CAMDEN CX-33 Quick Start Manual

The following are part of the WC-13 package:
- CX-33 Relay
- CX-MDC Door Contacts
- CM-45/4GRESE1 Illuminated Push plate switch
PUSH TO OPEN, with signage
- CM45/8GRESE1 Illuminated Push plate switch
PUSH TO LOCK, with signage
The following items are required, but NOT included:
- Door Operator
- Electric Strike
- Inside Activate wall switch
- 12 / 24V power supply
PUSH
TO OPEN
Outside
Wall Switch Wall Switch
CM-45/4GRESE1 (always unlocks
(or similar) & opens door)
Color Select
Aura
1
Red
2 G/B
Dip Switch
3 Red
Settings
4 G/B
ON
CX-33
12 - 24 V
AC/DC
Power
PUSH
TO
LOCK
PUSH
TO
OPEN
Inside Inside
Push to Lock
CM-45/8GRESE1
(or similar)
Enable
4
IDL
LOC/REM 3
RELAY 2
ACT
SPEAKER 1
ON
For Normally Locked Door, see over...
DISPLAY
0.0.7
Relay 1
MENU UP DOWN
+
12 / 24 VDC
Power
-
For Strike
N.C.
Contacts closed
when Door
is closed
CAMDEN DOOR CONTROLS
SCALE: NONE DRAWN BY: DGW
WC-13 Washroom Package Wiring Diagram (normally unlocked)
DRAWING No: DRG-CX-WC-13-7
NOTE: This Drawing should be
used in addition to each products
LED 1
respective Installation Manual.
LED 2
LED 3
Relay 2 Relay 3
Important :
Ensure wiring polarity is
consistent from Relay 3 to each
Aura´s Remote Input terminals.
Door
Operator
Magnetic
Contact
Switch
Wire MOV
MOV
(supplied)
directly to strike
DATE: 07/22/14
FILENAME:
WC-13-7 wiring diagram.vsd
(not in place of)
Fail-Safe
Electric Strike
Shown
(If Fail-Secure lock is
used, wire to
Terminals 1 & 2)
5502 Timberlea Blvd.
Mississauga, Ontario
L4W 2T7
REVISED:
Part # 40-82D003
