Daewoo DBT-301 - Bluetooth Speaker Manual

Important safety instructions

• Carefully read and follow all the warnings and instructions.
• Do not use this device near water. Avoid it getting splashed.
• Do not block the ventilation openings. Install the device following the manufacturer's instructions.
• Do not install the device near source of heat like, for example, radiators, ovens or other apparatus.
• Do not tamper with the products, if the event of any fault, contact the technical service.
• Do not place sources of heat or objects containing liquid on top of the device.
• Never take the outer casing off the device.

Function keys

1. Power on/off button
2. Micro USB port support charging when speaker connect to computer, download the music into TF card. LED light:
   • Blue: indicates when playing music
   • Red: Charging mode. Long bright when charging, the light turns off when full charged.
3. USB mode, support MAX 32G USB disk, compatible with: MP3 music files
4. TF card mode, support MAX 32G fl ash, compatible with: MP3 music files

5. M button: short press to change function modes
   Bluetooth Mode: When connect with the phone, it can playback from your mobile to speaker.
6. – button: Long press to volume down, short press to change into last song; long press to Volume down in FM radio, short press is manually search the previous station.
7. + button: Long press to volume up, short press to change into next song; long press to Volume up in FM radio, short press is manually search the for next station.
8. > Button: Short press to play/stop; Short press to search the station automatically in FM radio; In Bluetooth mode, when call is coming. Press the button to answer, press again to hang up. When playing music, continuously press the button twice, it can dial last time call number.

Reminder: When there is a warning sound when playing, it is low power please charge the speaker (charger voltage: 5V, charging currency: 0.5Ah).

Functioning

The speaker works with an internal rechargeable battery. To charge the battery use the USB cable supplied to connect the speaker to a computer, or use a USB adapter (not supplied) to connect it to the mains.

To switch the speaker on slide the "POWER/ON-OFF" button, change the function using the MODE button "M", you can choose between Bluetooth / Radio FM / SD CARD / USB.

Adjusting the volume

Keep the Volume key "+" or "-" pressed to turn the volume up or down.

Bluetooth function

• Slide the "POWER/ON-OFF" button to ON, you will hear a warning indicating that the device is ready to pair
• You need to activate the Bluetooth function on your mobile, tablet or other Bluetooth device.
• Select "DBT-301" on the Bluetooth device you want to pair it with. Your speaker is now paired and ready to play your favorite music.
  To ensure good reception do not place the device more than 10 meters away from the speaker in a straight line.

Answering a call

Start playing music on the Bluetooth device. When there is an incoming call press the ">" button to answer the call. Press the ">" button again when you want to hang up.

Product disposal

Attention should be drawn to the environmental aspects of battery disposal. Don't throw used batteries in dustbin.

Please contact your retailer in order to protect the environment. Electrical products should not be disposal of with household waste. Please recycle where facilities exist.

Guarantee

This product is guaranteed against all manufacturing defects for 2 years from the date of purchase. If the care advice and instructions contained in this manual are not followed the guarantee will be automatically void.

For this guarantee to be valid, it is necessary to present the original receipt or invoice. Industrias Masats S. L. U. exclusive importer.
