- Page 1 WINDOW/WALL TYPE ROOM AIR CONDITIONER Before using your air conditioner, please read this manual carefully and keep it for future reference.
- Page 2 Producto...
- Page 3 1 866 7 47 4332 1 866 7 47 4332...
-
Page 4: Table Of Contents
CONTENTS 1. SAFETY PRECAUTIONS..............2 2. IMPORTANT SAFETY INSTRUCTIONS ..........4 3. NORMAL SOUNDS ................5 ..4. AIR CONDITIONER FEATURES ..........5 ..5. INSTALLATION INSTRUCTIONS............10 6. CARE AND CLEANING ..............14 7. -
Page 5: Safety Precautions
Safety Precautions To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. The seriousness is classified by the following indications. WARNING This symbol indicates the possibility of death or serious injury. - Page 6 ! CAUTION Do not clean the air Ventilate the room well when When the air filter is to be conditioner with water. used together with a stove, removed, do not touch the metal parts of the unit. etc. It may cause an injury. Water may enter the unit and An oxygen shortage may occur.
-
Page 7: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS For your safety WARNING NOTE The power supply cord with Do not store or use gasoline or other flammable vapors and liquids this air conditioner contains a current in the vicinity of this or any other appliance. detection device designed to reduce Avoid fire hazard or electric shock. -
Page 8: Normal Sounds
NORMAL SOUNDS High Pitched Chatter High efficiency compressors may have a high pitched chatter Vibration during the cooling cycle. Unit may vibrate and make noise because of poor wall or window construction or incorrect installation. Sound of Rushing Air At the front of the unit, you may hear the sound of rushing air being moved by the fan Pinging or Switching... - Page 9 AIR CONDITIONER FEATURES(CONTINUED) NOTE: The following instructions represent the Unit Controls, the same instructions can be used for the Remote Control. TO TURN UNIT ON: Auto Auto Cool High Mode DO THIS: Press the On/Off button. Follow Energy On/Off Saver TO CHANGE TEMPERATURE SETTING: NOTE:...
- Page 10 AIR CONDITIONER FEATURES(CONTINUED) TO SELECT THE NOTE: OPERATING MODE: To choose operating mode, press the Mode button. Each time you press the button, a mode is selected in a sequence that goes from Auto, Cool, Dry to Fan. The indicator light besides will be illuminated and remained on once the mode is selected.
- Page 11 AIR CONDITIONER FEATURES(CONTINUED) TIMER: AUTO START/ STOP FEATURE: NOTE: First press the Timer button, the indicator light besides word On illuminates. It indicates the Auto Start program is initiated. Temp Temp Press or hold the Left arrow or Right arrow to change the Auto time by 0.5 hour increments, up to 10 hours, Timer Timer...
- Page 12 AIR CONDITIONER FEATURES(CONTINUED) NOTE: FOLLOW ME FEATURE: This feature can be activated from the remote control ONLY. The remote control serves as a remote thermostat allowing for the precise temperature control at its location. Auto Auto To activate the Follow Me feature, point the remote Cool Light flashing control towards the unit and press the Follow Me...
- Page 13 INSTALLATION INSTRUCTIONS Your air conditioner is designed to install in standard double hung windows with opening widths of 23 to 36 inches(584mm to 914mm) (See Fig.1). Lower sash must open sufficiently to allow a clear vertical opening of 14-1/2 inches (368mm). Side louvers and the rear EX ERIOR of the AC must have clear air space to allow enough airflow OFFSET...
- Page 14 Fig.B C: Align the hole in the top rail with those in the Fig.C top of the unit as shown in Fig.B D: Secure the top rail to the unit with the 3/8 Screws as shown in Fig.C. NOTE: For safety reasons, all four(4) screws MUST be securely fastened.
- Page 15 Fig.4 C. Once the panel has been installed on the side of the cabinet, make sure it sits securely inside the frame channel by making slight adjustments. Slide the top and bottom ends of the frame into the top and bottom ends of the frame into the top and bottom rails of the cabinet.
- Page 16 Drive 3 / 4 (19mm) locking screws through frame Fig.9 holes into window sash (Fig.9/10). To secure lower sash in place, attach right angle sash lock with 3 / 4 (19mm) screw as shown(Fig.11). Fig.10 Fig.11 Fig.12 Cut foam seal and insert in the space between the upper and lower sashes (Fig.12).
-
Page 18: Troubleshooting Tips
TROUBLESHOOTING TIPS Before calling for service, review this list. It may save you time and expenditure. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Problem Solution Wall plug disconnected. Push plug firmly into wall outlet. Air conditioner does not start House fuse blown or circuit breaker tripped. - Page 19 Problem Solution Unit removing large quantity of moisture from humid room. This is normal during Water dripping excessively humid days. OUTSIDE when unit is cooling. Remote control not located within range. Place remote control within 20 feet & 180 , Remote Sensing radius of the front of the unit.
