Please read and keep this manual, Read carefully before attempting to assemble, install, operate or maintain the
product described. Protect yourself and others by observing all safety information. Failure to comply with instructions
could result in personal injury and/or property damage! Retain instruction for future reference.
Operating Instruction
Product model:DP-3400
DP-3400
5.5 hp 4.0L
www.dpairless.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Airless DP-3400
Summary of Contents for Airless DP-3400
- Page 1 Operating Instruction Product model:DP-3400 DP-3400 5.5 hp 4.0L Please read and keep this manual, Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or property damage! Retain instruction for future reference.
- Page 2 Warning Warning The following warnings include general safety information for this equipment. Further product specific warnings may be included in the text where applicable. WARNING FIRE AND EXPLOSION HAZARD Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. To help prevent fire and explosion: •...
- Page 3 WARNING WARNING EQUIPMENT MISUSE HAZARD Misuse can cause death or serious injury. • Do not exceed the maximum working pressure or temperature rating of the lowest rated system component. See Technical Data in all equipment manuals. • Use fluids and solvents that are compatible with equipment wetted parts. See Technical Data in all equipment manuals.
- Page 4 Engine controls Commandes moteur Controles del motor Engine ON/OFF switch Bouton MARCHE/ARRÊT Interruptor encendido/apagado du moteur (ON/OFF) del motor Pump On/Off Switch Bouton marche/arrêt de la pompe Interruptor On/Off de la bomba Pressure control Régulation de la pression Dispositivo de control de la presión Prime valve &...
- Page 5 Setup Setup Connect appropriate Graco Connect other end of hose Tighten securely. Remove tip guard. high-pressure hose to to gun. Setup sprayer. Tighten securely. (cold) Approximate Fill Level Install clean inlet strainer. Check engine oil level. Fill fuel tank. Attach sprayer grounding Fill throat packing nut with Add SAE 10W-30 clamp to earth ground.
- Page 6 Startup Start engine. Move fuel valve to open. Move choke to closed. Set throttle to fast. Set engine switch to ON. Set pump switch ON. - Pump/clutch is now active - Pull starter rope. After engine starts, move Set throttle to desired setting. choke to open.
- Page 7 Startup safety Switch PAINT FLUSH seat OneSeal SwitchTip and Guard Assembly Place siphon tube in paint Trigger gun again into Put trigger safety ON. Screw assembly onto gun. pail. flushing fluid pail until paint Insert SwitchTip. Insert Hand tighten. appears. Assemble tip and seat and OneSeal.
- Page 8 Pressure Relief PressureRelief PAINT Set pump valve OFF. Turn pressure to lowest Turn prime valve down. Remove guard and Turn engine OFF. setting. Trigger gun into pail SwitchTip. to relieve pressure. Cleanup PAINT FLUSH FLUSH Do Pressure Relief, Clean filter, guard and Remove siphon tube set Turn engine ON and start page 17.
- Page 9 Cleanup PAINT 20 SEC FLUSH PAINT FLUSH Hold gun against paint pail. Move gun to flushing pail, Turn prime valve down Raise siphon tube above Take trigger safety OFF. hold gun against pail, and allow flushing fluid to flushing fluid and run Turn pressure control up trigger gun to thoroughly circulate for approximately...
