Summary of Contents for FocalPoint DS-FS22
- Page 5 STEP 3 Fixings Parts AX 4PCS BX 6PCS CX6PCS In sert some glue U) in to the 2x dowel holes in each side leg (3 an d 4). In sert 4x dowels (A) in to the side legs (3 an d 4). Then with a cross headed screw driver, carefully screw 6x cam bolts (C) in to the side legs (3 an d 4).
- Page 6 Firstly insert 4x wooden dowels (A) with glue U) into the top of the hearth (6). With a cross headed screw driver, carefully insert 6 x single headed cam bolts into the top of the hearth (6). For this step we recommend to use two people. Carefully lift the surround over the hearth (6) ensuring that all 6 x single headed cam bolts and 4x wooden dowels (A) insert the bottom edges of the surround.
