponding channel.
  • Page 38: Appendix

    Network Camera User Manual Appendix Appendix 1 — Installation of Water-proof Rubber Plug For the purpose of better water-proof, the rubber plugs are attached to some network bullet cameras. You may mount the rubber plugs to the mounting base of the camera as requried when installing.
