WIRING
UNIT 82066 | 120V | USA
BLACK
WHITE
GREEN
1
Cord Assembly
2
Bushing/Strain Relief
3
Rocker Switch
4
Thermal Cutout
5
Thermostat
6
500W Heating Element
7
Terminal Splice
UNITS 82110, 81003, 84580 | 230V | CONT. EUROPE, AU, UK
BROWN
BLUE
GREEN/YELLOW
1
Cord Assembly
2
Bushing/Strain Relief
3
Rocker Switch
4
Wire Assembly
5
Thermostat
6
500W Heating Element
1
2
7
1
2
3
4
4
3
1A
1
2A
2
2
1
6
5
FLAG
FLAG
6
