Sony KV-C2161D Service Manual

KV-C2161D C2561D C2961D
SERVICE MANUAL
[ K V - C 2161 D, KV-C 2561 D, KV-C 2961 D]
Television system
B / G / H
Color system
P A L , S E C A M , NTSC3.58, NTSC4.43
Stereo system
G E R M A N stereo
Cha nnel coverage
V H F : E2-E12
C A B L E TV (1) :S1-S41
C A B L E TV (2)
Picture tube
Hl-Black Trinitron tube
Approx. 54.5 cm (21 inches) ( K V - C 2161 D)
(Approx. 51 cm picture measured diagonally)
100 ° degree deflection
Approx. 63.5 cm (25 inches) ( K V - C 2561 D)
(Approx. 59 cm picture measured diagonally)
110 ° degree deflection
Approx. 72.4 cm (29 inches) ( K V - C 2961 D)
(Approx. 68 cm picture measured diagonally)
110 ° degree deflection
S P E C I F I C A T I O N S
UHF: E21-E69
: S 01-S 05, M 1-M 10, U 1-U 10
M O D E L S O F T H E
KV-C2161D/C2561D/C2961D
K V - C 2 5 5 1 E / C 2 9 5 1 E
K V - C 2 5 6 0 B / C 2 9 6 0 B
Inputs / Outputs Terminals
REAR
-& 21 pin Euro connector -Inputs for audio and vido signals
(CENELEC standard) -Inputs for RGB
-Outputs of TV video an (audio signals
Q-2/-021 -pin Euro •Inputs for audio and vido signals
connector
-Inputs for S-video
-Outputs for video and aiiio signals
O Audio output(vartable) -phonojacks
FRONT
-Q Video input phono jack
-O Audio inputs (L,R) phono jacks
S-video lnputs-4 pin DIN
Headphone jack : stereo mini jack
-Continued no next page-
TRINITRON COLOR TV
RM-816
AEP Model
K V - C 2 1 6 i D
C/7ass;'s A/o. S C C - F 07 K-A
KV-C2561
Chassis No. SCC-F 07 F-A
KV-C2961
Chassis No. SCC-F 07 E-A
CHASSIS
S A M E S E R I E S
(selectable)
D
D
