Sedona Collection: Big Sky Bunk
PARTS LIST
BOX 1: 4145 Big Sky Bunk Ends
Part #
S0001END
S0002END
BOX 2: 4144 Big Sky Frame
Part #
S1001SRL
541750001
140533/40
FLDWL
5040-43181
5040-35410
COMPLETED ASSEMBLY
7030-01255 KIT
For: 4144 Frame Rails/4145 Bunk Ends
Description
Big Sky Bottom End
Big Sky Top End
Description
5/4 x 6 x 75 Mattress Rail
5/4 x 4 x 75 Guard Rail
Full Individual Slat
3" Fluted Dowel
Hex Lag Bolt/Washer
#6 x 1 1/4 Phil Flat Slat Screw
Quantity
2
2
Quantity
4
4
3
4
32
20
Advertisement
Related Manuals for Living Spaces Sedona 7030-01255 KIT
Summary of Contents for Living Spaces Sedona 7030-01255 KIT
- Page 1 7030-01255 KIT For: 4144 Frame Rails/4145 Bunk Ends Sedona Collection: Big Sky Bunk PARTS LIST BOX 1: 4145 Big Sky Bunk Ends Part # Picture Description Quantity S0001END Big Sky Bottom End S0002END Big Sky Top End BOX 2: 4144 Big Sky Frame Part # Picture Description...
- Page 2 1) Attach two mattress rails(S1001SRL) to two bottom end assemblies(S0001END) with 8 lag bolts and 8 washers(5040-43181), and tighten. 2) Attach two mattress rails(S1001SRL) and four guard rails(541750001) to top end assemblies(S0002END) with 24 lag bolts and 24 washers(5040-43181), and tighten. 3) Place four wooden dowels(FLDWL) in the four holes in top edge of bottom bunk assembly.
-
Page 3: Safety Warnings
8. Always use the ladder or bed end for entering and leaving the upper bunk. 9. Do not use substitute parts. Contact Living Spaces for replacement parts. 10. Use of a night-light may provide added safety precautions for a child using the upper bunk. - Page 5 7030-00420 STAIRWAY /BUNK 4453 / 4493 / 4676 STAIRWAY CHEST WITH BUNK BED The stairway chest has been designed for use as a free standing unit. However for your convenience, if you desire to attach the stairs to your bunk bed we have included four 2" angle brackets.
- Page 6 4453 / 4493 / 4676 STAIRWAY CHEST THE DRAWERS OF YOU STAIRWAY CHEST HAVE BEEN SECURED FOR SHIPPING WITH SECURITY STRIPS. TO RELEASE THESE STRIPS PULL EACH DRAWER FIRMLY OUT UNTIL YOU FEEL THE STRIP RELEASE. EACH DRAWER WILL FUNCTION PROPERLY AFTER THE FIRST TIME YOU PULL THEM OUT. THERE IS NO NEED TO ATTEMPT TO REMOVE THE SAFETY STRIPS AS THEY WILL NOT INTERFER WITH THE PROPER USE OF EACH DRAWER.
-
Page 7: Completed Assembly
7030-01285 KIT 4466 Trundle Sedona Collection: Trundle PARTS LIST BOX 1: 4466 Sedona Trundle Part # Picture Description Quantity 4466 Sedona Trundle Assembly 5048-00000 Bunkie Mattress 5045-65303 Caster Wheel 5045-65301 Caster Wheel Insert 5043-00205 Sedona Knob 5040-35643 1 1/2" Combo Truss Screw COMPLETED ASSEMBLY... - Page 8 TOOLS REQUIRED: NONE ASSEMBLY INSTRUCTIONS: 1) Push the 4 caster inserts into the pre-drilled holes on the bottom of the bed. Make sure the inserts sit flush with the holes and do not protrude. **Do no attempt to complete step 1 with the caster stems attached to the caster inserts** 4466 5045-65301 2) Once all 4 caster inserts are in place, install the caster wheels by pushing the stems of the caster wheels into the inserts...
- Page 9 7030-01195 KIT (Scan code for instructional video) Mateo/Sedona/Summit Collections: Knob and Pull Installation 1. Locate the box containing your knobs and/or pulls in the bottom drawer of your case good. 2. Identify which of the screw sizes is correct for your drawers/doors. The screw should protrude no more than 1/4"...
