Gorilla Playsets Empire Extreme Manual page 226

1: FASTEN THE 5/4 X 3 X 6-3/4" CHIMNEY MOUNTING BLOCK TO THE ROOF WITH 1-1/2" WOOD SCREWS. YOU CAN
PLACE THE BLOCK AT ANY DESIRED PLACE ON THE ROOF. USE THE DIAGRAM BELOW AS A GUIDE AS TO WHERE
YOU MIGHT INSTALL YOUR CHIMNEY.
2: AFTER INSTALLING THE CHIMNEY MOUNTING BLOCK, PLACE THE CHIMNEY ASSEMBLY ON THE ROOF SO THAT THE
INSIDE OF THE BACK WALL RESTS AGAINST THE BLOCK.
3: FASTEN THE CHIMNEY TO THE CHIMNEY MOUNTING BLOCK WITH A 1-1/2" WOOD SCREW IN EACH SIDE.
5/4 X 3 X 6-3/4"
CHIMNEY MOUNTING BLOCK
STEP 6: CHIMNEY
1-1/2" WOOD SCREW
ABOVE UNIT MAY NOT BE YOUR EXACT PLAYSET.
SHOWN FOR ILLUSTRATION PURPOSES ONLY.
1-1/2"
WOOD
SCREW
