ASSEMBLY & INSTALLATION INSTRUCTIONS
Focal Point Fires Ltd
Christchurch, Dorset BH23 2BT
Tel: 01202 499330
Fax: 01202 499326
www.focalpointfires.co.uk
e : sales@focalpointfires.co.uk
Focal Point Fires Ltd
RBK House, Irishtown, Athlone,
Co. Westmeath, N37 XP52,
Ireland Tel: 01202 499330
Fax: 01202 499326
www.focalpointfires.co.uk
e: sales@focalpointfires.co.uk
Please note : Except where otherwise stated, all rights, including copy-
right in the text, images and layout of this booklet is owned by Focal
Point Fires Ltd. You are not permitted to copy or adapt any of the
con-tent without the prior written permission of Focal Point Fires Ltd.
MODELS COVERED BY THESE INSTRUCTIONS
F820586 FPFBQ388 NEBRASKA SURROUND WALNUT VENEER
F820587 FPFBQ389 NEBRASKA SURROUND OAK VENEER
F820628 FPFBQ410 NEBRASKA SURROUND WHITE
F820879 FPFBQ832 NEBRASKA SURROUND PINE
1
All instructions must be handed to the user for
safekeeping.
Revision D - 07/21
© 2021 Focal Point Fires Ltd.
Advertisement
Table of Contents
Related Manuals for FocalPoint F820586
Summary of Contents for FocalPoint F820586
- Page 1 ASSEMBLY & INSTALLATION INSTRUCTIONS MODELS COVERED BY THESE INSTRUCTIONS F820586 FPFBQ388 NEBRASKA SURROUND WALNUT VENEER F820587 FPFBQ389 NEBRASKA SURROUND OAK VENEER Focal Point Fires Ltd F820628 FPFBQ410 NEBRASKA SURROUND WHITE Christchurch, Dorset BH23 2BT F820879 FPFBQ832 NEBRASKA SURROUND PINE Tel: 01202 499330 Fax: 01202 499326 www.focalpointfires.co.uk...
- Page 2 GB IE A S S E M B L Y I N S T R U C T I O N S Section Contents Page No. Important notes Tools required Hardware & parts list Assembly Installation Cleaning/ finishing Guarantee - terms and conditions 1.0 IMPORTANT NOTES To ensure safe and stable installation: 1.
- Page 3 GB IE 4.0 ASSEMBLY Fixings Parts STEP 1 A x 4 PCS D x 4 PCS ② ③ ④ Gently lay both legs you have prepared onto a suitable protected surface. Be extremely careful not to scratch the front edges of the legs.
- Page 4 GB IE 4.0 ASSEMBLY - CONTINUED Fixings Parts STEP 3 A x 4 PCS B x 6 PCS C x 6 PCS ⑥ ⑤ ② ⑤ ③ ⑤ ④ Use the Glue (I) in the dowel holes before inserting 2x dowels (A) into the left and right hand legs (3 and 4). Position the cam bolts (B) in to left and right side panels (3 and 4).
- Page 5 GB IE 5.0 INSTALLATION Fixings E x 2 PCS F x 4 PCS G x 2 PCS H x 2PCS With a pencil mark out the desired height where you would like the mirror brackets (H) to be situated on the rear of the legs. To avoid splitting the leg, pre drill the bracket holes with a 2mm drill bit.
