  • Page 1 User Manual of Network Camera Network Camera User Manual UD14457N...
  • Page 2 Network Camera User Manual User Manual About this Manual This Manual is applicable to Network Camera. The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
  • Page 3 Network Camera User Manual SECURITY RISKS; HOWEVER, OUR COMPANY WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED. SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW.
  • Page 4 Network Camera User Manual  Please adopt the power adapter which can meet the safety extra low voltage (SELV) standard. And source with 12 VDC or 24 VAC (depending on models) according to the IEC60950-1 and Limited Power Source standard. ...
  • Page 5 Network Camera User Manual expose it to high electromagnetic radiation.  To avoid heat accumulation, ensure there is good ventilation to the device.  Keep the camera away from water and any liquids.  While shipping, pack the camera in its original, or equivalent, packing materials. Or packing the same texture.

  • Page 6: Table Of Contents

    Network Camera User Manual Table of Contents Chapter 1 System Requirement ................9 Chapter 2 Network Connection ................10 Setting the Network Camera over the LAN ............10 2.1.1 Wiring over the LAN......................10 2.1.2 Activating the Camera ....................11 2.1.3 (Optional) Setting Security Question ................
  • Page 7 Network Camera User Manual 6.2.3 Configuring RS232 Settings ..................... 48 6.2.4 Configuring RS485 Settings ..................... 49 6.2.5 Configuring DST Settings ....................50 6.2.6 Configuring External Devices ..................51 6.2.7 Configuring VCA Resource ....................52 6.2.8 Configuring Metadata Settings ..................52 6.2.9 Open Source Software License ..................
  • Page 8 Network Camera User Manual 7.2.11 Network Service ......................90 7.2.12 Smooth Streaming ......................91 Chapter 8 Video/Audio Settings ................. 93 Configuring Video Settings ................93 8.1.1 Video Settings ......................... 93 8.1.2 Custom Video........................96 Configuring Audio Settings ................98 Configuring ROI Encoding ................98 Display Info.
  • Page 9 Network Camera User Manual 10.2.10 Configuring Object Removal Detection ..............143 10.3 VCA Configuration ..................145 10.3.1 Behavior Analysis ......................145 10.3.2 Face Capture ......................... 152 10.3.3 People Counting ......................156 10.3.4 Counting ........................160 10.3.5 Heat Map ........................161 10.3.6 Road Traffic ........................

  • Page 10: Chapter 1 System Requirement

    Network Camera User Manual Chapter 1 System Requirement Operating System Microsoft Windows XP SP1 and above version 2.0 GHz or higher 1G or higher Display 1024×768 resolution or higher Web Browser For camera that supports plug-in free live view Internet Explorer 8 – 11, Mozilla Firefox 30.0 and above version and Google Chrome 41.0 and above version.

  • Page 11: Chapter 2 Network Connection

    Network Camera User Manual Chapter 2 Network Connection Note:  You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection. If the product does not work properly, please contact with your dealer or the nearest service center.
  • Page 12 Network Camera User Manual computer with a network cable as shown in Figure 2-1.  Refer to the Figure 2-2 to set network camera over the LAN via a switch or a router. Network Cable Network Camera Computer Connecting Directly Network Camera Computer Connecting via a Switch or a Router...
  • Page 13 Network Camera User Manual to search the IP address. Activation via Web Browser 3. Create a password and input the password into the password field. A password with user name in it is not allowed. STRONG PASSWORD RECOMMENDED–We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the...
  • Page 14 Network Camera User Manual 2. Check the device status from the device list, and select the inactive device. SADP Interface Note: The SADP software supports activating the camera in batch. Refer to the user manual of SADP software for details. 3.
  • Page 15 Network Camera User Manual failed, please make sure that the password meets the requirement and try again. 5. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Modify the IP Address 6.
  • Page 16 Network Camera User Manual 1. Run the client software and the control panel of the software pops up, as shown in the figure below. Control Panel 2. Click the Device Management icon to enter the Device Management interface, as shown in the figure below.
  • Page 17 Network Camera User Manual Device Management Interface 3. Check the device status from the device list, and select an inactive device. 4. Click the Activate button to pop up the Activation interface. 5. Create a password and input the password in the password field, and confirm the password.
  • Page 18 Network Camera User Manual Activation Interface (Client Software) 6. Click OK button to start activation. 7. Click the Modify Netinfo button to pop up the Network Parameter Modification interface, as shown in the figure below. Modifying the Network Parameters 8. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP.
  • Page 19 Network Camera User Manual Security question is used to reset the admin password when admin user forgets the password. Admin user can follow the pop-up window to complete security question settings during camera activation. Or, admin user can go to User Management interface to set up the function.
  • Page 20 Network Camera User Manual 5. Visit the network camera through a web browser or the client software over the internet. Accessing the Camera through Router with Static IP Connecting the network camera with static IP directly  You can also save the static IP in the camera and directly connect it to the internet without using a router.
  • Page 21 Network Camera User Manual with port mapping. Note: Refer to Appendix 2 for detailed information about port mapping. 5. Apply a domain name from a domain name provider. 6. Configure the DDNS settings in the setting interface of the router. 7.
  • Page 22 Network Camera User Manual Steps: 1. Apply a domain name from a domain name provider. 2. Configure the DDNS settings in the DDNS Settings interface of the network camera. Refer to Section 7.1.2 Configuring DDNS Settings for detailed configuration. 3. Visit the camera via the applied domain name.

  • Page 23: Chapter 3 Access To The Network Camera

    User Manual of Network Camera Chapter 3 Access to the Network Camera Note: For certain camera models, HTTPS is enabled by default and the camera creates an unsigned certificate automatically. When you access to the camera the first time, the web browser prompts a notification about the certificate issue.
  • Page 24 Network Camera User Manual 4. Click Login. 5. (Optional) Install the plug-in before viewing the live video and operating the camera. Follow the installation prompts to install the plug-in Note: For camera that supports plug-in free live view, if you are using Google Chrome 45 and its above version or Mozilla Firefox 52 and its above version, plug-in installation is not required.
  • Page 25 Network Camera User Manual Guarding Expert Main View...

  • Page 26: Chapter 4 Wi-Fi Settings

    Network Camera User Manual Chapter 4 Wi-Fi Settings Purpose: By connecting to the wireless network, you don’t need to use cable of any kind for network connection, which is very convenient for the actual surveillance application. Note: This chapter is only applicable for the cameras with the built-in Wi-Fi module. Purpose: Two connection modes are supported.
  • Page 27 Network Camera User Manual 3. Click to choose a wireless connection on the list. Wi-Fi Setting- Manage Mode 4. Check the radio button to select the Network mode as Manage, and the Security mode of the network is automatically shown when you select the wireless network, please don’t change it manually.
  • Page 28 Network Camera User Manual 2. Customize a SSID for the camera. 3. Choose the Security Mode of the wireless connection. 4. Enable the wireless connection function for your PC. 5. On the PC side, search the network and you can see the SSID of the camera listed.
  • Page 29 Network Camera User Manual WEP Mode Authentication - Select Open or Shared Key System Authentication, depending on  the method used by your access point. Not all access points have this option, in which case they probably use Open System, which is sometimes known as SSID Authentication.
  • Page 30 Network Camera User Manual Choose the type of client/server authentication being used by the access point; EAP-TLS or EAP-PEAP. EAP-TLS EAP-TLS Identity - Enter the user ID to present to the network.  Private key password – Enter the password for your user ID. ...
  • Page 31 Network Camera User Manual strongly recommend the use of strong passwords for all functions and network devices. The password should be something of your own choosing (using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers and special characters) in order to increase the security of your product.
  • Page 32 Network Camera User Manual PBC Mode: PBC refers to the Push-Button-Configuration, in which the user simply has to push a button, either an actual or virtual one (as the button on the configuration interface of the IE browser), on both the Access Point (and a registrar of the network) and the new wireless client device.
  • Page 33 Network Camera User Manual Use PIN Code If the PIN code is generated from the router side, you should enter the PIN code you get from the router side in the Router PIN code field. 3. Click Connect. You can generate the PIN code on the camera side. And the expired time for the PIN code is 120 seconds.
  • Page 34 Network Camera User Manual Setting WLAN Parameters 3. Customize the IPv4 address, the IPv4 Subnet Mask and the Default Gateway. The setting procedure is the same with that of LAN. If you want to be assigned the IP address you can check the checkbox to enable the DHCP.

  • Page 35: Chapter 5 Live View

    User Manual of Network Camera Chapter 5 Live View Purpose: The live view page allows you to view the real-time video, capture images, realize PTZ control, set/call presets and configure video parameters. Log in the network camera to enter the live view page, or you can click Live View on the menu bar of the main page to enter the live view page.
  • Page 36 Network Camera User Manual For IE (Internet Explorer) users, plug-ins as webcomponents and quick time are selectable. And for Non-IE users, webcomponents, quick time, VLC or MJPEG is selectable if they are supported by the web browser. Note: For camera that supports plug-in free live view, when Google Chrome 45 and its above version or Mozilla Firefox 52 and its above version are used, plug-in installation is not required.
  • Page 37 Network Camera User Manual Icon Description Live view with the different video streams. Supported video streams vary according to camera models. etc. For the camera models that support 10 streams, go to Video/Audio > Custom to add the streams. Click to select the third-party plug-in. Manually capture the picture.

  • Page 38: Install Plug-In

    Network Camera User Manual Operation Web Browser Operation System  Internet Explorer 8+  Google Chrome 57 and earlier Follow pop-up prompts version complete plug-in installation.  Mozilla Firefox 52 and earlier Windows version  Google Chrome 57+ Click to download ...
  • Page 39 Network Camera User Manual It allows quick setup of image/video related parameters on live view page. Steps: 1. Click button on the right of the live view window to show the PTZ control panel. Click to hide it. 2. Specify PTZ, Display, OSD and Video/Audio and VCA resource parameters. For more settings, go to Configuration >...

  • Page 40: Ptz Control Panel

    Network Camera User Manual Note: VCA Resource function varies according to different camera models.  VCA options are mutually exclusive.  The function may not be supported by some camera models.  Purpose: In the live view interface, you can use the PTZ control buttons to realize pan/tilt/zoom control of the camera.
  • Page 41 Network Camera User Manual  For the cameras which support lens movements only, the direction buttons are invalid. Table 5-2 Descriptions of PTZ Control Panel Icon Description Zoom in/out Focus near/far Iris +/- PTZ speed adjustment Light on/off Wiper on/off Auxiliary focus Initialize lens Adjust speed of pan/tilt movements...

  • Page 42: Setting/Calling A Preset

    Network Camera User Manual • Zoom in or out. • Refocus the lens. 5. Click to finish the setting of the current preset. 6. You can click to delete the preset.  Calling a Preset: This feature enables the camera to point to a specified preset scene manually or when an event takes place.
  • Page 43 Network Camera User Manual Figure 5-6 Add Patrol Path 6. Click OK to save a patrol. 7. Click to start the patrol, and click to stop it. 8. (Optional) Click to delete a patrol. It allows quick setup of image/video related parameters on live view page. Steps: 1.
  • Page 44 Network Camera User Manual HLC: High Light Compensation makes the camera identify and suppress  the strong light sources that usually flare across a scene. This makes it possible to see the detail of the image that would normally be hidden. ...

  • Page 45: Chapter 6 Network Camera Configuration

    User Manual of Network Camera Chapter 6 Network Camera Configuration Purpose: The local configuration refers to the parameters of the live view, record files and captured pictures. The record files and captured pictures are the ones you record and capture using the web browser and thus the saving paths of them are on the PC running the browser.
  • Page 46 Network Camera User Manual  Display POS Information: Enable the function, feature information of the detected target is dynamically displayed near the target in the live image. The feature information of different functions is different. For example, ID and waiting time for Queue Management, height for People Counting, etc. Note: Display POS Information is only available for certain camera models.
  • Page 47 Network Camera User Manual 3. Click Save to save the settings. Purpose: Follow the instructions below to configure the system settings, include System Settings, Maintenance, Security, and User Management, etc. Enter the Device Information interface: Configuration > System > System Settings > Basic Information.
  • Page 48 Network Camera User Manual Time Settings 2. Select the Time Zone of your location from the drop-down menu. 3. Configure the NTP settings. (1) Click to enable the NTP function. (2) Configure the following settings: Server Address: IP address of NTP server. NTP Port: Port of NTP server.
  • Page 49 Network Camera User Manual Note: If the camera is connected to a public network, you should use a NTP server that has a time synchronization function, such as the server at the National Time Center (IP Address: 210.72.145.44). If the camera is set in a customized network, NTP software can be used to establish a NTP server for time synchronization.
  • Page 50 Network Camera User Manual Steps: 1. Enter RS232 Port Setting interface: Configuration> System > System Settings > RS232. 2. Configure the Baud Rate, Data Bit, Stop Bit, Parity, Flow Control, and Usage. RS232 Settings Note: If you want to connect the camera by the RS232 port, the parameters of the RS232 should be exactly the same with the parameters you configured here.
  • Page 51 Network Camera User Manual RS-485 Settings 2. Set the RS485 parameters and click Save to save the settings. By default, the Baud Rate is set as 9600 bps, the Data Bit is 8, the stop bit is 1 and the Parity and Flow Control is None. Note: The Baud Rate, PTZ Protocol and PTZ Address parameters should be exactly the same as the PTZ camera parameters.
  • Page 52 Network Camera User Manual DST Settings 2. Select the start time and the end time. 3. Select the DST Bias. 4. Click Save to activate the settings. Purpose: For the device supported external devices, including the wiper on the housing or the LED light, you can control them via the Web browser.
  • Page 53 Network Camera User Manual the Start Time and End Time. Set Schedule  Auto: The LED will be turned on according to the environment illumination. 5. Click Save to save the settings. Purpose: VCA resource offers you options to enable certain VCA functions according to actual need when several VCA functions are available.
  • Page 54 Network Camera User Manual detection, unattended baggage detection, object removal, queue management and face capture can be uploaded. If enabled, the metadata of the corresponding event are available for users to explore the possibility of various data usage. Steps: 1. Enter Metadata settings interface: Configuration >...

  • Page 55: Upgrade & Maintenance

    Network Camera User Manual upgrade the device. Enter the Maintenance interface: Configuration > System > Maintenance > Upgrade & Maintenance  Reboot: Restart the device.  Restore: Reset all the parameters, except the IP parameters and user information, to the default settings. ...
  • Page 56 Network Camera User Manual required. 2. Click Browse to select the local upgrade file and then click Upgrade to start remote upgrade. Note: The upgrading process will take 1 to 10 minutes. Please don't disconnect power of the camera during the process, and the camera reboots automatically after upgrade.

  • Page 57: System Service

    Network Camera User Manual Log Searching 4. To export the log files, click Export to save the log files. Purpose: System service settings refer to the software and hardware service the camera supports. Supported functions vary according to the different cameras. For the cameras support IR LED, ABF (Auto Back Focus), Auto Defog, or Status LED, you can select to enable or disable the corresponding service according to the actual demands.

  • Page 58: Security Audit Log

    Network Camera User Manual Purpose: The security audit logs refer to the security operation logs. You can search and analyze the security log files of the camera so that to find out the illegal intrusion and troubleshooting the security events. Security audit logs can be saved on device flash. The log will be saved every half hour after device booting.
  • Page 59 Network Camera User Manual Log Searching 4. To export the log files, click Export to save the log files.  Setting Log Server Steps: 1. Check Enable Log Upload Server. 2. Input Log Server IP and Log Server Port. 3. Click Test to test settings. 4.

  • Page 60: Authentication

    Network Camera User Manual Purpose: You can specifically secure the stream data of live view. Steps: 1. Enter the Authentication interface: Configuration > System > Security > Authentication. Authentication 2. Set up authentication method for RTSP authentication and WEB authentication. Caution: Digest is the recommended authentication method for better data security.
  • Page 61 Network Camera User Manual IP Address Filter Interface 2. Check the checkbox of Enable IP Address Filter. 3. Select the type of IP Address Filter in the drop-down list, Forbidden and Allowed are selectable. 4. Set the IP Address Filter list. Add an IP Address ...

  • Page 62: Security Service

    Network Camera User Manual 5. Click Save to save the settings. To enable the remote login, and improve the data communication security, the camera provides the security service for better user experience. Steps: 1. Enter the security service configuration interface: Configuration > System > Security >...

  • Page 63: User Management

    Network Camera User Manual you make no operation to the device via web browser (Viewing live image and playback are not included.) for the set timeout period. Algorithm  Displays the currently active digest algorithm. If Security Reinforce is enabled, MD5 is disabled and SHA256 is enabled instead.
  • Page 64 Network Camera User Manual Notes: ● Up to 31 user accounts can be created. ● Users of different levels own different default permissions. Operator and user are selectable. STRONG PASSWORD RECOMMENDED–We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.

  • Page 65: User Management

    Network Camera User Manual 2. Click OK on the pop-up dialogue box to confirm the deletion. Setting Simultaneous Login  Steps: 1. Click General. 2. Slide the slide bar to set the simultaneous login. If the number of the illegal login attempts exceeds the set threshold, your access will be denied.
  • Page 66 Network Camera User Manual Before you start: The PC used to reset password and the camera should belong to the same IP address segment of the same LAN. Steps: 1. Enter login interface via web browser. 2. Click Forget Password. 3.

  • Page 67: Online Users

    Network Camera User Manual Note: User IP address is locked for 30 minutes after 7 failed attempts of answering security questions. Purpose: You can see the current users who are visiting the device through this interface. User information, such as user name, level, IP address, and operation time, is displayed in the User List.

  • Page 68: Chapter 7 Network Settings

    User Manual of Network Camera Chapter 7 Network Settings Purpose: Follow the instructions in this chapter to configure the basic settings and advanced settings. Purpose: You can configure the parameters, including TCP/IP, DDNS, PPPoE, Port, and NAT, etc., by following the instructions in this section. Purpose: TCP/IP settings must be properly configured before you operate the camera over network.
  • Page 69 Network Camera User Manual TCP/IP Settings 2. Configure the basic network settings, including the NIC Type, IPv4 or IPv6 Address, IPv4 or IPv6 Subnet Mask, IPv4 or IPv6 Default Gateway, MTU settings and Multicast Address. 3. (Optional) Check the checkbox of Enable Multicast Discovery, and then the online network camera can be automatically detected by client software via private multicast protocol in the LAN.
  • Page 70 Network Camera User Manual multicast group address. Before utilizing this function, you have to enable the Multicast function of your router.  A reboot is required for the settings to take effect. Purpose: If your camera is set to use PPPoE as its default network connection, you can use the Dynamic DNS (DDNS) for network access.
  • Page 71 Network Camera User Manual Figure 7-2 DynDNS Settings NO-IP:  Steps: (1) Choose the DDNS Type as NO-IP. Figure 7-3 NO-IP DNS Settings (2) Enter the Server Address as www.noip.com (3) Enter the Domain name you registered. (4) Enter the User Name and Password. (5) Click Save and then you can view the camera with the domain name.
  • Page 72 Network Camera User Manual Steps: Enter the PPPoE Settings interface: Configuration > Network > Basic Settings > PPPoE PPPoE Settings 2. Check the Enable PPPoE checkbox to enable this feature. 3. Enter User Name, Password, and Confirm password for PPPoE access. Note: The User Name and Password should be assigned by your ISP.
  • Page 73 Network Camera User Manual You can set the port No. of the camera, e.g., HTTP port, RTSP port and HTTPS port. Steps: 1. Enter the Port Settings interface, Configuration > Network > Basic Settings > Port Port Settings 2. Set the ports of the camera. HTTP Port: The default port number is 80, and it can be changed to any port No.
  • Page 74 Network Camera User Manual Note: WebSocket and WebSockets protocol are used for plug-in free live view. For detailed information, see 7.2.11 Network Service. 3. Click Save to save the settings. Note: A reboot is required for the settings to take effect. Purpose: NAT interface allows you to configure the UPnP™...
  • Page 75 Network Camera User Manual 3. Choose a friendly name for the camera, or you can use the default name. 4. Select the port mapping mode. Manual and Auto are selectable. Note: If you select Auto, you should enable UPnP™ function on the router. If you select Manual, you can customize the value of the external port and complete port mapping settings on router manually.
  • Page 76 Network Camera User Manual IP Address stands for the address of multicast. • Video port and audio port of each video stream of each camera channel can be • specified by selecting a stream in Video Stream and inputting port number in Video Port and Audio Port.
  • Page 77 Network Camera User Manual minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers and special characters) in order to increase the security of your product. Proper configuration of all passwords and other security settings is the ...
  • Page 78 Network Camera User Manual SNMP Settings 2. Check the checkbox of Enable SNMPv1, Enable SNMP v2c, Enable SNMPv3 to enable the feature correspondingly. 3. Configure the SNMP settings. Note: The settings of the SNMP software should be the same as the settings you...
  • Page 79 Network Camera User Manual configure here. 4. Click Save to save and finish the settings. Notes: A reboot is required for the settings to take effect. • To lower the risk of information leakage, you are suggested to enable SNMP v3 •...
  • Page 80 Network Camera User Manual 3. Input the server address and port. 4. Configure the FTP/SFTP settings; and the user name and password are required for the FTP server login. For your privacy and to better protect your system against security risks, we ...
  • Page 81 Network Camera User Manual Anonymous Access to the FTP Server (in which case the user name and password won’t be required.): Check the Anonymous checkbox to enable the anonymous access to the FTP server. Note: The anonymous access function must be supported by the FTP server. 7.
  • Page 82 Network Camera User Manual Email Encryption: None, SSL, and TLS are selectable. When you select SSL or TLS and disable STARTTLS, e-mails will be sent after encrypted by SSL or TLS. The SMTP port should be set as 465 for this encryption method. When you select SSL or TLS and enable STARTTLS, emails will be sent after encrypted by STARTTLS, and the SMTP port should be set as 25.

  • Page 83: Platform Access

    Network Camera User Manual Email Settings 4. Click Save to save the settings. Purpose: Platform access provides you an option to manage the devices via platform. Steps: 1. Enter the Platform Access settings interface: Configuration > Network > Advanced Settings > Platform Access 2.

  • Page 84: Wireless Dial

    Network Camera User Manual If you select Platform Access Mode as Guarding Vision, 1) Click and read "Terms of Service" and "Privacy Policy" in pop-up window. 2) Create a verification code or change the verification code for the camera. Note: The verification code is required when you add the camera to Guarding •...
  • Page 85 Network Camera User Manual selected, you can set the offline time and manual dialing parameters. 2) Set the access number, user name, password, APN, MTU and verification protocol. You can also leave these parameters blank, and the device will adopt the default settings for dialing after other parameters are configured. 3) Select the network mode from the drop-down list.

  • Page 86: Network Service

    Network Camera User Manual Purpose: HTTPS provides authentication of the web site and its associated web server, which protects against Man-in-the-middle attacks. Note:  For the camera that supports plug-in free live view, when you use HTTPS to visit the camera, you should enable Websockets for live view. Go to Configuration > Network >...
  • Page 87 Network Camera User Manual Create Self-signed Certificate Create the self-signed certificate  (1) Select Create Self-signed Certificate as the Installation Method. (2) Click Create button to enter the creation interface. (3) Enter the country, host name/IP, validity and other information. (4) Click OK to save the settings.
  • Page 88 Network Camera User Manual Import the Certificate (2) 5. There will be the certificate information after your successfully creating and installing the certificate. Installed Certificate 6. Export and save the certificate for verification when adding the device to client software. Note: The exported certificate should be saved in the certificate folder of your client software before adding the device to your PC client.
  • Page 89 Network Camera User Manual Settings > QoS QoS Settings 2. Configure the QoS settings, including Video/Audio DSCP, Event/Alarm DSCP and Management DSCP. The valid value range of the DSCP is 0 to 63. The bigger the DSCP value is, the higher the priority is.
  • Page 90 Network Camera User Manual minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers and special characters) in order to increase the security of your product. Proper configuration of all passwords and other security settings is the ...
  • Page 91 Network Camera User Manual rules. 1. Check the Enable ONVIF checkbox to enable the function. 2. Add ONVIF users. Up to 32 users are allowed. Set the user name and password, and confirm the password. You can set the user as media user, operator, and administrator.

  • Page 92: Smooth Streaming

    Network Camera User Manual SDK Service and Enhanced SDK Service If you want to add the device to the client software, you should enable SDK Service or Enhanced SDK Service. SDK Service: SDK protocol is used. Enhanced SDK Service: SDK over TLS protocol is used. Communication between the device and the client software is secured by using TLS (Transport Layer Security) protocol.
  • Page 93 Network Camera User Manual 3. Check Enable Smooth Streaming. Note: Be sure the Bitrate Type is selected as Constant and the SVC is selected as OFF before enable this function. Go to Configuration > Video/Audio > Video page to set the parameters. 4.

  • Page 94: Chapter 8 Video/Audio Settings

    User Manual of Network Camera Chapter 8 Video/Audio Settings Purpose: Follow the instructions below to configure the video setting, audio settings, ROI, Display info. on Stream, etc. For certain camera models, you can configure parameters for available video streams, for example, the main stream, the sub-stream, etc. And you can also customize additional video streams for further needs.
  • Page 95 Network Camera User Manual 2. Select the Stream Type. Supported stream types are listed in the drop-down list. Notes: For some models, the Third Stream is not enabled by default. Go to System > • Maintenance > System Service> Software to enable the function is required. The main stream is usually for recording and live view with good bandwidth, •...
  • Page 96 Network Camera User Manual MJPEG, and MPEG4. Supported encoding type for different stream types may differ. H.265 is a new encoding technology. Compared with H.264, it reduces the transmission bitrate under the same resolution, frame rate and image quality. Note: Selectable video encoding types may vary according to different camera modes.
  • Page 97 Network Camera User Manual bitrate in the long term. The camera needs at least 24 hours to adapt to a fixed monitoring scene. Max. Average Bitrate: When you set a maximum bitrate, its corresponding recommended maximum average bitrate will be shown in the Max. Average Bitrate box. You can also set the maximum average bitrate manually from 32 Kbps to the value of the set maximum bitrate.

  • Page 98: Custom Video

    Network Camera User Manual can live view them, but cannot record or playback them. Notes: Custom video function requires the support of the camera. • After a camera restore action (not restore to default setting), quantity of custom • video streams and their names are kept, but the related parameters are restored. Custom Video Settings Steps: 1.
  • Page 99 Network Camera User Manual Steps: 1. Enter the Audio Settings interface: Configuration > Video/Audio > Audio. Audio Settings 2. Configure the following settings. Note: Audio settings vary according to different camera models. Audio Encoding: G.722.1, G.711 ulaw, G.711alaw, G.726, MP2L2, PCM and MP3 are selectable.
  • Page 100 Network Camera User Manual encoding resource to the region of interest, thus to increase the quality of the ROI whereas the background information is less focused. Note: ROI function varies according to different camera models. Region of Interest Settings Steps: 1.

  • Page 101: Display Info. On Stream

    Network Camera User Manual 4. Set Fixed Region for ROI. (1) Select the Region No. from the drop-down list. (2) Check the Enable checkbox to enable ROI function for the chosen region. (3) Click Drawing. Click and drag the mouse on the view screen to draw a red rectangle as the ROI region.
  • Page 102 Network Camera User Manual Purpose: You can specify a target area on the live video, and then the specified video area can be displayed via the third stream in certain resolution, providing more details of the target area if needed. Note: Target cropping function varies according to different camera models.

  • Page 103: Chapter 9 Image Settings

    User Manual of Network Camera Chapter 9 Image Settings Purpose: Follow the instructions in this chapter to configure the image parameters, including display settings, OSD settings, privacy mask, and picture overlay and image parameters switch. Purpose: Configure the image adjustment, exposure settings, day/night switch, backlight settings, white balance, image enhancement, video adjustment, and other parameters in display settings.
  • Page 104 Network Camera User Manual Display Settings 2. Select the desired scene. 3. Set the image parameters of the camera.  Image Adjustment Brightness describes bright of the image, which ranges from 1 to 100. Contrast describes the contrast of the image, which ranges from 1 to 100. Saturation describes the colorfulness of the image color, which ranges from 1 to 100.

  • Page 105: Day/Night Auto-Switch

    Network Camera User Manual and auxiliary focus manually. Semi-Auto: Camera will focus automatically when you adjust the zoom parameters.  Day/Night Switch Select the Day/Night Switch mode according to different surveillance demand. Day, Night, Auto, Scheduled-Switch, and Triggered by alarm input are selectable for day/night switch.
  • Page 106 Network Camera User Manual if the object is near the camera, the device adjusts the supplement light to lower power, and the light is in higher power if the object is far away. Backlight Settings  BLC Area: If you focus on an object against strong backlight, the object will be too dark to be seen clearly.
  • Page 107 Network Camera User Manual and the image is misty. It enhances the subtle details so that the image appears clearer. EIS (Electrical Image Stabilizer): EIS reduces the effects of vibration in a video. Grey Scale: You can choose the range of the grey scale as [0-255] or [16-235]. Video Adjustment ...
  • Page 108 Network Camera User Manual displayed on the live view. OSD Settings Steps: 1. Enter the OSD Settings interface: Configuration > Image > OSD Settings. 2. Select the desired character set. 3. Check the corresponding checkbox to select the display of camera name, date or week if required.
  • Page 109 Network Camera User Manual or all align right, you can set the left and right margins and up and down margins. 1 Character, 2 character and none are available. If you select custom, you can use the mouse to click and drag text frames in the live view window to adjust their positions.
  • Page 110 Network Camera User Manual Privacy Mask Settings 4. Click and drag the mouse in the live video window to draw the mask area. Note: You are allowed to draw up to 4/8 areas on the same image. The supported number of the areas vary with the camera model. 5.
  • Page 111 Network Camera User Manual 5. Set X Coordinate and Y Coordinate values adjust the picture position on the image. Adjust Picture Width and Picture Height to the desired size. 6. Click Save to save settings. Note: The picture must be in RGB24 bmp format and the maximum picture size is 128*128.

  • Page 112: Chapter 10 Event Settings

    User Manual of Network Camera Chapter 10 Event Settings This section explains how to configure the network camera to respond to alarm events, including basic event and smart event. You can configure the basic events by following the instructions in this section, including motion detection, video tampering, alarm input, alarm output, and exception, etc.
  • Page 113 Network Camera User Manual 3. Check the checkbox of Enable Dynamic Analysis for Motion if you want to mark the detected objects with green rectangles. Note: Select Disable for rules if you don’t want the detected objected displayed with the green rectangles. Select disable rules from Configuration > Local Configuration >...
  • Page 114 Network Camera User Manual Task 2: Set the Arming Schedule for Motion Detection Arming Schedule Steps: 1. Click Arming Schedule to edit the arming schedule. 2. Click on the time bar and drag the mouse to select the time period. Arming Schedule Note: Click on the selected time period, you can adjust the time period to the...
  • Page 115 Network Camera User Manual 4. Move the mouse to the end of each day, a copy dialogue box pops up, and you can copy the current settings to other days. 5. Click Save to save the settings. Note: The time of each period can’t be overlapped. Up to 8 periods can be configured for each day.

  • Page 116: Configuring Alarm Output

    Network Camera User Manual  Upload to FTP/Memory Card/NAS Capture the image when an alarm is triggered and upload the picture to a FTP server. Notes: ● Set the FTP address and the remote FTP server first. Refer to Section 7.2.2 Configuring FTP Settings for detailed information.
  • Page 117 Network Camera User Manual Expert Mode of Motion Detection  Day/Night Switch OFF Steps: 1. Draw the detection area as in the normal configuration mode. Up to 8 areas are supported. 2. Select OFF for Switch Day and Night Settings. 3.
  • Page 118 Network Camera User Manual 6. Set the arming schedule and linkage method as in the normal configuration mode. 7. Click Save to save the settings.  Day/Night Scheduled-Switch Steps: 1. Draw the detection area as in the normal configuration mode. Up to 8 areas are supported.
  • Page 119 Network Camera User Manual 2. Check Enable Video Tampering checkbox to enable the video tampering detection. 3. Click Edit to edit the arming schedule for video tampering. The arming schedule configuration is the same as the setting of the arming schedule for motion detection.
  • Page 120 Network Camera User Manual Alarm Input Settings 3. Click Arming Schedule to set the arming schedule for the alarm input. Refer to Task 2: Set the Arming Schedule for Motion Detection in Section 10.1.1. 4. Click Linkage Method and check the checkbox to select the linkage method taken for the alarm input.
  • Page 121 Network Camera User Manual Alarm Output Settings Steps: 1. Enter the Alarm Output Settings interface: Configuration> Event > Basic Event > Alarm Output. 2. Select one alarm output channel in the Alarm Output drop-down list. You can also set a name for the alarm output (optional). 3.
  • Page 122 Network Camera User Manual 6. Click Save to save the settings. The exception type can be HDD full, HDD error, network disconnected, IP address conflicted and illegal login to the cameras. Steps: 1. Enter the Exception Settings interface: Configuration > Event > Basic Event > Exception.
  • Page 123 Network Camera User Manual Flashing Alarm Light Output Settings Steps: 1. Enter the Flashing Alarm Light Output settings interface: Configuration > Event > Basic Event > Flashing Alarm Light Output.  Flashing Duration: The time period the flashing lasts when one alarm happens. ...
  • Page 124 Network Camera User Manual Audible Alarm Output Settings Steps: 1. Enter the Audible Alarm Output settings interface: Configuration > Event > Basic Event > Audible Alarm Output.  Alarm Sound Type: The content of audible warning.  Alarm Times: The repeating times of the warning. 2.
  • Page 125 Network Camera User Manual Note: Some certain cameras support Wireless Alarm, PIR (passive infrared sensor) Alarm or Emergency Alarm.  Wireless Alarm Purpose: When wireless alarm signal is sent to the camera from the detector, such as the wireless door contact, the wireless alarm is triggered and a series of response actions can be taken.
  • Page 126 Network Camera User Manual wireless alarm. Configuring Wireless Alarm Settings...
  • Page 127 Network Camera User Manual  PIR Alarm Purpose: A PIR (Passive Infrared) alarm is triggered when an intruder moves within the detector's field of view. The heat energy dissipated by a person, or any other warm blooded creature such as dogs, cats, etc., can be detected. Steps: 1.
  • Page 128 Network Camera User Manual Arming PIR Alarm  Emergency Alarm Purpose: You can press the Emergency button on the remote control to trigger the Emergency Alarm in case of an emergency. Note: The remote control is required for the Emergency Alarm. Go to Configuration > System>...
  • Page 129 Network Camera User Manual intrusion detection, and line crossing detection, etc. These events can trigger the linkage methods, such as Notify Surveillance Center, Send Email, Trigger Alarm Output, etc. Purpose: Audio exception detection function detects the abnormal sounds in the surveillance scene, such as the sudden increase/decrease of the sound intensity, and some certain actions can be taken when the alarm is triggered.
  • Page 130 Network Camera User Manual the sound steep rise in the surveillance scene. You can set the detection sensitivity and threshold for sound steep rise. 4. Check the checkbox of Sudden Decrease of Sound Intensity Detection to detect the sound steep drop in the surveillance scene. You can set the detection sensitivity and threshold for sound steep drop.

  • Page 131: Smart Events

    Network Camera User Manual Configuring Defocus Detection 2. Check the checkbox of Enable to enable the function. 3. Click-and-drag the slider to set the detection sensitivity. The sensitivity value ranges from 1 to 100, and the higher the value is, the more easily the defocus image can trigger the alarm.
  • Page 132 Network Camera User Manual Scene Change Detection 2. Check the checkbox of Enable to enable the function. 3. Click-and-drag the slider to set the detection sensitivity. The sensitivity value ranges from 1 to 100, and the higher the value is, the more easily the change of scene can trigger the alarm.
  • Page 133 Network Camera User Manual Enter the Face Detection settings interface, Configuration > Event > Smart Event > Face Detection. Check the Enable Face Detection checkbox to enable the function. Check the checkbox of Enable Dynamic Analysis for Face Detection, and then the detected face is marked with green rectangle on the live video.
  • Page 134 Network Camera User Manual Purpose: Intrusion detection function detects people, vehicle or other objects which enter and loiter in a pre-defined virtual region, and some certain actions can be taken when the alarm is triggered. Note: Intrusion detection function varies according to different camera models. Steps: 1.
  • Page 135 Network Camera User Manual Region: A pre-defined vertexes area on the live view image. Targets, such as, people, vehicle or other objects, who enter and loiter in the region will be detected and trigger the set alarm. 4. Set the Max. Size and Min. Size for valid targets. Targets smaller or larger than the valid target size are not able to trigger detection.
  • Page 136 Network Camera User Manual can click the Clear button to clear all pre-defined regions. 10. Click Arming Schedule to set the arming schedule. 11. Click Linkage Method to select the linkage methods for intrusion detection, including Notify Surveillance Center, Send Email, Upload to FTP/Memory Card/NAS, Trigger Channel, Trigger Alarm Output, Flashing Alarm and Audible Warning.
  • Page 137 Network Camera User Manual Line Crossing Detection 2. Check the checkbox of Enable to enable the function. 3. Select the line from the drop-down list. 4. Set the Max. Size and Min. Size for valid targets. Targets smaller or larger than the valid target size are not able to trigger detection.
  • Page 138 Network Camera User Manual human and vehicle. 7. Select the direction for line crossing detection. And you can select the directions as A<->B, A ->B, and B->A. A<->B: The object going across the plane with both directions can be detected and alarms are triggered.
  • Page 139 Network Camera User Manual Purpose: Region entrance detection function detects people, vehicle or other objects which enter a pre-defined virtual region from the outside place, and some certain actions can be taken when the alarm is triggered. Steps: 1. Enter the Region Entrance Detection settings interface, Configuration > Event > Smart Event >...
  • Page 140 Network Camera User Manual Min. Size: The minimum size of a valid target. Targets with smaller sizes would not trigger detection. 5. Set the detection area. Click on the live video to specify the four vertexes of the detection region, and right click to complete drawing. 6.
  • Page 141 Network Camera User Manual Region exiting detection function detects people, vehicle or other objects which exit from a pre-defined virtual region, and some certain actions can be taken when the alarm is triggered. Steps: 1. Enter the Region Exiting Detection settings interface, Configuration > Event > Smart Event >...
  • Page 142 Network Camera User Manual detection region, and right click to complete drawing. 6. Select the detection target. Human and vehicle are available. If the detection target is not selected, all the detected targets will be reported, including the human and vehicle. 7.
  • Page 143 Network Camera User Manual taken when the alarm is triggered. Steps: 1. Enter the Unattended Baggage Detection settings interface, Configuration > Event > Smart Event > Unattended Baggage Detection. Unattended Baggage Detection 2. Check Enable checkbox to enable the function. 3.
  • Page 144 Network Camera User Manual Min. Size: The minimum size of a valid target. Targets with smaller sizes would not trigger detection. 7. Click Stop Drawing when finish drawing. 8. Set the time threshold and detection sensitivity for unattended baggage detection. Threshold: Range [5-100s], the threshold for the time of the objects left over in the region.
  • Page 145 Network Camera User Manual Steps: 1. Enter the Object Removal Detection settings interface, Configuration > Event > Smart Event > Object Removal Detection. Object Removal Detection 2. Check Enable checkbox to enable the function. 3. Select the Region from the drop-down list for detection settings. 4.
  • Page 146 Network Camera User Manual 7. Click Stop Drawing when finish drawing. 8. Set the time threshold for object removal detection. Threshold: Range [5-100s], the threshold for the time of the objects removed from the region. If you set the value as 10, alarm is triggered after the object disappears from the region for 10s.

  • Page 147: Behavior Analysis

    Network Camera User Manual Behavior Analysis  Overlay & Capture Display information includes the display on picture and display on stream. Display VCA info. on Stream: The green frames will be displayed on the target if in a live view or playback. Display Target info.
  • Page 148 Network Camera User Manual be more accurate if the camera calibration is configured. Steps: 1. Check the checkbox of Camera Calibration to enable this function. 2. Select the calibration mode as Input Basic Data or Draw on Live View Video. Input Basic Data: Input the mounting height, viewing angle, and horizon ratio of the camera manually.
  • Page 149 Network Camera User Manual 4. You can click to delete the drawn lines. 5. Click Save to save the settings.  Shield Region The shield region allows you to set the specific region in which the behavior analysis will not function. Up to 4 shield regions are supported. Steps: 1.
  • Page 150 Network Camera User Manual Configure the Rule Filter type: Pixels and Actual Size are selectable. If Pixels is selected, draw the area of maximum size and minimum size on the live video for each rule. If Actual Size is selected, input the length and width of the maximum size and minimum size.
  • Page 151 Network Camera User Manual finish the area drawing. Note: If the live view is stopped, the detection area / line cannot be draw and the rules cannot be set. 4. Check the checkbox of the combined rule to enable the rule for behavior analysis.
  • Page 152 Network Camera User Manual Advanced Configuration Detection Sensitivity [0~4]: Refers to the sensitivity of the camera detects a target. The higher the value, the easier a target be recognized, and the higher the misinformation is. The default value of 3 is recommended. Background Update Rate [0~4]: It refers to the speed of the new scene replaces the previous scene.

  • Page 153: Face Capture

    Network Camera User Manual 1. Check the checkbox of Global Size Filter to enable the function. 2. Select the Filter Type as Actual Size or Pixel. Actual Size: Input the length and width of both the maximum size and the minimum size.
  • Page 154 Network Camera User Manual the uploaded alarm picture if the checkbox is checked. Snapshot Settings:  Target Picture Settings a. Set the target picture size. Four types are available: Custom, Head Shot, Half-Body Shot and Full-Body Shot. If you select the Custom, you can customized the width, head height and body height as required.
  • Page 155 Network Camera User Manual Draw Shield Area 2. Click Save to save the settings.  Rule Steps: 1. Check the checkbox of Rule to enable rules of face capture. 2. Click the rectangle sign to draw the minimum pupil distance. The distance of the drawn pupil will be displayed on the box below the live view.
  • Page 156 Network Camera User Manual Advanced Configuration Detection Parameters: Generation Speed [1~5]: The speed to identify a target. The higher the value, the faster the target will be recognized. Setting the value quite low, and if there was a face in the configured area from the start, this face will not be captured. It can reduce the misinformation of the faces in the wall painting or posters.
  • Page 157 Network Camera User Manual alarm. Higher value means better quality should be met to trigger capture and alarm. 2) Quick Shot: You can define quick shot threshold and max. capture interval. Quick Shot Threshold: It stands for the quality of face to trigger quick shot. Face Exposure: Check the checkbox to enable the face exposure.
  • Page 158 Network Camera User Manual and make sure it is horizontal to improve the counting accuracy. Steps ： 1. Enter the Counting Configuration interface: Configuration > People Counting. Figure 10-33 People Counting Configuration 2. Check Enable People Counting checkbox to enable the function. 3.
  • Page 159 Network Camera User Manual Don’t draw the line at the place where people may linger.  6) You can click to delete the detection line. 7) You can click to change the direction. The yellow arrow indicates the direction of entering. 4.
  • Page 160 Network Camera User Manual 1) Check Enable OSD Overlay checkbox, and the real-time number of people entered and exited is displayed on the live video. 2) You can drag the OSD text frame to adjust its position according to the actual needs.

  • Page 161: Counting

    User Manual of Network Camera Counting function helps to calculate the number of people entered or exited a certain configured area and is widely applied to the entrances or exits. Compared with the people counting function supported by iDS camera, counting function needs no camera calibration.

  • Page 162: Heat Map

    Network Camera User Manual 4. Set the detection line. An orange line, named as detection line can be set on the live video, and the object entering or exiting through the line will be detected and counted. 1) Click to draw a detection line, and an orange detection line will appear on the image.
  • Page 163 Network Camera User Manual Heat Map Configuration 2. Check Enable Heat Map checkbox to enable the function. 3. Go to Area Settings to draw detection area. Draw area by left click the end-points in the live view window, and right click to finish the area drawing. Up to 8 areas are configurable.
  • Page 164 Network Camera User Manual camera treats the cabinet (on which the good removed) as a new scene. The default value of 50 is recommended. Scene Change Level [0~100]: It refers to level of the camera responses to the dynamic environment, e.g., a swaying curtain. The camera may treat the swaying curtain as a target.
  • Page 165 Network Camera User Manual Note: Road traffic function varies according to different camera models.  Detection Configuration Steps: 1. Select the detection type from the list. Vehicle Detection and Mixed-traffic Detection are selectable. Note: Reboot the device to activate the new settings when switching the detection type of road traffic.

  • Page 166: Queue Management

    Network Camera User Manual Upload to FTP/Memory Card/NAS: Capture the image when an alarm is • triggered and upload the picture to a FTP server. And save the picture on the local SD card or connected NAS. 9. Click the Save button to activate the settings. Queue Management is a function to detect queuing-up people number and waiting time of each person.
  • Page 167 Network Camera User Manual A region is the defined area in which the detections are active. When drawing the regions, note that a valid region-entering action of a target is that his/her head and shoulder enter the region. Steps: Click Add Region. (Optional) Select a color for a region from the color drop-down list.
  • Page 168 Network Camera User Manual trigger one notification. Set regional people queuing-up settings. Check OSD to display the region name and its real-time queuing-up people number. Alarm Trigger Condition: When the people number in the region is greater than, less than, equal to or not equal to the set threshold, an alarm is triggered.

  • Page 169: Chapter 11 Storage Settings

    User Manual of Network Camera Chapter 11 Storage Settings Before you start: To configure record settings, please make sure that you have the network storage device or local storage device configured. Purpose: There are two kinds of recording for the cameras: manual recording and scheduled recording.
  • Page 170 Network Camera User Manual Record Parameters  Pre-record: The time you set to start recording before the scheduled time or the event. For example, if an alarm triggers recording at 10:00, and the pre-record time is set as 5 seconds, the camera starts to record at 9:59:55. The Pre-record time can be configured as No Pre-record, 5s, 10s, 15s, 20s, 25s, 30s or not limited.
  • Page 171 Network Camera User Manual please refer to the Task 1: Set the Motion Detection Area in the Section 10.1.1.  Record Triggered by Alarm If you select Alarm, the video will be recorded when the alarm is triggered via the external alarm input channels. Besides configuring the recording schedule, you have to set the Alarm Type and check the checkbox of Trigger Channel in the Linkage Method of Alarm Input Settings interface.
  • Page 172 Network Camera User Manual Purpose: You can configure the scheduled snapshot and event-triggered snapshot. The captured picture can be stored in the local storage or network storage. Steps: 1. Enter the Capture Settings interface: Configuration > Storage > Storage Settings > Capture. Capture Configuration 2.
  • Page 173 Network Camera User Manual 5. Go to Capture Parameters tab to configure the capture parameters. (1) Check the Enable Timing Snapshot checkbox to enable continuous snapshot. (2) Select the picture format, resolution, quality and capture interval. (3) Check the Enable Event-triggered Snapshot checkbox to enable event-triggered snapshot.
  • Page 174 Network Camera User Manual The network disk should be available within the network and properly configured to store the recorded files, log files, pictures, etc. Steps: 1. Add Net HDD. (1) Enter the Net HDD settings interface, Configuration > Storage > Storage Management >...
  • Page 175 Network Camera User Manual (1) Enter the HDD Settings interface, Configuration > Storage > Storage Management > HDD Management, in which you can view the capacity, free space, status, type and property of the disk. Storage Management Interface (2) If the status of the disk is Uninitialized, check the corresponding checkbox to select the disk and click Format to start initializing the disk.
  • Page 176 Network Camera User Manual Quota Settings Note: Up to 8 NAS disks can be connected to the camera. Purpose: With memory card detection, you can view the memory card status, lock your memory card, and receive notification when your memory card is detected abnormal. Note: Memory card detection function is only supported by certain types of memory cards and camera models.

  • Page 177: Memory Card Detection

    Network Camera User Manual Memory Card Detection 2. View the memory card status on Status Detection tab. Remaining Lifespan: It shows the percentage of the remaining lifespan. The lifespan of a memory card may be influenced by factors such as its capacity and the bitrate.
  • Page 178 Network Camera User Manual (2) Input the password. (3) Click Save to save the settings.  Unlock (1) If you use the memory card on the camera that locks it, unlocking will be done automatically and no unlocking procedures are required on the part of users.
  • Page 179 Network Camera User Manual Notes:  Lite storage function varies according to different camera models.  The video files recorded in lite storage mode will be played back in full frame rate (25fps/30fps), and thus the playback process is speeded up to the eye. 1.

  • Page 180: Chapter 12 Playback

    User Manual of Network Camera Chapter 12 Playback Purpose: This section explains how to view the remotely recorded video files stored in the network disks or memory cards. Steps: 1. Click Playback on the menu bar to enter playback interface. Playback Interface 2.
  • Page 181 Network Camera User Manual The toolbar on the bottom of Playback interface can be used to control playing process. Playback Toolbar Table 12-1 Description of the buttons Button Operation Button Operation Play Capture a picture Start/Stop clipping video Pause files Audio on and adjust Stop volume/Mute...

  • Page 182: Chapter 13 Picture

    User Manual of Network Camera Chapter 13 Picture Click Picture to enter the picture searching interface. You can search, view, and download the pictures stored in the local storage or network storage. Notes: Make sure HDD, NAS or memory card are properly configured before you ...

  • Page 183: Application

    User Manual of Network Camera Chapter 14 Application Click Application to enter the statistics counting interface. You can search, view, and download the counting data stored in the local storage or network storage. Note: Application function varies according to the different camera models. After you enable the face capture function, you can view and download the captured face data from application tab.
  • Page 184 Network Camera User Manual counting data from application tab. To get more intuitional results, you can display the data in different charts. Steps: 1. Select the report type. Daily report, weekly report, monthly report, and annual report are selectable. Note: Daily report calculates the data on the date you selected;...
  • Page 185 Network Camera User Manual Note: Daily report calculates the data on the date you selected; weekly report calculates for the week your selected date belongs to; monthly report calculates for the month your selected date belongs to; and the annual report calculates for the year your selected date belongs to.
  • Page 186 Network Camera User Manual different charts. Steps: 1. Select the report type. Daily report, weekly report, monthly report, and annual report are selectable. Note: Daily report calculates the data on the date you selected; weekly report calculates for the week your selected date belongs to; monthly report calculates for the month your selected date belongs to;...

  • Page 187: Queuing-Up Time Analysis

    Network Camera User Manual To compare the time and duration that a queue stays a certain length in multiple • queues/regions, use queue status analysis, check target regions and set a queue length level. To compare the time and duration that a queue stays at different length in multiple •...

  • Page 188: Queue Status Analysis

    Network Camera User Manual 2. Select Report Type. Daily report, weekly report, monthly report and custom are supported. 3. Select Statistics Time. 4. Click Counting to generate report. 5. (Optional) Click Export in the upper right corner to export the data in desired format (.txt and xls.

  • Page 189: Raw Data

    Network Camera User Manual 3. Select Statistics Time. 4. Click Counting to generate the report. 5. (Optional) Click Export in the upper right corner to export the data in desired format (.txt and xls. are selectable.). Storage of Raw Data Raw data of queue management is saved in local storage of the device.

  • Page 190: Open Platform

    Network Camera User Manual Open Platform 4. Click Import. Then the application is installed successfully. 5. The installed applications and their related information are displayed in the list, such as the version, memory used, flash used, company, status and license. In the Operation list, you can click to export the log, click to set the...
  • Page 191 Network Camera User Manual Import License Note: Before you import the application package, make sure the following requirements are met.  The imported applications cannot have the same name.  The flash memory size of the imported application should be less than the free flash memory of the device.

  • Page 192: Appendix

    User Manual of Network Camera Appendix Appendix 1 SADP Software Introduction  Description of SADP SADP (Search Active Devices Protocol) is a kind of user-friendly and installation-free online device search tool. It searches the active online devices within your subnet and displays the information of the devices.
  • Page 193 Network Camera User Manual You can also click to refresh the online device list manually. The newly searched devices will be added to the list. You can click on each column heading to order the information; you can click to expand the device table and hide the network parameter panel on the right side, or click to show the network parameter panel.
  • Page 194 Network Camera User Manual Figure A.1.2 Modify Network Parameters...

  • Page 195: Appendix 2 Port Mapping

    Network Camera User Manual Appendix 2 Port Mapping The following settings are for TP-LINK router (TL-WR641G). The settings vary depending on different models of routers. Steps: 1. Select the WAN Connection Type, as shown below: Figure A.2.1 Select the WAN Connection Type 2.
  • Page 196 Network Camera User Manual another camera as 81, 8001, 555, 8201 with IP 192.168.1.24. Refer to the steps as below: Steps: 1. As the settings mentioned above, map the port 80, 8000, 554 and 8200 for the network camera at 192.168.1.23 2.
  • Page 197 Network Camera User Manual...

This manual is also suitable for:

Sip46b5/28-h

Table of Contents
