sauermann KIRAY 50 User Manual

Distance from the target
USER MANUAL
KIRAY 50
Infrared thermometer
Infrared thermometer KIRAY 50 is a key tool to diagnose, inspect and check
any temperature, with the advantage of using "no-contact" technology.
You can safely measure surface temperatures of hot objects, dangerous or
difficult to access. Perfect tool to take temperature in a house, a garage, a
workshop, an office, a car, a kitchen etc...
Technical features
Spectral response
Optical
Temperature range
Accuracy*
Display resolution
Response time
Emissivity
Over range indication
Laser sighting
Indication of positive or
negative temperature
Screen
Auto-extinction
Power supply
Autonomy
Use temperature
Storage temperature
Relative humidity
Dimensions
Weight
*Accuracy for an ambient temperature from 18 to 28°C (with a relative humidity lower than 80% RH)
6 - 14 μm
D.S : 12:1 (100 mm at 1200 mm)
From -50 to +380 °C
From -50 to -20 °C: ±5 °C
From -20 to +380 °C: ±2% of reading or ±2 °C
0.1 °C
Less than 1 second
0.95 (fixed value)
LCD will show: "HI" / "Lo"
Wave length: from 630 nm to 670 nm
Output < at 1mW, Class 2 (II)
Automatic (no indication for a positive temperature)
(-) sign for a negative temperature
4 digits with LCD backlighted screen
Automatic after 10 seconds of inactivity
Alkaline 9 V battery
100 h (inactive laser and backlight)
30 h (active laser and backlight)
From 0 to +10 °C for a short period
From +11 to +50 °C for a long period
From -20 °C to +60 °C
From 10 to 90%RH in operating mode
and lower than 80%RH in storage
155 x 82 x 43 mm
170 g (included battery)
°C
°F
