PCB Piezotronics IMI SENSORS 642A10/034BZ Installation And Operating Manual page 16

Model Number
642A10
Performance
Measurement Range
Output
Frequency Range(± 10 %)
Broadband Resolution
Non-Linearity
Environmental
Temperature Range
Electrical
Excitation Voltage
Settling Time(within 2% of value)
Electrical Isolation(Case)
Physical
Size (Hex x Height)
Weight(without cable)
Mounting Thread
Mounting Torque(Stud)
Mounting Torque(hex nut)
Sensing Element
Sensing Geometry
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
Cable Termination
Electrical Connections(Red)
Electrical Connections(Blue)
Cable Length
Cable Type
[7]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
4-20 MA OUTPUT VELOCITY SENSOR
ENGLISH SI
0.0 to 0.5 in/sec pk 0 to 12.7 mm/s pk
4-20 mA 4-20 mA
180 to 60,000 cpm 3 to 1 kHz
0.005 in/sec rms 0.13 mm/s rms
± 1 % ± 1 %
-40 to 185 °F -40 to 85 °C
12 to 30 VDC 12 to 30 VDC
<15 sec <15 sec
8 8
>10 Ohm >10 Ohm
7/8 in x 1.41 in 22.2 mm x 35.8 mm
3.8 oz 108 gm
1/4-28 UNF 1/4-28 UNF
3 to 4 ft-lb 4.1 to 5.4 Nm
2 to 3 ft-lb 2.7 to 4.1 Nm
Ceramic Ceramic
Shear Shear
Stainless Steel Stainless Steel
Welded Hermetic Welded Hermetic
Integral Cable Integral Cable
Side Side
Pigtail Ends Pigtail Ends
4-20 mA Pos (+) 4-20 mA Pos (+)
4-20 mA Neg (-) 4-20 mA Neg (-)
10 ft 3.0 m
Polyurethane Polyurethane
OPTIONAL VERSIONS
[1]
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
[2][3]
[4]
EX
- Hazardous Area Approval- contact factory for specific approvals
Hazardous Area Approval DIV II, CL I, GRPS A-D, ExnL,
Hazardous Area Approval EEx ia IIC T4, -40°C≤Ta≤80°C,
Hazardous Area Approval EEx nL IIC T4, -40°C≤Ta≤80°
Hazardous Area Approval DIV I, CL I, II, III, GRPS A-G,
M
- Metric Mount
Supplied Accessory : Model M080A163A (1) replaces Model 080A162
[5][6]
RV
- Buffered Analog Signal Output - 100 mV/g (±20%)
Electrical Connector
Electrical Connections(Red)
Electrical Connections(Black)
Electrical Connections(White)
Electrical Connections(Green)
NOTES:
[1]Conversion Factor 1 in/sec = 0.0254 m/sec.
[2]1Hz = 60 cpm (cycles per minute).
[3]Current will fluctuate at frequencies below 5 Hz.
[4]Typical value.
[5]1/8" hex Allen key required for English version, 3mm hex Allen key required for metric version.
[6]Stud torque must exceed sensor hex nut torque to ensure proper dismantling.
[7]See PCB Declaration of Conformance PS039 or PS053 for details.
SUPPLIED ACCESSORIES:
Model 080A162 Mounting Stud (1)
Model ICS-4 NIST-traceable single-axis amplitude response calibration from 0 cpm (0 Hz) to
upper 10% frequency for 4 - 20 mA output vibration sensor
Entered: AP Engineer: DK
Date: 10/10/2014 Date: 10/10/2014
3425 Walden Avenue, Depew, NY 14043
Revision: B
ECN #: 43341
DIV II, CL I, GRPS A-D, ExnL,
AExnA, IIC T4 AExnA, IIC T4
EEx ia IIC T4, -40°C≤Ta≤80°C,
II 1 G II 1 G
EEx nL IIC T4, -40°C≤Ta≤80°
C, II 3 G C, II 3 G
DIV I, CL I, II, III, GRPS A-G,
Exia, AExia, IIC T4 Exia, AExia, IIC T4
Integral Cable Integral Cable
4-20 mA Pos (+) 4-20 mA Pos (+)
4-20 mA Neg (-) 4-20 mA Neg (-)
Signal Output Pos Signal Output Pos
Signal Output Neg Signal Output Neg
Sales: EGY Approved: BAM Spec Number:
Date: 10/10/2014 Date: 10/10/2014
Phone: 800-959-4464
Fax: 716-684-3823
E-Mail: imi@pcb.com
37312
