modway BBT 6503 TWIN HB Assembly Instructions

MODEL : BBT 6503 TWIN HB
Read this instruction carefully. See hardware and furniture part list for guidance.
Be sure all parts are complete, before you assemble. Place all wooden furniture
parts on a clean and flat soft surface to prevent from being scratched.
Follow the figure to start assembling.
CAUTIONS
: 1. Do not FULLY - TIGHTEN the nut or nut bolt until all nut or bolt is ready assembed.
2. Do not OVER - TIGHTEN the nut or bolt to avoid causing damages to the thread.
3. Keep all hardware parts out of reach of children.
NOTE : THE LIST AND QUANTITY SHOWN ARE FOR 1 UNIT ASSEMBLY.
Step 1
A
Align support board fixing holes over headboard
fixing holes according to your desire height.

STEP 3

Your headboard assembly is complete.
Note: Hardware may loose over time. Periodically
check that all connections are tight.
ASSEMBLY INSTRUCTIONS
ITEM
A
B
Step 2
B
Secure the support board by using JCBB Bolt [1]
& flat washer [2]. Tighten with supplied allen key
[3]. Repeat the same procedure to secure the
other side.

PART LIST

QTY ITEM
DESCRIPTION
1 JCBB BOLT M8 x 45mm
HEADBOARD 1 PC
2
M8 FLAT WASHER
SUPPORT BOARD 2 PCS
3 M5 ALLEN KEY (BALL SHAPE)
HARDWARE PART LIST
QTY
DESCRIPTION
4 PCS
4 PCS
1 PC
3
1
2
