- Page 1 SOLTAB Flood Lights Installation Manual SOLTECH offers Advanced LED Technology That Is Eco-friendly And Utilizes Clean Energy.
- Page 2 01 Introduction 02 Specification Thank you for purchasing SOLTAB Urban Lighting Products. Specifications SOLTAB 10W Important quickly shows the battery capacity at any time. Enables better Please read these instructions before installation to ensure optimum results planning for your activities LED Nominal Power and longevity of your lights.
- Page 3 03 Installation WALL MOUNT 1. Take out all of the parts from the package. Confirm the installation location and wire length. 2. Use the card to mark hole positions, then drill 4 holes of 0.3 inch diameter and 2.4 inches depth. 3.
- Page 4 04 Remote Control ACCORDING TO THE CONNECTION OF THE LIGHT AND SOLAR PANEL, THE LAMP WILL AUTOMATICALLY RECOGNIZE THE SENSOR MODE & CONSTANT LIGHTING MODE & POWER BANK FUNCTION. Mode A: Constant Lighting Mode (Lamp separate with Solar Panel) Mode B: Sensor Mode (Lamp body connected to Solar Panel) NOTE: Under this work model, the Radar sensor &...
- Page 5 05 Panel Angle 70° N 69° N 68° N 67° N The Solar charge in a battery pack won’t last forever. The off–grid system 66° N relies on stored solar energy for autonomy. Angling your solar panels 65° N properly can boost the power intake of your solar lighting system. You want to angle your solar panels at a tilt based on the area’s latitude.
- Page 6 06 Luminous Distribution 07 Warranty SOLTAB 10W SOLTAB is covered by a 3 year limited warranty. SOLTAB urban light warrants to the original purchaser that this Lamp=1 210.9 lm Type C Max=531 cd/klm product is free from defects in materials and workmanship Power=1 W Multiplier=1.2109...
- Page 7 1460 Park Avenue. Emeryville CA 94608 USA www.soltechlighting.com SOLTECH LLC reserves the right to update all product data sheets at any time. Consult SOLTECH marketing specialists for publication updates at Copyright©2020–2021 SOLTECH LLC, hello@soltechlighting.com All Rights Reserved.
