ENS Face Detection Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Face Detection Series
2
Megapixel
Network
Camera
User Manual
Please read this instruction carefully before operating the unit and keep it for further
reference

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Face Detection Series and is the answer not in the manual?

Questions and answers

Related Manuals for ENS Face Detection Series

Summary of Contents for ENS Face Detection Series

  • Page 1 Face Detection Series Megapixel Network Camera User Manual Please read this instruction carefully before operating the unit and keep it for further reference...
  • Page 2 Notes on Safety  This product is intended to be supplied by a Listed Power Unit, marked with 'Limited Power Source', 'LPS' on unit, output rated minimum 12V/2 A or POE 48V/ 350mA or AC24V (depending on models), no more than 2000m altitude of operation and Tma=60 Deg.C.

  • Page 3: Table Of Contents

    Table of Contents Introduction ........................1 Network Connection ...................... 2 LAN ..............................2 2.1.1 Access through IP-Tool ....................2 2.1.2 Directly Access through IE ..................... 4 WAN ............................... 5 Live View ........................8 Network Camera Configuration ................. 11 System Configuration........................11 4.1.1 Basic Information ......................
  • Page 4 Network Camera User Manual 4.6.4 DDNS ........................... 45 4.6.5 SNMP ........................... 47 4.6.6 802.1x ........................... 48 4.6.7 RTSP ..........................49 4.6.8 UPNP ........................... 50 4.6.9 Email ..........................50 4.6.10 FTP ..........................51 4.6.11 HTTPS.......................... 51 4.6.12 P2P (Optional) ......................53 4.6.13 QoS..........................

  • Page 5: Introduction

    Network Camera User Manual 1 Introduction This IP-CAMERA (short for IP-CAM) is designed for high performance CCTV solutions. It adopts state of the art video processing chips, integrated with the most advanced technologies (like video encoding and decoding technology) to make the image transmission more stable and smooth.

  • Page 6: Network Connection

    Network Camera User Manual 2 Network Connection Connect IP-Cam via LAN or WAN. Here only take IE browser for example. The details are as follows: 2.1 LAN In LAN, there are two ways to access IP-Cam: 1. access through IP-Tool; 2. directly access through IE browser.
  • Page 7 Network Camera User Manual For example, the IP address of your computer is 192.168.1.4. So the IP address of the camera shall be changed to 192.168.1.X. After modification, please enter the password of the administrator and click the “Modify” button to modify the setting. ...

  • Page 8: Directly Access Through Ie

    Network Camera User Manual The system will pop up the above-mentioned textbox to ask you to change the default password. It is strongly recommended to change the default password for account security. If “Do not show again” is checked, the textbox will not be prompted next time. 2.1.2 Directly Access through IE The default network settings are as shown below: IP address: 192.168.226.201...

  • Page 9: Wan

    Network Camera User Manual ② Open the IE browser and enter the default address of IP-CAM and confirm. ③ Follow directions to download and install the Active X control. ④ Enter the default username and password in the login window and then enter to view. 2.2 WAN ...
  • Page 10 Network Camera User Manual IP Setup ③ Go to the router’s management interface through IE browser to forward the IP address and port of the camera in the “Virtual Server”. Router Setup ④ Open the IE browser and enter its WAN IP and http port to access. (for example, if the http port is changed to 81, please enter “192.198.1.201:81”...
  • Page 11 Network Camera User Manual ① Go to ConfigNetworkPort menu to set the port number. ② Go to Config NetworkTCP/IPPPPoE Config menu. Enable PPPoE and then enter the user name and password from your internet service provider. ③ Go to Config NetworkDDNS menu. Before configuring the DDNS, please apply for a domain name first.

  • Page 12: Live View

    Network Camera User Manual 3 Live View After logging in, the following window will be shown. The following table is the instructions of the icons on the live view interface. Icon Description Icon Description Original size SD card recording indicator Fit correct scale Color abnormal indicator Auto (fill the window)
  • Page 13 Network Camera User Manual Icon Description Icon Description Zoom in People intrusion indicator Zoom out Sensor alarm indicator PTZ control Motion alarm indicator AZ control (only available model with Face detection indicator motorized zoom lens ) Those smart alarm indicators will flash only when the camera supports those functions and the corresponding events are enabled.
  • Page 14 Network Camera User Manual Auto scan Wiper Light Radom scan Group scan Preset Select preset and click to call the preset. Select and set the preset and then click save the position of the preset. Select the set preset and click to delete it...

  • Page 15: Network Camera Configuration

    Network Camera User Manual 4 Network Camera Configuration In the Webcam client, choose “Config” to go to the configuration interface. Note: Wherever applicable, click the “Save” button to save the settings. 4.1 System Configuration 4.1.1 Basic Information In the “Basic Information” interface, the system information of the device is listed. Some versions may support device ID and QR code.

  • Page 16: Local Config

    Network Camera User Manual Click the “Date and Time” tab to set the time mode. 4.1.3 Local Config Go to ConfigSystemLocal Config to set up the storage path of captured pictures and recorded videos on the local PC. There is also an option to enable or disable the bitrate display in the recorded files.
  • Page 17 Network Camera User Manual Snapshot Quota: Set the capacity proportion of captured pictures on the SD card. Video Quota: Set the capacity proportion of record files on the SD card.  Schedule Recording Settings    1. Go to Config System Storage Record to go to the interface as shown below.

  • Page 18: Image Configuration

    Network Camera User Manual Day schedule Set the alarm time for alarm a special day, such as a holiday. Note: Holiday schedule takes priority over weekly schedule.  Snapshot Settings    Go to Config System Storage Snapshot to go to the interface as shown below. Set the format, resolution and quality of the image saved on the SD card and the snapshot interval and quantity and the timing snapshot here.
  • Page 19 Network Camera User Manual effect can be quickly seen by switching the configuration file. Brightness: Set the brightness level of the camera’s image. Contrast: Set the color difference between the brightest and darkest parts. Hue: Set the total color degree of the image. Saturation: Set the degree of color purity.

  • Page 20: Video / Audio Configuration

    Network Camera User Manual image’s bright area and reducing the size of the halo area.  BLC: If enabled, the auto exposure will activate according to the scene so that the object of the image in the darkest area will be seen clearly. Antiflicker: ...
  • Page 21 Network Camera User Manual Click the “Audio” tab to go to the interface as shown below. Three video streams can be adjustable. Resolution: The size of image. Frame rate: The higher the frame rate, the video is smoother. Bitrate type: CBR and VBR are optional. Bitrate is related to image quality. CBR means that no matter how much change is seen in the video scene, the compression bitrate will be kept constant.

  • Page 22: Osd Configuration

    Network Camera User Manual Audio Encoding: G711A and G711U are selectable. Audio Type: LIN or MIC optional. 4.2.3 OSD Configuration Go to ImageOSD interface as shown below. Set time stamp, device name, OSD content and picture overlap here. After enabling the corresponding display and entering the content, drag them to change their position.

  • Page 23: Roi Configuration

    Network Camera User Manual To set up video mask: 1. Enable video mask. 2. Click the “Draw Area” button and then drag the mouse to draw the video mask area. 3. Click the “Save” button to save the settings. 4. Return to the live to verify that the area have been drawn as shown as blocked out in the image.

  • Page 24: Lens Control

    Network Camera User Manual 1. Check “Enable” and then click the “Draw Area” button. 2. Drag the mouse to set the ROI area. 3. Set the level. 4. Click the “Save” button to save the settings. 4.2.6 Lens Control This function is only available for the model with motorized zoom lens. Within this section, zoom and focus can be controlled.

  • Page 25: Ptz Configuration

    Network Camera User Manual 4.3 PTZ Configuration This function is only available for the models with RS485 interface. It can be used with a compatible external PTZ enclosure. Go to PTZProtocol interface as shown below. Set the protocol, address and baud rate according to the PTZ. 4.4 Alarm Configuration 4.4.1 Motion Detection Go to AlarmMotion Detection to set motion detection alarm.
  • Page 26 Network Camera User Manual 1. Check “Enable” check box to activate motion based alarms. If unchecked, the camera will not send out any signals to trigger motion-based recording to the NVR or CMS, even if there is motion in the video. Alarm Out: If selected, this would trigger an external relay output that is connected to the camera on detecting a motion based alarm.

  • Page 27: Other Alarms

    Network Camera User Manual Move the “Sensitivity” scroll bar to set the sensitivity. Higher sensitivity value means that motion will be triggered more easily. Select “Add” and click “Draw”. Drag the mouse to draw the motion detection area; Select “Erase” and drag the mouse to clear motion detection area. After that, click the “Save”...

  • Page 28: Alarm In

    Network Camera User Manual 3. Set alarm trigger options. Trigger alarm out, Email and FTP. The setup steps are the same as motion detection. Please refer to motion detection chapter for details.  IP Address Conflict This function is only available for the models with Alarm Out interface. ...

  • Page 29: Alarm Out

    Network Camera User Manual 1. Click “Enable” and set the alarm type, alarm holding time and sensor name. 2. Set alarm trigger options. The setup steps are the same as motion detection. Please refer to motion detection chapter for details. 3.

  • Page 30: Alarm Server

    Network Camera User Manual Day/Night Switch Linkage: Having selected this mode, choose to open or close alarm out when the camera switches to day mode or night mode. Schedule: Click “Add” and drag the mouse on the timeline to set the schedule of alarm out; click “Erase”...

  • Page 31: Object Removal

    Network Camera User Manual  At any time of day or night, please make sure the image of the camera is clear and with adequate and even light, avoiding overexposure or too much darkness on both sides. 4.5.1 Object Removal Alarms will be triggered when the objects removed from or left at the pre-defined area.
  • Page 32 Network Camera User Manual Set the alarm area number and then enter the desired alarm area name. Up to 4 alarm areas can be added. Click the “Draw Area” button and then click around the area where you want to set as the alarm area in the image (the alarm area should be a closed area).

  • Page 33: Exception

    Network Camera User Manual There are so many trees near the road and cars running on the road, which make the scene too complex to detect the removal objects. 4.5.2 Exception This function can detect changes in the surveillance environment affected by the external factors.

  • Page 34: Line Crossing

    Network Camera User Manual motion detection. Please refer to motion detection chapter for details. 3. Click “Save” button to save the settings. 4. Set the sensitivity of the exception detection. Click “Sensitivity” tab to go to the interface as shown below. Drag the slider to set the sensitivity value or directly enter the sensitivity value in the textbox.
  • Page 35 Network Camera User Manual 1. Enable line crossing alarm and set the alarm holding time. 2. Set alarm trigger options. The setup steps are the same as motion detection. Please refer to motion detection chapter for details. 3. Click “Save” button to save the settings. 4.
  • Page 36 Network Camera User Manual A->B: The alarm will be triggered when the intruder crosses over the alarm line from A to B. A<-B: The alarm will be triggered when the intruder crosses over the alarm line from B to A. Click the “Draw Area”...

  • Page 37: Intrusion

    Network Camera User Manual The ground is covered with vegetation; at the right of the fence is a gym where people pass by frequently. The above mentioned environment is too complex to detect the crossing objects. 4.5.4 Intrusion Intrusion: Alarms will be triggered if someone or something intrudes into the pre-defined areas.
  • Page 38 Network Camera User Manual Set the alarm area number on the right side. Up to 4 alarm areas can be added. Click the “Draw Area” button and then click around the area where you want to set as the alarm area in the image on the left side (the alarm area should be a closed area). Click the “Stop Draw”...

  • Page 39: Crowd Density Detection

    Network Camera User Manual The camera’s angle of depression is not wide enough; there are so many trees in the scene. The above mentioned environment is too complex to detect the intrusion. The camera’s angle of depression is not wide enough;...
  • Page 40 Network Camera User Manual 1. Enable the crowd density detection. 2. Set “Refresh Frequency”, “Density Alarm Threshold” and “Alarm Holding Time”. Refresh Frequency: The refresh frequency of the detection result. Density Alarm Threshold: Alarms will be triggered once the percentage of the crowd density in a specified area exceeds the pre-defined threshold value.

  • Page 41: People Intrusion

    Network Camera User Manual 5. Set the schedule of the crowd density detection. The setup steps of the schedule are the same as schedule recording setup (See Schedule Recording). ※Configuration of camera and surrounding area 1. The camera lens should face to the people flow. The direction of the people flow is allowed to deviate slightly from the direction of the camera lens (The angle (a) shall be less than 45°...

  • Page 42: People Counting

    Network Camera User Manual if someone enters into the detection area in 3~5s. The setup steps are as follows. 1. Go to ConfigEventPeople Intrusion. Please refer to the following picture. 2. Enable the people intrusion detection. 3. Set “Alarm Sensitivity” and “Alarm Holding Time”. 4.
  • Page 43 Network Camera User Manual 1. Go to ConfigEventPeople Counting. Please refer to the following picture. 2. Enable the people counting detection. 3. Set “Detection Sensitivity”, “Entrancing Threshold”, “Departing Threshold”, “Staying Threshold”, “Counting Period”, “Alarm Holding Time” and so on. Counting Period: All, daily, weekly and monthly are optional. Counting Reset: The current number of people counting will be cleared and the current counting period will restart by clicking “Reset”...
  • Page 44 Network Camera User Manual Click “Draw Area” and drag the mouse to draw a rectangle area. Drag the four border lines or the four corners of the rectangle to modify its size. Click “Stop Draw” to stop drawing the area. Click “Clear” to clear the area. Click and drag the arrow or the other end of the arrow line to change the people entrance direction.

  • Page 45: Face Detection

    Network Camera User Manual Remember keeping a certain space on both sides to let the entrance/exit lie in the center of the entire image. The recommending height of installation as shown below: Lens Mounting height 2.8mm 2.6 ~ 3.2m 3.3mm 3.0 ~ 4.0m 3.6mm 3.3 ~ 5.0m...
  • Page 46 Network Camera User Manual 2. Enable the face detection function and then select auto detection or interval detection. Save Source Information: if checked, the whole picture will be saved to a local PC or an SD card when detecting a face. Save Face Information: if checked, the captured face picture will be saved to a local PC or an SD card when detecting a face.

  • Page 47: Network Configuration

    Network Camera User Manual ※ Configuration requirements of camera and surrounding area 1. Cameras must be installed in the area with stable and adequate light sources. 2. The installation height ranges from 2.0m to 3.5m, adjustable according to the focal-length of different lenses and object distances.
  • Page 48 Network Camera User Manual Use IP address (take IPv4 for example)-There are two options for IP setup: obtain an IP address automatically by DHCP and use the following IP address. Please choose one of the options as needed. Test: Test the effectiveness of the IP address by clicking this button. Use PPPoE-Click the “PPPoE Config”...

  • Page 49: Port

    Network Camera User Manual 4.6.2 Port Go to ConfigNetworkPort interface as shown below. HTTP port, Data port and RTSP port can be set. HTTP Port: The default HTTP port is 80. It can be changed to any port which is not occupied.
  • Page 50 Network Camera User Manual 2. Apply for a domain name. Take www.dvrdyndns.com for example. Enter www.dvrdydns.com in the IE address bar to visit its website. Then Click the “Registration” button. Create domain name. After the domain name is successfully applied for, the domain name will be listed as below. 3.

  • Page 51: Snmp

    Network Camera User Manual 4. Click the “Save” button to save the settings. 4.6.5 SNMP To get camera status, parameters and alarm information and remotely manage the camera, the SNMP function can be used. Before using SNMP, please install an SNMP management tool and set the parameters of the SNMP, such as SNMP port, trap address.

  • Page 52: 802.1X

    Network Camera User Manual Note: Please use the different version in accordance with the security level you required. The higher the version is, the higher the level of the security is. 4.6.6 802.1x IEEE802.X which is an access control protocol manages the device in connection with the local network by authentication.

  • Page 53: Rtsp

    Network Camera User Manual 4.6.7 RTSP Go to ConfigNetworkRTSP. Select “Enable” to enable the RTSP function. Port: Access port of the streaming media. The default number is 554. RTSP Address: The RTSP address (unicast) format that can be used to play the stream in a media player.

  • Page 54: Upnp

    Network Camera User Manual 4.6.8 UPNP If this function is enabled, the camera can be quickly accessed through the LAN. Go to ConfigNetworkUPnP. Enable UPNP and then enter UPnP name. 4.6.9 Email If you need to trigger Email when an alarm happens or IP address is changed, please set the Email here first.

  • Page 55: Ftp

    Network Camera User Manual SMTP Port: The SMTP port. Send Interval(S): The time interval of sending email. For example, if it is set to 60 seconds and multiple motion detection alarms are triggered within 60 seconds, they will be considered as only one alarm event and only one email will be sent.
  • Page 56 Network Camera User Manual Go to Config ConfigNetworkHTTPS as shown below. There is a certificate installed by default as shown above. Enable this function and save it. Then the camera can be accessed by entering https://IP: https port via the web browser (eg. https://192.168.226.201:443).

  • Page 57: P2P (Optional)

    Network Camera User Manual Click “Create” to create the certificate request. Then download the certificate request and submit it to the trusted certificate authority for signature. After receiving the signed certificate, import the certificate to the device. 4.6.12 P2P (Optional) If this function is enabled, the network camera can be quickly accessed by adding the device ID in mobile surveillance client or CMS/NVMS client via WAN.
  • Page 58 Network Camera User Manual Add user: 1. Click the “Add” button to pop up the following textbox. 2. Enter user name in “User Name” textbox. 3. Enter letters or numbers in “Password” and “Confirm Password” textbox. 4. Choose the user type. Administrator has all permissions. Normal user can only view the live video.

  • Page 59: Online User

    Network Camera User Manual 3. Enter the old password of the user in the “Old Password” text box. 4. Enter the new password in the “New password” and “Confirm Password” text box. 5. Enter computer’s MAC address as necessary. 6. Click the “OK” button to save the settings. Note: To change the access level of a user, the user must be deleted and added again with the new access level.

  • Page 60: Security Management

    Network Camera User Manual Check the “Enable address filtering” check box. Select “Block/Allow the following address”, IPv4/IPv6/MAC and then enter IP address or MAC address in the address box and click the “Add” button. 4.7.4 Security Management Go to ConfigSecuritySecurity Management as shown below. In order to prevent against malicious password unlocking, “locking once illegal login”...

  • Page 61: Reboot

    Network Camera User Manual  Import & Export Settings Configuration settings of the camera can be exported form a camera into another camera. 1. Click “Browse” to select the save path for import or export information on the PC. 2. Click the “Import Setting” or “Export Setting” button. ...

  • Page 62: Operation Log

    Network Camera User Manual 1. Click the “Browse” button to select the save path of the upgrade file 2. Click the “Upgrade” button to start upgrading the firmware. 3. The device will restart automatically Caution! Do not close the browser or disconnect the camera from the network during the upgrade.

  • Page 63: Search

    Network Camera User Manual 5 Search 5.1 Image Search Click Search to go to the interface as shown below. Images that are saved on the SD card can be found here.  Local Image Search Choose “Picture”—“Local”. Set time: Select date and choose the start and end time. Click to search the images.
  • Page 64 Network Camera User Manual Click to return to the previous interface.  SD Card Image Search Choose “Picture”—“SD Card”. Set time: Select date and choose the start and end time. Choose the alarm events at the bottom of the interface. Click to search the images.

  • Page 65: Video Search

    Network Camera User Manual Icon Description Icon Description Close: Select an image and click Close all: Click this button to this button to close the image. close all images. Save: Click this button to select Save all: Click this button to the path for saving the image on select the path for saving all the PC.

  • Page 66: Sd Card Video Search

    Network Camera User Manual Icon Description Icon Description Play button. After pausing the video, click this button Pause button to continue playing. Stop button Speed down Speed up Watermark display Enable / disable audio; drag the slider to adjust the volume after enabling audio.
  • Page 67 Network Camera User Manual Select the alarm events at the bottom of the interface. Select mix stream (video and audio stream) or video stream as needed. Double click on a file name in the list to start playback. The time table can be shown in 24H/12H/2H/1H format by clicking the corresponding buttons.
  • Page 68 Network Camera User Manual Click “Set up” to set the storage directory of the video files. Click “Open” to play the video. Click “Clear List” to clear the downloading list. Click “Close” to close the downloading window.

  • Page 69: Appendix

    Network Camera User Manual Appendix Appendix 1 Troubleshooting How to find the password? A：Reset the device to the default factory settings. Default IP: 192.168.226.201; User name: admin; Password: 123456 Fail to connect devices through IE browser. A: Network is not well connected. Check the connection and make sure it is connected well. B: IP address is not available.
  • Page 70 Network Camera User Manual No sound can be heard. A：Audio input device is not connected. Please connect and try again. B: Audio function is not enabled at the corresponding channel. Please enable this function.

  • Page 71: Appendix 2 Specifications

    Network Camera User Manual Appendix 2 Specifications Specification /Model Face Detection Bullet AI Network Camera Image Sensor 1/2.8＂CMOS Image Size 1920× 1080 Electronic Shutter 1/25s~1/100000s Iris Type Fixed Iris Min. llumination 0 lux 8mm@F1.6, horizontal FoV: 40.6° , recommended face capturing distance: 3m Camera Lens 12mm@F2.0, horizontal FoV: 26.6°...
  • Page 72 Network Camera User Manual Specification /Model Face Detection Bullet AI Network Camera Image Sensor 1/2.8＂CMOS Image Size 1920× 1080 Electronic Shutter 1/25s~1/100000s Iris Type Fixed Iris Min. llumination 0 lux Camera Lens 7~22mm@F1.4, horizontal FoV:37° ~22.5° , recommended face capturing distance: 5~15m Lens Mount Ø14 Day&Night...
  • Page 73 Network Camera User Manual Specification /Model Face Detection Dome AI Network Camera Image Sensor 1/2.8＂CMOS Image Size 1920× 1080 Electronic Shutter 1/25s~1/100000s Iris Type Fixed Iris Min. llumination 0 lux 8mm@F1.6, horizontal FoV: 40.6° , recommended face capturing distance: 3m Camera Lens 12mm@F2.0, horizontal FoV: 26.6°...
  • Page 74 Network Camera User Manual Specification /Model Face Detection Dome AI Network Camera Image Sensor 1/2.8＂CMOS Image Size 1920× 1080 Electronic Shutter 1/25s~1/100000s Iris Type Fixed Iris Min. llumination 0 lux 8mm@F1.6, horizontal FoV: 40.6° , recommended face capturing distance: 3m Camera Lens 12mm@F2.0, horizontal FoV: 26.6°...
  • Page 75 Network Camera User Manual Specification /Model Face Detection Dome AI Network Camera Image Sensor 1/2.8＂CMOS Image Size 1920× 1080 Electronic Shutter 1/25s~1/100000s Iris Type Fixed Iris Min. llumination 0 lux Camera Lens 7~22mm@F1.4, horizontal FoV:37° ~22.5° , recommended face capturing distance: 5~15m Lens Mount Ø14 Day&Night...
  • Page 76 Network Camera User Manual Specification /Model Face Detection Dome AI Network Camera Image Sensor 1/2.8＂CMOS Image Size 1920× 1080 Electronic Shutter 1/25s~1/100000s Iris Type Fixed Iris Min. llumination 0 lux Camera Lens 2.8-12mm, recommended face capturing distance: 1.5~7m Ø14 Lens Mount Day&Night Digital WDR Digital NR...
