- Page 1 Rewinders Slitters Dispensers Applicators Unwinders Print Solutions Counters Core-Chucks Splicers RRC-400 Reel-to-Reel Counter / Rewinder User Manual www.labelmateusa.com...
-
Page 2: Training And Instruction
• Any machine can be dangerous to operators when improperly used or poorly maintained. • All employees operating and maintaining Labelmate equipment should be instructed on correct use and safety guidelines. • Most accidents are preventable if adequate precautions are taken. -
Page 3: Built-In Safety Features
• The RRC-400 slows down at the end of the roll to ensure accurate counts and to prevent the label backing from breaking due to excess speed. -
Page 4: Encoder Option
Reel-to-Reel Counters provide the ideal off-line solution for counting rolls of labels. With these machines you can verify the number of labels on a roll, divide large rolls into smaller rolls using the preset count/stop fea- ture, and re-tension loose rolls. The RRC-400 affords high-speed bi-directional counting capability for up to 16” diameter rolls. -
Page 5: Getting Started
GETTING STARTED Step 1: Install Exterior Roll Guide Shafts and Brackets (Recommended) • The Guide Bracket is used to maintain a flush outer roll edge. • The Guide Bracket Shafts are mounted in the two upper corners of the unit. (FIG. 1) •... - Page 6 A) Using the Quick-Chuck • Slide a label roll or empty label core over the “Quick-Chuck” and turn the red lock knob clockwise until it is tight. (FIG. 4 & FIG. 5) • When using narrow label cores the outer edge of the “Quick-Chuck” must be constrained to ensure that the “Quick-Chuck”...
- Page 7 B) Using the Adjustable Core Holder (ACH) • Unlock the three locking levers underneath the plate by turning them clockwise. (FIG. 8) • If any of the levers are difficult to grasp, pull the lever arm down, and turn the arm to reposition it so that it is approxi- mately perpendicular to the cylindrical metal hub.
- Page 8 LED above the Counter Reset button illuminates. (FIG. 16) • Remove the label liner from the label gap sensor. CALIBRATING THE ULTRASONIC SENSOR (RRC-400-U Model Only) • Once the labels have been threaded through the label sensor, press and hold the “T” button, located on the front of the sensor, until the green and yellow LED’s flash simultaneously.
- Page 9 SENSOR SELECT OPTION (For RRC-400-U and RRC-ENC Encoder Option Only) • Opaque labels and liners: Flip the switch on the lower front left side of the unit to OPAQUE. (FIG. 19) • Transparent labels and liners: Flip the switch on the lower front left side of the unit to TRANSPARENT.
- Page 10 ADJUSTING THE DAMPER ROLLERS (FIG. 20 - Top) • The damper rollers at the top of the machine should be slightly separated from the aluminum rollers such that the labels are close but do not touch the rubber rollers. • The rubber rollers help prevent any variance in the final count by preventing the fluttering of the web at the end of the roll from being felt by the label sensor as the web is pulled off of the unwind side of the machine.
- Page 11 OPERATING THE RRC-400 • Place both direction switches in the stop position (illustrated by the “|” symbol). (FIG. 16) • Place the supply roll of labels onto a core holder on one side of the machine. • Install an empty label core onto the other side of the machine and tighten the Core-Holder.
- Page 12 A) Sync Mode (FIG. 20 - Bottom) • Sync Mode enables semi-automatic operation. Once the operator has chosen the desired direction and speed, the machine will automatically adjust the speed throughout the counting process to optimize the counting time and roll tension. •...
- Page 13 B) Manual Mode (FIG. 16) • Manual Mode gives the user complete control over the operation of the machine. The two bidirectional motors enable the rewinding and unwinding in any direction and any configuration. (FIG. 25, 26, 27, 28). Note: The motors CAN be set in opposite directions and at different speeds. This is perfectly OK and will not damage the machine.
- Page 14 Each button increases the preset count by its respective order of magnitude. • When the preset number of labels is reached, the RRC-400 will stop as close to the desired count as possi- ble. Pressing the white “COUNTER RESET” button to the left of the counter will start the RRC-400 again.
- Page 15 FIG. 29 RESET “UP” SET/LOCK FIG. 30 Label Label Label FIG. 31 FIG. 32 Page 15...
-
Page 16: Scale Factor
RRC-ENC ENCODER OPTION DESIRED READOUT - UNITS SCALE FACTOR Millimeters (mm) 4.555 Centimeters (cm) 0.456 Meters (M) 0.004 Inches (in) 0.179 Feet (ft) 0.015 B) Numerically Count Opaque Labels with Gaps • Flip the switch on the lower front left side of the unit to OPAQUE. (FIG. 19) •... - Page 17 USA’s option. Labelmate USA retains sole discretion to determine whether or not a product is defective. In no event shall Labelmate USA have any obligation to repair or replace until the customer returns the defec- tive product to Labelmate USA. The customer assumes any and all responsibility and liability associated with transportation of products for service under this Warranty.
- Page 18 Toll Free: 877.833.7149 Direct: 702.435.8535 12A Sunset Way Henderson, NV 89014...
