- Page 1 FLUX Multifunctional Flood Light 6W 20W Installation Manual SOLTECH Designs and Manufactures Advanced, Solar-Powered LED Technology.
- Page 2 01 Introduction Thank you for purchasing FLUX Multifunctional Flood Light Products. Important Notice & Warning Please read these instructions before installation to ensure optimum results 1. The FLUX will provide optimal performance where and longevity of your lights. The solar panel should be charged in full there is direct sunshine.
-
Page 3: Specification
02 Specification Specifications FLUX 6W FLUX 20W LED Nominal Power Solar Panel Mono-Crystalline 10V 10W Mono-Crystalline 10V 20W LiFePO Battery 6.4V 3AH 6.4V 12AH 4,000K 4,000K Lumen Output@4000K 1,020 3,400 > 70 > 70 Product Size Light Head 9.5 X 6.9 X 1.6 Inches Light Head 12.4 X 9.0 X 2.3 Inches... -
Page 4: Installation
03 Installation WALL MOUNT Permanent Mounting Removable Mounting 90° 120° Big Screw 120° Wall Mount Base First mount the solar panel: First mount the solar panel: 4. Attach the bracket to the 1. Drill two holes into the wall 1. Drill two holes into the wall fixture and then hang the surface then use the screw kit surface, then use the screw kit... -
Page 5: Pole Mount
4. Use the screw kit to secure the fixture bracket to the pole mount base on the pole. 5. Connect the light and solar panel cables. Check List FLUX 6W FLUX 20W 01. Fixture 03. Pole Mount 01. Fixture 03. Pole Mount 02. -
Page 6: Remote Control
04 Remote Control MOTION SENSOR MODES Light on 100% if motion is detected, stand-by period is Light on 100% if motion is detected, stand-by period is 60 60 seconds. Light will turn off when no motion is detected. seconds. Light will dim down to 5% output when no motion is detected. - Page 7 Light on 50% for 3 hours (Sensor disabled), then returns to motion sensor mode. If motion detected, stand-by period is 60 seconds. Light will turn off when no motion is detected. Light on 50% for 3 hours (Sensor disabled), then returns to motion sensor mode.
- Page 8 70° N 69° N 68° N 67° N 66° N 65° N 64° N 63° N 62° N 60° Alaska 61° N 60° N 49° N 48° N Washington 47° N 46° N Montana 45° N North Dakota Oregon 44° N Minne Idaho 43°...
- Page 9 05 Panel Angle The solar charge in a battery pack won’t last forever. The off–grid system relies on stored solar energy for autonomy. Angling your solar panels properly can boost the power intake of your solar lighting system. You want to angle your solar panels at a tilt based on the area’s latitude. You can increase the tilt 15°...
- Page 10 06 IES Light Distribution FLUX 6W Lamp=1 097.4 lm Type B Max=430.1 cd Power=6 W Multiplier=1.0974 Degrees=0 Rect 122x120 mm FLUX 20W Lamp=3 125.2 lm Type B Max=1 143.6 cd Power=18 W Multiplier=3.1252 Degrees=0 1 000...
-
Page 11: Warranty
07 Warranty FLUX is covered by a 3 year limited warranty. SOLTECH urban light warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 3 years from date of purchase. To obtain warranty service please contact your local distributor or sales rep for further instruction. - Page 12 1460 Park Avenue. Emeryville, CA 94608 USA www.soltechlighting.com SOLTECH LLC reserves the right to update all product data sheets at any time. Consult SOLTECH marketing specialists for publication updates at Copyright©2022–2023 SOLTECH LLC, hello@soltechlighting.com All Rights Reserved.
