- Page 1 English Smart Roller Shutter 7 1 2 3 4 5 6 OPERATING INSTRUCTIONS PRODUCT CODE PRODUCT VARIANT UMS700 Standard RXMC700 RX (white wire)
-
Page 2: Table Of Contents
Revision History Rev. Doc. Date Page Description 30/06/2022 Initial version 29/09/2022 Update of the Association section 21/10/2022 Parameter 38 has been removed Parameter 37: size has been changed to 1 Supported Command Classes paragraph has been updated 07/12/2022 Electrical connection diagram (added RX variant) 02/02/2023 Integrated Max transmitted power update Content... - Page 3 Compliance with directives ............................13 Warranty ..................................13 Legal Notes ...................................13 Smart Roller Shutter 7 - Operating Instructions...
-
Page 4: Device Description
Device description Smart Roller Shutter 7 is an "in wall device", for the multilevel control of roller shutter motors. It can accurately control the opening and closing of blinds, curtains, shutters, venetian blinds as requested by the user through local commands or remotely using computers, smartphones, tablets. -
Page 5: Technical Specifications
Technical Specifications Power supply 110 - 230 VAC±10% 50/60 Hz Maximum Load 1200 Watt System temperature limitation 105°C Work temperature From -10° to 40° C < 230 mW in standby mode Power consumption < 500 mW when motor is moving Radio frequency 868.4 MHz Maximum transmitted power... -
Page 6: Electrical Connections Diagram
Electrical Connections diagram The device must be supplied by 230 AC Power Supply. Connections must be done following one of the diagrams below: Standard Variant RX Variant 1 2 3 4 5 6 Power Supply: 1 – Null, 6 - Line Power Supply: 1 –... -
Page 7: Device Installation
Device Installation 1) Make sure the main switch is set to the OFF position 2) Connect the device based on the diagrams provided 3) Turn the main switch to the ON position 4) If necessary, calibrate the motor limit switches (see motor manufacturer's manual) 5) Include the device in the Z-Wave™... -
Page 8: Smartstart Inclusion
Standard exclusion (remove) Only a controller can remove the device from the network. After activating the exclusion function by the controller, the device can be removed by setting it in Learn Mode. The procedure of exclusion can be activated by Removing a node from the Z-Wave™ network and executing 1 or 3 click on the integrated button;... -
Page 9: Supported Command Classes
Supported Command Classes Command Class Version Non-Secure CC Secure CC BASIC ZWAVEPLUS_INFO ASSOCIATION MULTI_CHANNEL_ASSOCIATION ASSOCIATION_GRP_INFO TRANSPORT_SERVICE VERSION MANUFACTURER_SPECIFIC DEVICE_RESET_LOCALLY INDICATOR POWERLEVEL SECURITY_2 SUPERVISION FIRMWARE_UPDATE_MD APPLICATION_STATUS CONFIGURATION_V4 SWITCH_MULTILEVEL WINDOW_COVERING Supporting Command Class Basic The basic command classes are mapped into the Switch Multilevel Command Class. Basic Command received Mapped Command (multilevel Switch) Basic Set (0xFF) -
Page 10: Device Control
Device Control Smart Roller Shutter 7 is an "in wall device", for the multilevel control of roller shutter motors. It can accurately control the opening and closing of blinds, curtains, shutters, venetian blinds by using an external switch, or from remote through a controller. -
Page 11: Controlling The Device By A Z-Wave™ Controller
Controlling the device by a Z-Wave™ controller The device can be controlled by any Z-Wave™ / Z-Wave Plus™ certified controller available in the market. In the figure below, are represented a couple of examples of control panel interfaces that show how the device will appear once included into the Gateway. -
Page 12: Firmware Update
Firmware Update The system supports over-the-air firmware updates that do not require the device to be removed from its location. The firmware update can be activated from all certified controllers supporting version 2 of the Firmware Update function. WARNING: The system will be rebooted at the end of the firmware update procedure. It is advisable to carry out the firmware update procedure only when necessary and following careful planning of the intervention. -
Page 13: Configurations
Configurations Favorite positions The system can set two favorite positions: one for the upward movements (opening movements) Favorite level for ON position, the other for the downward movements (closing movements) Favorite level for OFF position. Parameter Default Size Parameter Name Description Number Value... - Page 14 Parameter Default Size Parameter Name Description Number Value Time to reach Max level starting from the Min Level Defines the time in thousandth of a second necessary to MAX_LEVEL_TIME reach the complete open position starting from complete close position. Parameters Values Min: 100 Max: 100.000 Value...
-
Page 15: Report Configuration
Parameter Default Size Parameter Name Description Number Value Adjustment in Percentage value of the 50% level position after the initial calibration. FINE_CALIBRATION Increasing/decreasing of this value will move the 50% level in the UP direction/Down direction. Parameters Values Min: 50 Max: 150 Value Description... -
Page 16: Disposing The Devices
Disposing the devices This product bears the selective sorting symbol for waste electrical and electronic equipment (WEEE) and must be handled pursuant to European Directive WEEE in order to be recycled or dismantled to minimize its impact on the environment. For further information, please contact your local or regional authorities.
