Empire Extreme
*51-0090-W*
51-0090-W
Model: 1500MW
(BOXES: 1501, 1504, 1506,
1509N, 1509W, 1514, 1528,
1529, 1535, 1535F, 1537, 7'
Turbo Tube Slide Box, 14' Scoop
Slide (bagged) & Slide Box)
Copyright © 2018 Gorilla Playsets
All Rights Reserved
190 Etowah Industrial Court
Canton, GA 30114
www.gorillaplaysets.com
™
™
playsets
playsets
Stained Post Option
BOXES: 1533, 1534,
1522, 1541
™
™
playse ts
playse ts

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Empire Extreme and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gorilla Playsets Empire Extreme

Summary of Contents for Gorilla Playsets Empire Extreme

  • Page 1 (BOXES: 1501, 1504, 1506, 1509N, 1509W, 1514, 1528, 1529, 1535, 1535F, 1537, 7’ Turbo Tube Slide Box, 14’ Scoop Slide (bagged) & Slide Box) Copyright © 2018 Gorilla Playsets All Rights Reserved *51-0090-W* 190 Etowah Industrial Court Canton, GA 30114 www.gorillaplaysets.com...
  • Page 2 Please inspect and inventory all parts immediately upon accepting delivery. Use the inventory pages in the manual to make sure you have received all necessary parts. The quickest method to get any parts that are missing or damaged is to use our “Quick Response Center”...
  • Page 3 This decision is subject to verification of the defect, which, at Gorilla’s discretion, may be accomplished by submitting photographs or by delivery of the defective part to Gorilla Playsets • 190 Etowah Industrial Ct. • Canton, GA 30114 • 1-800-882-0272 Monday to Friday 9AM-5PM EST. Any warranty claim must include proof of purchase, including the date of purchase.
  • Page 4 Gorilla shall not be liable for incidental, indirect or consequential damages or injuries that result from building and/or playing on our play sets. Adult supervision is recommended anytime a play set is being used. WEIGHT LIMITS FOR GORILLA PLAYSETS • FORT PLATFORMS: 800 LBS. TOTAL WEIGHT • SWING BELT: 225 LBS.
  • Page 5 Product registration - emPire extreme - Gorilla Playsets manufactures ™ 3 Easy Ways To REgisTER the finest quality products that are designed for outstanding Complete the online registration form at: oPtion 1 http://www.gorillaplaysets.com/register strength and durability. We back our products with unparalleled...
  • Page 6 IMPORTANT – PLEASE READ Congratulations! You have just purchase one of the finest residential wooden swing sets available today. As with any wooden product that spends its entire life outside, in varying elements, it is important to know what to expect with your new swing set so that your family can enjoy it for many years.
  • Page 7 Please review these safety rules regularly with your children. WARNING: Children must NOT use this play set until it has been completely assembled and inspected by an adult to ensure it has been properly installed. Gorilla Playsets 190 Etowah Industrial Court Canton, GA. 30114...
  • Page 8 Model: 1500MW Stained Post Option BOXES: 1533, 1534, (BOXES: 1501, 1504, 1506, 1522, 1541 1509N, 1509W, 1514, 1528, 1529, 1535, 1535F, 1537, 7’ Turbo Tube Slide Box, 14’ Scoop Slide (bagged) & Slide Box) REV: 9.14.2018...
  • Page 9 TABLE OF CONTENTS Safety Guidelines………………………………………..……......Pages 4-7 Leveling Fort, General Information and Definitions..........Pages 7-9 How to Install T-nuts, Board Identification, Predrill Lag Screw Directions and Swing Beam Loading..................Pages 10-14 Site Plan, Required Tool List and Kit Contents ……………………….....Pages 15-16 Hardware, Lumber and Accessory Checklists……………………………..Pages 17-64 Adding T-Nuts to Corner Posts (Middle Level Deck)...………..………...…....

  • Page 10: Table Of Contents

    TABLE OF CONTENTS Upper Level Wood Roof Assembly.………………………..……....Steps 66-70 Middle Level Wood Roof Assembly..............Steps 71-76 Lower Level Wood Roof Assembly..............Steps 77-84 Wall Panel Boards....................Step 85 Plastic Sunburst..................... Step 86 Sandbox Seats and Name Plate................Step 87 Picnic Table....................
  • Page 11 Safety and Maintenance Tips for Your New Play Set: NOTE: Your children’s safety is our #1 concern. Observing the following statements and warnings reduces the likelihood of serious or fatal injury. Please review these safety rules regularly with your children. •...
  • Page 12 Safety and Maintenance Tips for Your New Play Set: (continued) Playgrounds should be inspected on a regular basis. If any of the following conditions are noted, they should be removed, corrected, or repaired immediately to prevent injuries. • Hardware that is loose, worn or that has protrusions or projections. •...
  • Page 13 Play Set Surfacing Recommendations: Below are some of the recommendations that the U.S. Consumer Product Safety Commission (CPSC) offers from its Handbook for Public Playground Safety. The guide can be downloaded in full at www.cpsc.gov/PageFiles/122149/325.pdf 1. Protective Surfacing - Since almost 60% of all injuries are caused by falls to the ground, protective surfacing under and around all playground equipment is the most critical safety factor on playgrounds.
  • Page 14 2. Fall Zones - A fall zone, covered with a protective surfacing material, is essential under and around equipment where a child might fall. This area should be free of other equipment and obstacles onto which a child might fall. Stationary climbing equipment and slides should have a fall zone extending a Minimum of 6’...
  • Page 15 General Info to Review Before Installation • Depending on your experience, assembly of the playset can take as little as 6 hours up to 24 hours, depending on size, after inventory of parts; therefore, we recommend you set aside a full two days for assembly. •...
  • Page 16 This page is a list of definitions and explanations used throughout our instructions to aid you in the assembly of your play set. Offset Holes- Throughout the installation procedures we will refer to parts with offset holes. This refers to the orientation of the holes on the board. An offset hole is one that is closer to one side than it is the other or in other words, it is not centered on the board.
  • Page 17 Common Installation Practice Installing T-nuts When installing T-nuts into the wood, use a smooth faced hammer to set the face of the T-nut flush into the wood. Corner Post T-nut Insert the barrel of the T-nut into the predrilled hole. Using a smooth faced hammer, drive the T-nut until the face of the T-nut is flush to the wood.
  • Page 18 HOW A T-NUT WORKS THE FIRST STEP IN OUR ASSEMBLY INSTRUCTIONS IS TO INSERT T-NUTS INTO THE CORNER POSTS. A T-NUT IS A FASTENER WHICH IS THREADED ON THE INSIDE AND IT FUNCTIONS JUST LIKE A STANDARD HEX NUT. YOU INSERT THE T-NUTS INTO THE PREDRILLED HOLES IN THE CORNER POSTS.
  • Page 19 BOARD IDENTIFICATION 1. On the end of each board there should be a small white tag that is stapled or stuck into place. Remove the staples and/or tag after the board is installed. 2. This white identifcation tag displays the thickness, width, length and an abbreviated description of the part.
  • Page 20 PRE-DRILL LAG SCREW DIRECTIONS Pre-drilling holes for lag screws will make it easier to drive the screws in by hand. "Jobber" length drill bits are available in sizes that are longer than standard drill bits and those are ideal for the job. When using the drill bit you will have to "spot" drill the post and then remove the board you are attaching to finish drilling the hole.
  • Page 21 SWING BEAM LOADING Weight Limits for Accessories: The weight limit for a Swing Belt is 225 lbs. (Although 150lbs is the maximum recommended swinging weight capacity for the swing position.) The weight limit for a Trapeze Bar is 125 lbs. Maximum Allowable swinging weight for a three position swing: 1) The maximum allowable swinging weight at each Swing Belt position is 150 lbs.
  • Page 22 Everest Extreme / Empire Extreme Please familiarize yourself with the manual, parts/components and general construction process of your new playset before getting started. SITE PLAN: 9'-10 " Swing Belts (2) Trapeze (1) 10'-1 8 " Clatter Bridge 3'-11 2 "...
  • Page 23 REQUIRED TOOL LIST: ___ Standard or Cordless Drill w/ Phillips Bit (#2 square bit provided) ___ Drill Bits 1/8”, 3/8”, 9/64”, 11/64” and a 1” Paddle style bit. ___ ½” Wrench and Socket ___ ½” Deep Well Socket ___ 9/16” Deep Well Socket ___ 9/16”...
  • Page 24 1501 HARDWARE PAGE: 1 OF 2 REV A: 9/10/2014 JH #8 X 1" WOOD SCREW QTY: 2 #14 X 1-1/4" #8 X 1-3/4" PAN HEAD SCREW WOOD SCREW QTY: 4 QTY: 4 #8 X 2" WOOD SCREW QTY: 189 #8 X 2-1/2" WOOD SCREW QTY: 52 #8 X 3"...
  • Page 25 5/16" X 3-1/2" 3/8 X 3-1/2" HEX LAG HEX LAG SCREW SCREW QTY: 12 QTY: 12 1501 HARDWARE PAGE: 2 OF 2 REV A: 9/10/2014 JH #2 SQUARE DRIVE BIT QTY: 1 3/8 x 9" 3/8 x 7" 3/8 x 6-1/2" 3/8 x 3-1/2"...
  • Page 26 1504 HARDWARE PAGE: 1 OF 1 PRELIMINARY 9/18/2012 J.H. #8 X 2" WOOD SCREW QTY: 71 #8 X 2-1/2" WOOD SCREW QTY: 12 #8 X 3" WOOD SCREW QTY: 5 #10 x 3-1/2" WOOD SCREW #14 x 3" QTY: 2 PAN HEAD SCREW QTY: 3 5/16"...
  • Page 27 1506N HARDWARE #8 X 1-1/4" PAGE: 1 OF 1 WOOD SCREW QTY: 6 REV B: 8/18/2015 J.H. #8 X 1-1/2" WOOD SCREW QTY: 104 #8 X 2" WOOD SCREW QTY: 28 #8 X 2-1/2" WOOD SCREW QTY: 10 #8 X 3" WOOD SCREW QTY: 2 5/16"...
  • Page 28 11-0071 1509N HARDWARE PAGE: 1 OF 1 REV A: 9/19/2014 JH #8 X 2" WOOD SCREW QTY: 94 #8 X 2-1/2" #14 x 1-1/4" WOOD SCREW PAN HEAD SCREW QTY: 18 QTY: 6 #8 X 3" WOOD SCREW QTY: 5 3/8"...
  • Page 29 1509W HARDWARE #8 X 1-1/4" WOOD SCREW PAGE 1 OF 1 QTY: 8 9/11/2014 JH #8 X 1-1/2" WOOD SCREW QTY: 60 #8 X 2" WOOD SCREW QTY: 8 5/16" x 3-1/2" HEX LAG SCREW QTY: 4 5/16" WASHER QTY: 4 USE THE RULER TO THE RIGHT TO MEASURE YOUR BOLTS AND SCREWS.
  • Page 30 1514 HARDWARE PAGE: 1 OF 1 PRELIMINARY 9/19/2012 J.H. END OF SCREW #10 X 2" SELF LOOKS SPLIT DRILLING SCREW SIMILAR TO A QTY: 18 DRILL BIT. #14 x 1-1/4" PAN HEAD SCREW QTY: 4 5/16" TEE NUT QTY: 8 3/8"...
  • Page 31 1528 HARDWARE #8 X 1" PAGE 1 OF 1 WOOD SCREW QTY: 2 1/16/2015 SO. #8 X 1-1/4" WOOD SCREW QTY: 25 #8 X 1-1/2" WOOD SCREW QTY: 110 #8 X 2" WOOD SCREW QTY: 25 #8 X 2-1/2" WOOD SCREW QTY: 12 #2 SQUARE DRIVE BIT...
  • Page 32 1529 HARDWARE #8 X 1-1/4" PAGE 1 OF 1 WOOD SCREW QTY: 22 1/16/2015 S.O. #8 X 1-1/2" WOOD SCREW QTY: 34 #8 X 1-3/4" WOOD SCREW QTY: 8 #8 X 2" WOOD SCREW QTY: 6 #8 X 2-1/2" WOOD SCREW QTY: 4 #2 SQUARE DRIVE BIT...
  • Page 33 11-0087 #8 X 3" 1535 Hardware WOOD SCREW PAGE 1 OF 1 QTY: 3 REV: C 4/12/2017 S.O. #8 X 2-1/2" WOOD SCREW QTY: 2 #8 X 2" WOOD SCREW QTY: 84 3/8" WASHER QTY: 24 #8 X 1-1/2" WOOD SCREW QTY: 130 #8 X 1-1/4"...
  • Page 34 11-2027 SUB BRACKET HARDWARE 3/8" X 2-1/2" 3/8" WASHER LAG SCREW QTY: 4 12/09/2015 QTY: 4 USE THE RULER TO THE RIGHT TO MEASURE YOUR BOLTS AND SCREWS. PICTURE VIEWS SHOWN ABOVE ARE 1:1 SCALE AND CAN BE USED TO MATCH BOLT AND SCREW SIZES.
  • Page 35 11-0091 780/1540 HARDWARE KIT 3/12/2018 JH 5/16" X 2-3/4" 5/16" X 3-1/2" HEX HEAD BOLT LAG SCREW QTY: 2 QTY: 2 5/16" WASHER 5/16" QTY: 4 T-NUT QTY: 2 USE THE RULER TO THE RIGHT TO MEASURE YOUR BOLTS AND SCREWS. PICTURE VIEWS SHOWN ABOVE ARE 1:1 SCALE AND CAN BE USED TO MATCH BOLT AND SCREW SIZES.
  • Page 36 PICTURE DESCRIPTION QTY. 1501 2 X 4 X 13" ANGLE SUPPORT 2-4-1300-AS 2 X 4 X 14-3/4" PICNIC TABLE TOP SUPPORT 2-4-1475-PTTS NOT USED 2 X 4 X 17" LADDER STEP 2-4-1700-LS 2 X 4 X 18" ANGLE SUPPORT 2-4-1800-AS NOT USED 2 X 4 X 24"...
  • Page 37 PICTURE DESCRIPTION QTY. 2 X 4 X 47-1/2" SAFETY/END PANEL BOARD 2-4-4750-SBEP 2 X 4 X 58" SWING BEAM CROSS MEMBER 2-4-5800-CM NOT USED 2 X 4 X 66" LADDER RIGHT SIDE 2-4-6600-LRS NOT USED 2 X 4 X 66" LADDER LEFT SIDE 2-4-6600-LLS...
  • Page 38 PICTURE DESCRIPTION QTY. 2 x 4 x 70" REAR TOP PANEL BOARD 2-4-7000-RTPB 2 x 6 x 47-1/2" END SANDBOX/ BOTTOM PANEL BOARD 2-6-4750-ESPB 2 x 6 x 70" FRONT FACE BOARD 2-6-7000-FFB 2 x 6 x 70" SANDBOX BOARD 2-6-7000-SB 4 x 4 x 47-1/2"...
  • Page 39 PICTURE DESCRIPTION QTY. NOT USED 5/4 X 3 X 18-3/4" LADDER BACK 125-3-1875-LB 5/4 X 3 X 23-7/8" ROCK WALL 125-3-2387-RWC 2 NOT USED 5/4 X 3 X 28-1/4" PANEL SLATS 125-3-2825-PS 5/4 X 4 X 40-3/8" DECK SPACER 125-4-4038-DS 5/4 X 6 X 22"...
  • Page 40 PICTURE DESCRIPTION QTY. 5/4 X 6 X 43" PICNIC TABLE & SEAT BOARD 125-6-4300-PTTS 5/4 X 6 X 47-3/8" DECK BOARD 125-6-4737-DB...
  • Page 41 PICTURE DESCRIPTION QTY. 1504 2 X 4 X 18" ANGLE SUPPORT- UPPER LEVEL RAD RIDE SIDE 2-4-1800-ULRDAS 2 X 4 X 18" ANGLE SUPPORT- UPPER LEVEL REAR 2-4-1800-ULRAS 2 X 4 X 21-1/2" ANGLE SUPPORT- UPPER LEVEL SWING SIDE 2-4-2150-ULSAS 2 X 4 X 30-7/16"...
  • Page 42 PICTURE DESCRIPTION QTY. 1 NOT USED 2 X 6 X 30-7/16" SIDE BOTTOM PANEL BOARD 2-6-3043-SBPB 2 X 6 X 42-1/2" REAR BOTTOM PANEL BOARD 2-6-4250-RBPB 2 X 6 X 70" BACK PANEL BOARD 2-6-7000-BPB5 4 X 4 X 23-1/2" SLIDE BLOCK 4-4-2350-SB 4 X 4 X 30-1/2"...
  • Page 43 PICTURE DESCRIPTION QTY. 4 NOT USED 5/4 X 3 X 34-1/2" PANEL SLAT 125-3-3450-PS 5/4 X 4 X 25" RAD RIDE DECK SPACER 125-4-2500-RRDS 5/4 X 4 X 29-1/2" UPPER DECK SPACER 125-4-2950-UDS 5/4 X 4 X 35-1/2" REAR DECK SPACER 125-4-3550-RDS 5/4 X 4 X 63"...
  • Page 44 PICTURE DESCRIPTION QTY. 1506 1 X 4 X 30-1/2" ROOF FINISHER 1-4-3050-RF 1 X 4 X 30-1/2" ROOF STARTER 1-4-3050-RS 1 X 5 X 30-1/2" ROOF BOARD 1-5-3050-RB 1 X 6 X 30-1/2" ROOF PEAK 1-6-3050-RP NOT USED 2 X 4 X 18" CLOSE OUT BOARD 2-4-1800-COB...
  • Page 45 PICTURE DESCRIPTION QTY. 2 X 4 X 51-1/8" ROOF SUPPORT RIGHT 2-4-5113-RSR 4 X 4 X 33-5/16" UPPER LEVEL CENTER POST 4-4-3331-ULCP 4 X 4 X 59-1/2" LOWER LEVEL CENTER POST 4-4-5950-LLCP 4 X 4 X 60-1/4" LAG POST WOOD ROOF LEFT 4-4-6025-LPWL RIGHT HAS...
  • Page 46 PICTURE DESCRIPTION QTY. 1509N 2 X 4 X 29" BRIDGE DECK 2-4-2900-BD 2 X 4 X 36-3/4" SAFETY BOARD WITH CHAIN HOLES 2-4-3675-SBH 2 X 4 X 36-3/4" SAFETY BOARD 2-4-3675-SB 2 X 4 X 66" RAIL 2-4-6600-R 2 X 6 X 36-3/4" BOTTOM PANEL BOARD/SANDBOX BOARD...
  • Page 47 PICTURE DESCRIPTION QTY. 5/4 X 3 X 28-1/2" PANEL SLAT 125-3-2850-PS 5/4 X 4 X 29-3/8" DECK SPACER 125-4-2937-DS 5/4 X 4 X 36-1/2" DECK BOARD 125-4-3650-DB...
  • Page 48 PICTURE DESCRIPTION QTY. 1509W 1 X 3 X 36-3/4" ROOF PEAK BOARD 2 1-3-3675-RPB2 1 X 4 X 36-3/4" ROOF PEAK BOARD 1 1-4-3675-RPB1 1 X 5 X 36-3/4" ROOF BOARD 1-5-3675-RB 1 X 4 X 36-3/4" ROOF FINISHER 1-4-3675-RF 1 X 4 X 36-3/4"...
  • Page 49 PICTURE DESCRIPTION QTY. 1514 4 X 4 X 70" MONKEY BAR RUNNER-LEFT 4-4-7000-MBRL 4 X 4 X 70" MONKEY BAR RUNNER-RIGHT 4-4-7000-MBRR 4 X 4 X 86-1/4" MONKEY BAR LADDER 4-4-8650-MBL 4 X 4 X 70" LOWER LEVEL UNDER DECK SUPPORT 4-4-7000-MBS...
  • Page 50 PICTURE DESCRIPTION QTY. 1528 1 X 4 X 29.29" LEFT ROOF FINISHER FRONT 1-4-2929-RFFL 1-4-2929-RFFR RIGHT 1 X 4 X 76-7/8" ROOF STARTER REAR 1-4-7688-RSR 1 X 4 X 76-7/8" ROOF STARTER FRONT 1-4-7688-RSF 1 X 4 X 76-7/8" ROOF FINISHER REAR 1-4-7688-RFR 3 NOT USED...
  • Page 51 PICTURE DESCRIPTION QTY. 1 X 4 X 12-1/4" WALL PANEL BOARD 1-4-1225-WPB 1 X 4 X 15-3/4" WALL PANEL BOARD 1-4-1575-WPB 1 X 4 X 19-5/16" WALL PANEL BOARD 1-4-1931-WPB 5/4 X 5 X 10.81" ROOF PANEL PEAK SUPPORT 125-5-1081-RPPS 5/4 X 6 X 10"...
  • Page 52 PICTURE DESCRIPTION QTY. 2 X 4 X 22.75" WALL PANEL SUPPORT LEFT (1 HOLE ON ON CENTER) 2-4-2275-WPSL RIGHT 2-4-2275-WPSR 2 X 4 X 35.15" LEFT ROOF SUPPORT (1 HOLE OFFSET) 2-4-3515-RSL 2-4-3515-RSR RIGHT NOT USED 2 X 4 X 69.75" ROOF FINISHER SUPPORT (2 HOLES ON...
  • Page 53 PICTURE DESCRIPTION QTY. 1535 1 X 2 X 10" WINDOW BATTEN 1-2-1000-WB 1 X 2 X 17-1/2" WINDOW BATTEN 1-2-1750-WB 1 X 4 X 10-1/4" WINDOW PANEL BOARD 1-4-1025-WPB 1 X 4 X 11-1/8" WINDOW PANEL BOARD 1-4-1113-WPB 1 X 4 X 16-1/2" WINDOW PANEL BOARD 1-4-1650-WPB...
  • Page 54 PICTURE DESCRIPTION QTY. 1 X 4 X 26" WINDOW PANEL BOARD 1 X 4 X 2600-WPB 1 X 4 X 27" WINDOW PANEL BOARD 1-4-2700-WPB 1 X 4 X 28" WINDOW PANEL BOARD 1-4-2800-WPB 1 X 5 X 38-7/8" ROOF BOARD 1-5-3888-RB 1 X 5 X 38-7/8"...
  • Page 55 PICTURE DESCRIPTION QTY. 5/4 X 4 X 63" DECK SPACER 125 X 4 X 6300-DS 5/4 X 4 X 69-7/8" DECK BOARD 125-4-6988-DB 5/4 X 6 X 12-7/8" ROOF PEAK SUPPORT 125-6-1281-RPS 5/4 X 6 X 69-7/8" DECK BOARD 125-6-6988-DB 2 X 4 X 14"...
  • Page 56 PICTURE DESCRIPTION QTY. 2 X 4 X 29-1/2" SUN SUPPORT 2-4-2950-SS 2 X 4 X 35-1/2" CENTER DECK SUPPORT 2-4-3550-CDS 2 X 4 X 35-1/2" TOP PANEL BOARD 2-4-3550-TPB 2 X 4 X 39" PANEL AND DECK SUPPORT 2-4-3900-PDS 2 X 4 X 46-3/8" REAR ROOF SUPPORT LEFT 2-4-4635-RRSL...
  • Page 57 PICTURE DESCRIPTION QTY. 2 X 4 X 47-7/8" FRONT ROOF SUPPORT RIGHT 2-4-4788-FRSR 2 X 4 X 57" LADDER SIDE LEFT 2-4-5700-LSL 2 X 4 X 57" LADDER SIDE RIGHT 2-4-5700-LSR 2 X 4 X 70" TRANSITION STEP 2-4-7000-DS 2 X 4 X 70" TOP PANEL BOARD 2-4-7000-TPB...
  • Page 58 PICTURE DESCRIPTION QTY. 2 X 6 X 70" FRONT TOP PANEL BOARD 2-6-7000-FTPB 2 X 6 X 70" SANDBOX BOARD 2-6-7000-SB 4 X 4 X 35-1/2" MONKEY BARS MOUNT 4-4-3550-MBM 4 X 4 X 28-1/2" CONNECTOR POST 4-4-2850-CP 4 X 4 X 32" CENTER POST 4-4-3200-CP 4 X 4 X 87-1/2"...
  • Page 59 PICTURE DESCRIPTION QTY. 2 X 13 X 46-1/2" ROOF PANEL RIGHT ASSEMBLY 2-13-4652-RPRA 1535F 2 X 6 X 70" SANDBOX BOARD 2-6-7000-SB 2 X 6 X 78" SIDE SANDBOX BOARD LEFT 2-6-7800-SBL 2 X 6 X 78" SIDE SANDBOX BOARD RIGHT 2-6-7800-SBR...
  • Page 60 PICTURE DESCRIPTION QTY. 1539 FOOTER KIT (SUPPORT BASE) IF YOU PURCHASED A PLAYSET ALL PARTS ON 2 X 4 X 7" THIS PAGE ARE INCLUDED. FOOTER 1 7" 2-4-0700-F1 IF YOU DID NOT PURCHASE A PLAYSET YOU WILL HAVE TO PURCHASE ONE 2 X 4 X 8' PRESSURE TREATED BOARD TO MAKE THESE PARTS.
  • Page 61 PICTURE DESCRIPTION QTY. 1540 KIT PLAYSET PARTS INCLUDED ONLY IF A 1500 SERIES PLAYSET WAS PURCHASED 2 X 4 X 4" (AMBER STAINED) SLIDE BRACKET BLOCK 2-4-0400-SBB 2 X 4 X 70" SLIDE BRACKET SUPPORT 2-4-7000-SBS 780 KIT PLAYSET PARTS INCLUDED ONLY IF A 700 SERIES PLAYSET WAS PURCHASED 2 X 4 X 4"...
  • Page 62 PICTURE DESCRIPTION QTY. 4 X 4 X 108" CORNER POST- FRONT 4 X 4 X 120" CORNER POST- MIDDLE 4 X 4 X 120" CORNER POST- REAR 4 X 4 X 108" SWING LEG 4 X 6 X 120" SWING BEAM 4 X 4 X 96"...
  • Page 63 PICTURE DESCRIPTION QTY. WAVE SLIDE 03-0016-G SUPER SCOOP 03-0007-G TURBO TUBE SLIDE 03-0019...
  • Page 64 PICTURE DESCRIPTION QTY. ROCK WALL ROPE LADDER ROPES SWING W/CHAINS 04-0002 TRAPEZE W/CHAINS 04-0006 CHANNEL BRACKET 11-5018...
  • Page 65 PICTURE DESCRIPTION QTY. SWING PLATE 11-5002 CLIMBING ROCK (5 ROCKS ARE IN BAG) 07-0008 A-FRAME SWING BRACKET 11-5010 HARDWARE HARDWARE BOXES: BOXES 1501,1504, 1506, 1509N, 1509W, 1514, 1528, 1535, 1535F, 11-2027 INSTRUCTIONS...
  • Page 66 PICTURE DESCRIPTION QTY. GREEN BRACKET 11-5013 SPRING CLIP 11-4003 IRON DUCTILE SWING HANGER 11-4012...
  • Page 67 PICTURE DESCRIPTION QTY. UNASSEMBLED DORMER (1529 BOX) UNASSEMBLED CHIMNEY (1529 BOX) TELESCOPE 07-0001...
  • Page 68 PICTURE DESCRIPTION QTY. PLASTIC SUNBURST 07-0028-G FRONT PLASTIC ARCH 07-0027-G DORMER WINDOW 07-0029-G SOLAR WALL LIGHT 09-2003...
  • Page 69 PICTURE DESCRIPTION QTY. (NOT SHOWN) MANUFACTURER LOGO PLATE CLATTER BRIDGE MESH PANEL (NOT SHOWN) (PAIR) 06-2004 SAFETY (NOT SHOWN) WARNING PLATE 06-2004 GROUND STAKE (PAIR) 07-0016-P TIC TAC TOE (UNASSEMBLED) 07-0010 STEERING WHEEL 07-0004...
  • Page 70 PICTURE DESCRIPTION QTY. SAFETY HANDLE (2 HANDLES ARE IN ONE BAG) 07-0005 PLASTIC DORMER SUNBURST 07-0031-G UNASSEMBLED DORMERS (1537 BOX) BINOCULARS 07-0003 CHALKBOARD 07-0018...
  • Page 71 PICTURE DESCRIPTION QTY. CROWN 07-0019 PLASTIC WINDOW 07-0013-G 8-5/8"W X 6-1/2"H MONKEY BAR PLATE 11-5014 1-5/16" DIA. X 19-3/4L MONKEY 11-5104 16" SAFETY HANDLE 08-0001 96" CHAIN SECTION...
  • Page 72 STEP 1: ATTACHING T-NUTS TO THE CORNER POSTS 1: THIS STEP IS CRITICAL TO BUILDING THE FORT PROPERLY. IF ANY MISTAKES ARE MADE HERE, YOU WILL NEED TO DIS-ASSEMBLE AND THEN RE-ASSEMBLE TO MAKE YOUR CORRECTIONS. 2: MAKE SURE HOLES ARE FREE OF ANY OBSTRUCTIONS. USE A BOLT TO CLEAN OUT ANY DEBRIS. 3: LAY OUT EACH OF THE 4 X 4 X 108"...
  • Page 73 STEP 2: SWING BEAM PLATE 1: PLACE THE SWING BEAM PLATE ON TOP OF THE SWING BEAM MOUNT, LINING UP THE PILOT HOLES. 2: FASTEN THE SWING BEAM PLATE TO THE SWING BEAM MOUNT USING 3/8" X 3-1/2" CARRIAGE BOLTS ON TOP AND 3/8" LOCK NUTS WITH 3/8" WASHERS FROM UNDERNEATH. USE BOLT CAPS TO COVER ANY EXPOSED THREADS.
  • Page 74 STEP 3: ASSEMBLING THE RIGHT SIDE FRAME 1: LAY THE RIGHT SIDE CORNER POSTS ON THE GROUND IN THEIR PROPER ORIENTATION. 2: LAY THE 2 X 6 X 78" SIDE SANDBOX BOARD- RIGHT ON TOP OF THE RIGHT SIDE CORNER POSTS AT THE BOTTOM OF THE CORNER POSTS.
  • Page 75 STEP 4: ASSEMBLING THE LEFT SIDE FRAME 1: LAY THE LEFT SIDE CORNER POSTS ON THE GROUND IN THEIR PROPER ORIENTATION. 2: LAY THE 2 X 6 X 78" SIDE SANDBOX BOARD - LEFT ON TOP OF THE LEFT SIDE CORNER POSTS AT THE BOTTOM OF THE CORNER POSTS.
  • Page 76 STEP 5: DECK SUPPORTS YOU WILL NEED AN EXTRA PERSON FOR THIS STEP 1: WITH HELP, STAND UP THE LEFT AND RIGHT SIDE ASSEMBLIES. 2: FASTEN THE 2 X 4 X 70" DECK SUPPORTS TO THE HOLES AT 54-3/4" WITH 5/16" X 4-1/2" HEX BOLTS AND 5/16"...
  • Page 77 STEP 6: FRONT FRAME ASSEMBLY 1: PLACE THE 2 X 6 X 70" SANDBOX BOARD ON THE FRONT OF THE CORNER POSTS. THE HOLES IN THE SANDBOX BOARD SHOULD BE OFFSET UP. 2: USE 5/16 X 4-1/2" HEX BOLTS AND 5/16" WASHERS TO ATTACH THE TOP HOLES OF THE SANDBOX BOARD TO THE T-NUTS INSTALLED IN THE CORNER POSTS.
  • Page 78 STEP 7: REAR FRAME ASSEMBLY 1: PLACE THE 2 X 6 X 70" SANDBOX BOARD ON THE BOTTOM REAR OF THE CORNER POSTS. THE HOLES IN THE SANDBOX BOARD MUST BE OFFSET UP. 2: USE 5/16 X 4-1/2" HEX BOLTS AND 5/16" WASHERS TO ATTACH THE TOP HOLES OF THE SANDBOX BOARD TO THE T-NUTS INSTALLED IN THE CORNER POSTS.
  • Page 79 STEP 8: LEVELING THE PLAY SET AND LAGS 1: INSTALL LAG SCREWS ONLY IN THE FOUR 2 X 6 BOARDS AT DECK HEIGHT AT THIS TIME. SQUARE EACH OF THESE FOUR BOARDS TO THE CORNER POSTS AND THEN INSTALL THE LAG SCREWS.
  • Page 80 STEP 9: BOTTOM PANEL BOARDS 1: PLACE THE 2 X 4 X 14" BOTTOM PANEL BOARD ON TOP OF THE 2 X 6 PANEL BOARD AND FASTEN TO THE CORNER POSTS WITH 5/16" X 3-1/2" LAG SCREWS WITH 5/16" WASHERS. 2 X 4 X 14"...
  • Page 81 STEP10: ANGLE SUPPORTS 1: TWO 2 X 4 X 13" ANGLE SUPPORTS ARE MOUNTED UNDER THE DECK ON THE RIGHT SIDE OF THE PLAY SET TO THE 2 X 6 BOTTOM PANEL BOARD. THE TOP OF THE ANGLE SUPPORT SHOULD BE FLUSH OR LOWER THAN THE TOP OF THE DECK SUPPORT.
  • Page 82 STEP 11: DECK SPACERS 1: PLACE THE 5/4 X 4 X 40-3/8" DECK SPACER AT ONE END OF THE FORT. CENTER THE BOARD BETWEEN THE CORNER POSTS AND ATTACH IT WITH 2" WOOD SCREWS THROUGH THE PREDRILLED HOLES INTO THE DECK SUPPORT BELOW.
  • Page 83 STEP 12: CENTER DECK SUPPORT 1: FIND THE 2 X 4 X 70" CENTER DECK SUPPORT WITHOUT HOLES. 2: FROM THE UNDERSIDE OF THE DECK SPACERS THAT WERE PREVIOUSLY INSTALLED, PLACE THE CENTER DECK SUPPORT AT THE CENTER OF THE DECK SPACERS (USE THE HOLE ON CENTER AS A GUIDE) AND DRAW A LINE ON THE OUTSIDE OF THE FORT TO REPRESENT A CENTER LINE.
  • Page 84 STEP 13: DECK BOARDS 1: START WITH A 5/4 X 6 X 47-3/8" DECK BOARD AT ONE END OF THE FORT. CENTER THE BOARD BETWEEN THE FRONT FACE BOARD AND THE REAR BOTTOM PANEL BOARD AND ATTACH IT WITH 2" WOOD SCREWS THROUGH THE PREDRILED HOLES AND INTO THE DECK SUPPORTS BELOW.
  • Page 85 STEP 14: CONNECTOR POSTS 1: TWO 4 X 4 x 28.5" CONNECTOR POSTS WILL BE USED TO EXTEND THE FRONT CORNER POSTS TO ACCEPT THE LOWER LEVEL PLATFORM. 2: MAKE SURE TO INSTALL THE T-NUTS INTO THE CONNECTOR POSTS SIDE HOLES AS SHOWN IN THE DRAWING BELOW BEFORE MOUNTING IT TO THE FRONT POSTS.
  • Page 86 STEP 15: LOWER LEVEL CORNER POST T-NUTS 1: THIS STEP IS CRITICAL TO BUILDING THE LOWER LEVEL PROPERLY. IF ANY MISTAKES ARE MADE HERE, YOU WILL NEED TO DIS-ASSEMBLE AND THEN RE-ASSEMBLE TO MAKE YOUR CORRECTIONS. 2: MAKE SURE HOLES ARE FREE OF ANY OBSTRUCTIONS. USE A BOLT TO CLEAN OUT ANY DEBRIS. 3: LAY OUT EACH OF THE 4 X 4 X 87-1/2"...
  • Page 87 STEP 16: LOWER LEVEL PANEL BOARDS 1: PLACE THE 2 X 4 X 35.5" TOP PANEL BOARD FLUSH TO THE CONNECTOR POST. ATTACH THE COUNTERSUNK HOLE OF THE TOP PANEL BOARD TO THE T-NUT INSTALLED IN THE CONNECTOR POST USING ONE 5/16" X 4-1/2" HEX BOLT AND ONE 5/16"...
  • Page 88 STEP 16A: DRILL HOLES FOR BRIDGE CHAINS 1: LOCATE ONE 4 X 4 X 70" LOWER LEVEL UNDER DECK SUPPORT AND ONE 2 X 6 X 70" FRONT FACE BOARD. 2: MEASURE AS SHOWN BELOW AND MAKE MARKS ON EACH BOARD. 3: PLACE A SCRAP PIECE OF WOOD UNDER THE BOARD BEFORE YOU DRILL THE 1"...
  • Page 89 STEP 17: LOWER LEVEL FRONT FRAME ASSEMBLY 1: PLACE THE 2 X 6 X 70" FRONT TOP PANEL BOARD ON THE FRONT OF THE LOWER LEVEL CORNER POSTS. THE HOLES IN THE FRONT TOP PANEL BOARD SHOULD BE OFFSET UP. 2: USE 5/16 X 4-1/2"...
  • Page 90 STEP 18: LEVELING THE LOWER LEVEL FRAME 1: INSTALL LAG SCREWS ONLY IN THE THREE 2 X 6 BOARDS AT DECK HEIGHT AT THIS TIME. SQUARE EACH OF THESE THREE BOARDS TO THE LOWER LEVEL CORNER POSTS AND THEN INSTALL THE LAG SCREWS. THIS IS TO MAKE THE STRUCTURE RIGID FOR THE LEVELING AND SQUARING PROCESS.
  • Page 91 STEP 19: LOWER LEVEL DECK SUPPORTS 1: FASTEN THE 2 X 4 X 39" PANEL AND DECK SUPPORTS TO THE HOLES AT 45" WITH 5/16" X 4-1/2" HEX BOLTS AND 5/16" WASHERS FROM THE INSIDE OF THE FORT. 5/16" WASHER 5/16"...
  • Page 92 STEP 20: LOWER LEVEL UNDER DECK SUPPORTS 1: PLACE THE 4 X 4 X 70" LOWER LEVEL UNDER DECK SUPPORT DIRECTLY UNDERNEATH THE LOWER LEVEL DECK SUPPORTS. MAKE SURE THE CHAIN HOLES ARE OFFSET TO THE RIGHT SIDE OF THE PLAY SET. ATTACH THE UNDER DECK SUPPORT TO THE LOWER LEVEL CORNER POSTS WITH 3/8"...
  • Page 93 STEP 21: LOWER LEVEL DECK SPACER AND DECK BOARD 1: PLACE THE 5/4 X 4 X 63" DECK SPACER AT THE FRONT OF THE LOWER LEVEL FORT. CENTER THE BOARD BETWEEN THE LOWER LEVEL CORNER POSTS AND FLUSH TO THE FRONT FACE BOARD AND ATTACH IT WITH 2" WOOD SCREWS THROUGH THE PREDRILLED HOLES INTO THE LOWER LEVEL DECK SUPPORT BELOW.
  • Page 94 STEP 22: CENTER DECK SUPPORT 1: FIND THE 2 X 4 X 35.5" CENTER DECK SUPPORT WITHOUT HOLES. 2: FROM THE UNDERSIDE OF THE DECK SPACER AND DECK BOARD THAT WERE PREVIOUSLY INSTALLED, PLACE THE CENTER DECK SUPPORT AT THE CENTER OF THE DECK SPACER AND DECK BOARD (USE THE HOLE ON CENTER AS A GUIDE) CENTER THE 2 X 4 X 70"...
  • Page 95 STEP 23: LOWER LEVEL DECK BOARDS 1: START WITH A 5/4 X 6 X 69.875" DECK BOARD AT THE BACK OF THE LOWER LEVEL FORT. CENTER THE BOARD BETWEEN THE BOTTOM PANEL BOARDS AND ATTACH IT WITH #8 X 2" WOOD SCREWS THROUGH THE PREDRILLED HOLES AND INTO THE DECK SUPPORTS BELOW.
  • Page 96 STEP 24: PANEL SUPPORTS 2: PLACE THE 2 X 4 X 39" PANEL AND DECK SUPPORT ON TOP OF THE 2 X 6 BOTTOM PANEL BOARD WITH OFFSET HOLES DOWN AND FASTEN TO THE CORNER POSTS WITH 5/16" X 3-1/2" LAG SCREWS AND 5/16"...
  • Page 97 STEP 25: LADDER ASSEMBLY 1: LAY ONE 2 X 4 X 57” LADDER SIDE ON A FLAT SURFACE WITH CHANNELS FACING DOWN. PLACE THE BARREL OF A T-NUT IN THE HOLE AT THE TOP OF THE LADDER SIDE, AND SECURE WITH A HAMMER.
  • Page 98 STEP 26: LADDER TO FORT 1: PLACE THE LADDER INTO POSITION ON THE FRONT SIDE OF THE LOWER LEVEL FORT AS SHOWN BELOW.CENTER THE LADDER HORIZONTALLY ON THE 2 X 6. CENTER THE 90 BRACKETS VERTICALLY ON THE 2 X 6. USE THE HOLES IN THE LADDER BRACKETS AS A TEMPLATE TO DRILL 3/8"...
  • Page 99 STEP 27: LOWER LEVEL STEPS 1: PLACE THE TOP OF ONE 2 X 4 X 70" LOWER LEVEL STEP FLUSH WITH THE TOP OF THE MAIN LEVEL DECK BOARDS. LOWER LEVEL STEPS HAVE TWO HOLES THAT ARE CENTERED. 2: ATTACH THE UPPER LEVEL STEP TO THE POSTS WITH TWO 5/16" X 3-1/2" LAG SCREWS AND TWO 5/16"...
  • Page 100 STEP 28: MAIN LEVEL CENTER POST 1: LOCATE THE 4 X 4 X 32" CENTER POST AND PLACE IT CENTERED BEHIND THE HOLE IN THE TOP PANEL BOARD. 2: HAMMER A T-NUT INTO THE HOLE IN THE BACK SIDE OF THE CENTER POST. FASTEN THE CENTER POST TO THE TOP PANEL BOARD WITH A 5/16"...
  • Page 101 STEP 29: ROCK WALL 1: FIND TWO 2 X 4 X 66" ROCK WALL SIDES. 2: POSITION THE ROCK WALL SIDES SO THAT THE HOLES IN THE BOARDS ARE BOTH FACING THE SAME WAY. 3: INSERT T-NUTS INTO THE INSIDE OF THE ROCK WALL SIDES AND SET WITH A HAMMER. T-NUT 2 X 4 X 66"...
