modway BBT 6689 TWIN / FULL HB Assembly Instructions

MODEL : BBT 6689 TWIN / FULL HB
Read instructions carefully. See furniture and hardware part
list on the right for guidance.
Have all parts ready before assembly. Place all wooden furniture
parts on a clean and flat soft surface to prevent scratching.
Before you start, here are some words of caution:
1. Do not FULLY - TIGHTEN nuts and bolts until all nuts and bolts are partially tightened.
2. Do not FULLY - TIGHTEN nuts and bolts to avoid causing damage to the threading.
3. Keep all hardware parts out of reach of children.
NOTE : THE LIST AND QUANTITY SHOWN ARE FOR 1 UNIT ASSEMBLY.

STEP 1

A
FULL
SIZE
Headboard holes according to
your desired headboard Size
ASSEMBLY INSTRUCTIONS
FULL
SIZE
TWIN
SIZE
B
A
FURNITURE PART LIST
ITEM DESCRIPTION
A
HEADBOARD
B HEADBOARD (L & R)
C
SUPPORT WOOD
6
1
4
3
5
HARDWARE PART LIST
ITEM DESCRIPTION
QTY
1 JCBB BOLT M8 x 45mm
1 PC
2
JCBB BOLT M8 x 40mm
2 PCS
3
M8 FLAT WASHER
2 PCS
4
M8 SPRING WASHER
5
WOOD DOWEL M10 x 30mm
6 M5 ALLEN KEY (BALL SHAPE)
5
1 of 3
QTY
8 PCS
4 PCS
12 PCS
12 PCS
4 PCS
1 PC
B
