sauermann KIRAY 300 User Manual

Supplied with
thermocouple K
probe

Technical specifications

Spectral response
Optical
Temperature range
Accuracy*
Infrared repeatability
Display resolution
Response time
Emissivity
Over range indication
Dual laser sighting
Positive or negative
temperature indication
Display
Auto-extinction
High/low alarm
Power supply
Autonomy
Operating temperature
Storage temperature
Relative humidity
From 10% to 90%RH in operating mode and >80%RH in storage
Dimensions
Weight
Memory
*Accuracy for an ambient temperature from 23 to 25 °C (with a relative humidity lower than 80% RH).
USER MANUAL
KIRAY 300
Infrared thermometer
Infrared thermometer Kiray 300 is a thermometer used to diagnose, inspect
and check any temperature. Thanks to its elaborated optical system with a dual
laser sighting, it allows easy and accurate measurements of little distant targets.
The KIRAY 300 instrument has an internal memory which can save up to 100
measurements. Compatible with thermocouple K probe.
8 - 14 μm
D.S: 50:1 (50.8 mm at 2540 mm)
From -50 to +1850 °C
From -50 to +20 °C: ±3 °C
From +20 to +500 °C: ±1% ±1 °C
From +500 to +1000 °C: ±1.5%
From +1000 to +1850 °C: ±2%
From -50 to +20 °C: ±1.5 °C
From +20 to +1000 °C: ±0.5% or ±0.5 °C
From +1000 to +1850 °C: ±1%
0.1 °C
150 ms
Adjustable from 0.10 to 1.00 (pre-set at 0.95)
Display indication: "----"
Wavelength: from 630 nm to 670 nm
Output < 1mW, Class 2 (II)
Automatic (no indication for a positive temperature)
(-) sign for a negative temperature
3 lines, 4 digits with backlighted display LCD
Automatic after 7 seconds of inactivity
Flashing signal on display and beep signal with
adjustable thresholds
Alkaline 9 V battery
95 h (inactive laser and backlight)
15 h (active laser and backlight)
From 0 to +10 °C for a short period
From 11 to +50 °C for a long period
From -10 °C to +60 °C
200 x 140 x 50 mm
320 g (included battery)
100 temperature values
Distance from the target
Please make sure that the target is larger than
the size of the laser sighting.
Thermocouple K probe features
Temperature range
Display range From -50 to +1370 °C
Resolution
Accuracy ±1.5% of reading ±3 °C
Cable length
°C
°F
From -40 to +400 °C
0.1 °C
1 m
