sauermann KIRAY 200 User Manual

Supplied with
thermocouple K probe
Technical specifications
Spectral response
Optical
Temperature range
Accuracy*
Display resolution
Response time
Emissivity
Over range indication
Laser sighting
Positive or negative
temperature indication
Display
Auto-extinction
High/low alarm
Power supply
Autonomy
Operating temperature
Storage temperature
Relative humidity
From 10% to 90%RH in operating mode and >80%RH in storage
Dimensions
Weight
Memory
20 temperature values with unit of measurement (°C or °F)
*Accuracy for an ambient temperature from 18 to 28 °C (with a relative humidity lower than 80% RH)
USER MANUAL
KIRAY 200
Infrared thermometer
Infrared thermometer KIRAY 200 is an infrared thermometer used to diagnose,
inspect and check any temperature. Thanks to its elaborated optical system, it
allows an easy and accurate measurement of little distant targets. KIRAY 200
instrument has an internal memory which can save up to 20 measurements.
8 - 14 μm
D.S: 30:1 (50 mm at 1500 mm)
From -50 to +850 °C
From -50 to -20°C: ±5 °C
From -20 to +200 °C: ±1.5% of reading ±2 °C
From +200 to +538 °C: ±2% of reading ±2 °C
From +538 to +850 °C: ±3.5% of reading ±5 °C
0.1 °C
Less than 1 second
Adjustable from 0.10 to 1.00 (pre-set at 0.95)
Display indication: "-0L" for a negative over range,
"0L" for a positive over range.
Wavelength: 630-670 nm
Output < 1mW, Class 2 (II)
Automatic (no indication for a positive temperature)
(-) sign for a negative temperature
4 ½ digits with LCD backlighted display
Automatic after 7 seconds of inactivity
Flashing signal on display and beep signal with
adjustable thresholds
Alkaline 9 V battery
38 h (inactive laser and backlight)
15 h (active laser and backlight)
From 0 to +10 °C for a short period
From 11 to +50 °C for a long period
From -20 °C to +60 °C
175 x 110 x 45 mm
230 g (included battery)
Distance from target
Make sure that the target is larger than the
size of the laser sighting.
Thermocouple K probe features
Temperature range
Display range From -50 to +1370 °C
Resolution
Accuracy ±1.5% of reading ±3 °C
Cable length
°C
°F
From -40 to +400 °C
0.1 °C
1 m
