Abex Exhibits ELITE GRAPHIC WALL EGW-66 Quick Start Manual

ELITE GRAPHIC WALL fabric display
ELITE GRAPHIC WALL is constructed of aluminum extrusion
and features SEG press fit fabric graphics for hassle free set up.
Heavy duty aluminum feet ensure maximum stability. Graphics
are printed on premium fabric for vibrant colors. The entire unit
disassembles and packs flat in a single rotomolded case for
unparalleled protection.
MODEL #: EGW-66
SPECIFICATIONS / ASSEMBLY
3D VIEW
Details
• 1.5" Low-profile aluminum extrusion
frame
• Single or double-sided SEG press fit
dye-sublimated fabric graphics
• Easy assembly
• Packs in a single rotomolded
flat transport case
• Limited Lifetime Warranty
• Made in the USA
Dimensions
Assembled unit:
72"w x 72.25"h x 17.5"d
1829mm x 1835mm x 444mm
40 lbs / 18.1 kgS
Graphic area:
71.5"w x 71.5"h
1816mm x 1816mm
72"
Additional information
Set-Up Time: 25-30min
Lead Time: 10 Days
Warranty: Limited Lifetime Warranty
Includes
• 6' x 6' Elite Frame
• Elite Stabilizer Feet
• SEG Front Fabric Graphic
• Elite Tool Kit
• Rotomolded Case
72"
17 1/2"
RIGHT VIEW
FRONT VIEW
Shipping
Packs in ( 1 ) L-8R1851-02 case
Shipping dimensions:
51"h x 18"w x 4.5"d
1295mm x 457mm x 114mm
55 lbs / 24.9 kgS
72 1/4"
