- Page 1 INSTRUCTIONS DP-6376 Airless Spray Gun 5000 psi (345 bar) Maximum Working Pressure This manual contains important warnings and information. READ AND KEEP FOR REFERENCE. INSTRUCTIONS...
-
Page 2: Table Of Contents
This equipment is for professional use only. Read all instruction manuals, tags, and labels before operating the equipment. Use the equipment only for its intended purpose. If you are not sure, call your DP-Airless distributor Do not alter or modify this equipment. Use only DP-Airless parts. -
Page 3: Warnings
WARNING INJECTION HAZARD Spray from the gun, leaks or ruptured components can inject fluid into your body and cause extremely serious injury, including the need for amputation. Fluid splashed in the eyes or on the skin can also cause serious injury. Fluid injected into the skin might look like just a cut, but it is a serious injury. - Page 4 WARNING FIRE AND EXPLOSION HAZARD Improper grounding, poor ventilation, open flames or sparks can cause a hazardous condition and result in a fire or explosion and serious injury. If there is any static sparking or you feel an electric shock while using this equipment, stop spray- ing immediately.
-
Page 5: Installation/Operation
Installation/Operation Pressure Relief Procedure WARNING WARNING Be sure your system has a bleed-type master air valve (pneumatic pumps only) and a pressure drain INJECTION HAZARD valve. These accessories help reduce the risk of The system pressure must be manually serious bodily injury, including fluid injection, relieved to prevent the system from splashing in the eyes or on the skin, or injury from starting or spraying accidentally. -
Page 6: How To Use The Gun
Installation/Operation How to Use the Gun 7. If adjusting the pressure does not give a good spray pattern, follow the Pressure Relief Proce- dure on page 5 and then try another tip size. 1. Connect a grounded fluid hose to the gun inlet. See Fig. -
Page 7: How To Clean The Spray Tip And
Installation/Operation How to Clean the Spray Tip Clearing an Obstruction If the spray tip clogs while spraying, immediately stop and Clear a Spray Tip Obstruction spraying, then: WARNING To reduce the risk of fluid injection or splashing in 1. Lock the gun trigger safety, open the pressure the eyes or on the skin, do not hold a hand, body drain valve. -
Page 8: How To Check The Gun Diffuser
Installation/Operation How to Check the Gun Diffuser Operation Fig. 5 WARNING How to Flush the Gun To reduce the risk of serious injury whenever you are instructed to relieve pressure, always follow the Always flush the pump and the gun before the fluid Pressure Relief Procedure on page 5. - Page 9 Service Use all the new parts for the best results. Parts included in the kit are shown with one asterisk, (2a*). Keep parts very clean. Dried paint or other contami- nants cause friction which causes parts to wear faster. Needle Replacement WARNING To reduce the risk of serious injury whenever you Fig.
-
Page 10: Caution
Service 7. Slide the rear of the needle (2c*) into the front of the gun. Slide the tool (B), provided with the repair kit, into the gun, around the needle. Lightly tap the tool with a hammer or lightly press the tool against a flat surface to seat the needle. - Page 11 DP-6376 PARTS Lubricate, then torque to 20-25 ft-lb (27-34 N.m) Lubricate Torque to 30-40 in-lb (3.4–4.5 N.m)
