Summary of Contents for INVENTOR UIAA 55 UK

  • Page 1 UIAA 55 UK...

  • Page 2: Table Of Contents

    1. SAFETY WARNINGS ..................1 2. INSTALLTION ....................2 3. PRODUCT OVERVIEW ..................7 4. OPERATION ....................8 UIAA 55 UK 5. CLEANING ...................... 8 6. MAINTENANCE ....................9 7. TROUBLE SHOOTING ..................9 8. TIPS FOR ENERGY SAVING ................10...

  • Page 3: Safety Warnings

    1. SAFETY WARNINGS WARNING―Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING―Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. WARNING―Do not damage the refrigerant circuit. WARNING―Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

  • Page 4: Installtion

    2. INSTALLTION 2.1 Location When selecting a position for your unit you should make sure the floor is flat and firm, and the room is well ventilated. Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the electrical consumption.
  • Page 5 2) Remove the screws fixed the top-hinge with cross-slot screwdriver. 3) Replace the top-hinge and the top-door limit block and the door bearing bush to the other side. Remove the nut with sleeve. Take off the washer then remove the axes to the other side and fixed.
  • Page 6 Please taking out another door limit block, with screw mounting to the door 4) Disassemble the screws fixed the bottom-hinge with cross-slot screwdriver. Note：the refrigerator-freezer incline angle less 45°. 5) Replace the bottom hinge to the other side then fix it with screws.
  • Page 7 6) Set the door right position, fix the mid-hinge. 7) Replace the top-hinge. 8) Set the top door right position, fix the top-hinge and the cover.
  • Page 8 9) Replace the leveler to the other side and adjust it to make sure the cabinet level. Door Space Requirements The unit's door must be able to open fully as shown. W×D≥902×1052mm...
  • Page 9 Levelling the Unit To do this adjust the two levelling feet at the front of the unit. If the unit is not level, the door and magnetic seal alignments will not be covered properly. Make sure that the foot touches the ground before use. Look down from the top, clockwise and counterclockwise loosening, tightening.

  • Page 10: Product Overview

    You should always slide one of the full size glass storage shelves into the lowest set of guides, above the fruit and vegetable containers, and keep it in this posi on. To do this, pull the storage shelf forward un l it can be swivelled upwards or downwards and removed.

  • Page 11: Cleaning

    ◆During high ambient temperatures e.g. on hot summer days. It may be necessary to set the thermostat to the Coolest setting(position“Max”).This may cause the compressor running continuously in order to maintain a low temperature in the cabinet. ◆For the first time you install your refrigerator, set the thermostat knob at “Med”. Give your refrigerator time to cool down completely before adding food.

  • Page 12: Maintenance

    5.3 Cleaning Tips Condensation may appear on the outside of the unit. This may be due to a change in room temperature. Wipe of any moisture residue. If the problem continues, please contact a qualified technician for assistance. 6. MAINTENANCE 6.1 Care When Handling / Moving Your Unit Hold the unit around its sides or base when moving it.

  • Page 13: Tips For Energy Saving

    7.1 Warm tips: ◆The refrigerator enclosure may emit heat during operation specially in summer, this is caused by the radiation of the condenser, and it is a normal phenomenon. ◆Condensation: condensation phenomenon will be detected on the exterior surface and door seals of the freezer when the ambient humidity is large, this is a normal phenomenon, and the condensation can be wiped away with a dry towel.
  • Page 14 Correct Disposal of this product Correct Disposal of this product This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources.
