65 gallon billy goat™ indoor/outdoor kitchen solids interceptor

Advertisement

INSTALLATION GUIDE
SI-50
65 Gallon Billy Goat
Indoor/Outdoor Kitchen Solids Interceptor
Contents
Special Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Getting to Know the SI-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
LIFETIME GUARANTEED GREASE INTERCEPTORS
913-951-3300 | schierproducts.com
© Copyright 2023 Schier Products Company, 01/01/23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SI-50 and is the answer not in the manual?

Questions and answers

Summary of Contents for Schier SI-50

  • Page 1 Getting to Know the SI-50 ........4...
  • Page 2: Special Precautions

    SPECIAL PRECAUTIONS For Schier Solids Interceptor Installations - Failure to follow this guidance voids your warranty DO NOT AIR TEST UNIT OR RISER SYSTEM! Do not install this unit in any manner Doing so may result in property damage, personal injury or death.
  • Page 3 floodplains and areas that receive storm water. Great Basin™ models that are direct buried in high water table scenarios must be installed with an anchor kit. Model SI-50 uses model AK1 anchor kit. Corrugated Riser Pipe Requirements Riser adapter model CA2 must be used 6 - 94"...
  • Page 4 GETTING TO KNOW THE SI-50 Pickable cast iron cover (standard) 8. Outlet bulkhead connection (optional) 4" 15. Composite cover bolts FPT (x2) and washers (x4) 2. Cover gasket 9. Bulkhead connection gasket 16. Bolted composite cover (optional) 3. Safety Star®...
  • Page 5 Excavate hole at least 12" larger than interceptor on all sides and 6" deeper than tank bottom. Lay a level bed of well-packed, crushed aggregate (approximately 3/4" size rock or sand, with no fines) in the base of hole. page 5 of 9 Schier | SI-50 Installation Guide...
  • Page 6 Cap unused connections (all configurations) Screw in provided 4" cleanout plugs using pipe thread sealant or tape approved for use with plastics. Do not cap the inlet or outlet connections attached to the di users. page 6 of 9 Schier | SI-50 Installation Guide...
  • Page 7: Connect Piping

    Place unit into final position and set level. Mechanically couple inlet and outlet drainage lines to unit. Do not solvent weld. Ensure all upstream fixtures are trapped. Vent per local code. Installation of 2-way cleanout tees to grade (by others) is recommended for buried installations. page 7 of 9 Schier | SI-50 Installation Guide...
  • Page 8 Hours 8am-5pm CST, M-F Bring Covers Flush-to-Grade The SI-50 is ready for burial depth of 28-1/2" from finished grade to bottom of tank (or 10-1/2" to centerline of inlet). Deeper burials will require extending the cover adapters and possibly adding risers.
  • Page 9: Top View

    (including but not limited to tidal surge areas, floodplains and areas that receive storm water) the SI-50 must be installed with Schier model AK1 anchor kit. Model AK1 anchor kit Backfill and Finished Grade DO NOT COMPACT BACKFILL Backfill...
