About this Document Objective and Target Group of this User Manual This user manual contains the information necessary for using the E-836.1G as intended. We assume that the user has basic knowledge of closed-loop systems, motion control concepts, and applicable safety measures.
Contact our customer service department (p. 23). Downloading manuals 1. Open the website www.pi.ws. 2. Search the website for the product number (e.g., E-836.1G). 3. Click the corresponding product to open the product detail page. 4. Click the Downloads tab.
Safety Intended Use The E-836.1G is a laboratory device as defined by DIN EN 61010-1. It is intended to be used in interior spaces and in an environment which is free of dirt, oil and lubricants. Corresponding to its design, the E-836.1G is intended for driving capacitive loads (e. g. piezo ceramic actuators).
Add all information from the manufacturer to the user manual, for example, supplements or technical notes. If you give the E-836.1G to a third party, include this user manual as well as other relevant information provided by the manufacturer.
Type Function Manufacturer's logo E-836 Piezo Driver Product Description CE conformity mark 3.1.2 Rear Panel Figure 2: E-836.1G piezo amplifier, rear view Labeling Function Data matrix code (example; contains the serial number) E-836.1G Product name Manufacturer's logo 113064443 Serial number (example), individual for each E-836.1G...
100 to 240 VAC and voltage frequencies of 50 or 60 Hz, with barrel connector 3763 Power cord PZ250E User manual for E-836.1G (this document) E500T0011 Technical note for the PI analog drivers for use with NI LabVIEW software E-836.1G Piezo Amplifier PZ250E...
4 Unpacking Unpacking 1. Unpack the E-836.1G with care. 2. Compare the contents with the scope of delivery according to the contract and the delivery note. 3. Inspect the contents for signs of damage. If any parts are damaged or missing, contact our customer service department immediately (p.
5 Installing Installing General Notes on Installation Install the E-836.1G near the power source so that the power plug can be quickly and easily disconnected from the mains. Only use cables and connectors that meet local safety regulations.
Alternative: Sufficiently sized power cord Connecting the power supply to the E-836.1G Connect the power supply to the E-836.1G's 24 VDC connector. Connecting the Positioner Prerequisites When a signal source is connected to the Control In BNC socket: The signal source is switched off or its output is 0 V.
− Connecting the positioner Connect the voltage connection of the positioner to the PZT -30 to 130 V LEMO socket of the E-836.1G. Connecting the Control Input Voltage INFORMATION The control signal for the output piezo voltage is the sum of the following signals: Control input voltage at the Control In BNC socket ...
If the protective earth conductor is not or not properly connected, dangerous touch voltages can occur on the E-836.1G in the event of a malfunction or failure of the system. If there are touch voltages, touching the E-836.1G can result in serious injury or death from electric shock.
The DC Offset potentiometer is turned fully counterclockwise. Switching on the E-836.1G Connect the power cord of the power supply with the power socket. The Power LED on the front panel shows the ready state of the E-836.1G: − Green: E-836.1G is ready for operation Off: E-836.1G is not ready for operation...
Page 21
6 Startup − Turn the DC Offset potentiometer. The positioner generates corresponding motion. E-836.1G Piezo Amplifier PZ250E Version: 1.1.0...
The E-836.1G contains electrostatic-sensitive devices that can be damaged by short-circuiting or flashovers when cleaning fluids penetrate the housing. Before cleaning, disconnect the E-836.1G from the power source by removing the mains plug. Prevent cleaning fluid from penetrating the housing.
Page 25
Check whether the analog drivers and the data acquisition board are working correctly. E-836.1G voltage When the internal temperature reaches ≥85° C the E-836.1G output is deactivated voltage output is deactivated and the positioner stops moving. When the internal temperature then drops to 75° C, the voltage output is switched on again automatically.
Page 27
If possible: Take photographs or make videos of your system that can be sent to our customer service department if requested. The latest versions of the user manuals are available for download on our website (p. 2). E-836.1G Piezo Amplifier PZ250E Version: 1.1.0...
5 to 50 °C Overtemperature protection Deactivation at 85 °C Deactivation at 85 °C Operating voltage 24 V DC ±10 % 24 V DC ±10 %, in the scope of delivery: External power adapter E-836.1G Piezo Amplifier PZ250E Version: 1.1.0...
Barrel 24 V connector socket 10.1.3 Ambient Conditions and Classifications The following ambient conditions and classifications for the E-836.1G must be observed: Area of application For indoor use only Maximum altitude 2000 m Air pressure 1100 hPa to 0.1 hPa...
10 Technical Data 10.2 Operating Limits The following diagram shows the operating limits for various piezo loads. The curve values are capacitance values in μF. Figure 3: Operating limits E-836.1G Piezo Amplifier PZ250E Version: 1.1.0...
10 Technical Data 10.3 Dimensions Dimensions in mm. Note that the decimal points are separated by a comma in the drawings. Figure 4: E-836.1G, dimensions in mm Version: 1.1.0 PZ250E E-836.1G Piezo Amplifier...
Dispose of your old equipment according to international, national, and local rules and regulations. To fulfill the responsibility as the product manufacturer, Physik Instrumente (PI) GmbH & Co. KG undertakes environmentally correct disposal of all old PI equipment made available on the market after 13 August 2005 without charge.
Relative humidity The following diagrams show how the individual factors influence the lifetime of the actuator. Figure 6: Dependency of the mean time between failure (MTTF) of a PICMA® actuator on the applied voltage E-836.1G Piezo Amplifier PZ250E Version: 1.1.0...
Page 38
Figure 7: Dependency of the mean time between failure (MTTF) of a PICMA® actuator on the ambient temperature Figure 8: Dependency of the mean time between failure (MTTF) of a PICMA® actuator on the relative humidity Version: 1.1.0 PZ250E E-836.1G Piezo Amplifier...
The recommended maximum range for the input voltage of the E-836.1G is therefore –2 to +12 V. This results in a piezo voltage range of – 20 to 120 V (in open-loop operation). The input voltage range can be expanded from –3 to +13 V (the piezo voltage is then in the range of -30 to +130 V), which however reduces the lifetime of the actuator.
