King Kooker 94/90TKD Assembly Instructions And Use And Care Manual

Outdoor cookers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
English
94/90TKD AND 94/602
ASSEMBLY INSTRUCTIONS
AND USE AND CARE MANUAL
THE INSTRUCTION MANUAL CONTAINS IMPORTANT INFORMATION
NECESSARY FOR THE PROPER ASSEMBLY AND SAFE USE OF THE APPLIANCE.
READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS BEFORE
ASSEMBLING AND USING THE APPLIANCE. FOLLOW ALL WARNINGS AND
7:30 AM to 3:30 P.M. CST • Monday through Friday
AND WARNINGS COULD RESULT IN FIRE, EXPLOSION, BURN HAZARD OR
CARBON MONOXIDE POISONING WHICH COULD CAUSE PROPERTY DAMAGE,
OUTDOOR COOKERS
MODEL/SERIAL #
INSTRUCTIONS WHEN USING THE APPLIANCE.
KEEP THIS MANUAL FOR FUTURE REFERENCE.
METAL FUSION, INC.
712 St. George Avenue.
Jefferson, LA 70121
If you have any problems or questions
Call Us Toll Free at
1-800-783-3885
(504) 736-0201
www.kingkooker.com
FAILURE TO FOLLOW THESE INSTRUCTIONS
PERSONAL INJURY OR DEATH.
__________

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 94/90TKD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for King Kooker 94/90TKD

Summary of Contents for King Kooker 94/90TKD

  • Page 1 English OUTDOOR COOKERS 94/90TKD AND 94/602 ASSEMBLY INSTRUCTIONS AND USE AND CARE MANUAL __________ MODEL/SERIAL # THE INSTRUCTION MANUAL CONTAINS IMPORTANT INFORMATION NECESSARY FOR THE PROPER ASSEMBLY AND SAFE USE OF THE APPLIANCE. READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS BEFORE ASSEMBLING AND USING THE APPLIANCE.

  • Page 2: Warnings

    DANGER FOR YOUR SAFETY If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, keep away from the appliance and immediately call your Fire Department. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN FIRE OR EXPLOSION WHICH COULD CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
  • Page 3 READ AND UNDERSTAND BEFORE USING THIS PRODUCT Throughout this manual the words appliance, cooker, fryer/boiler, burner and stove will be used interchangeably to refer to the King Kooker Outdoor Cooker. ® This is an ATTENDED appliance. Do NOT leave this appliance unattended while the burner is lit or while heating oil, grease, water or cooking food.
  • Page 4 21) This appliance is not intended for commercial use. 22) Use King Kooker appliances only in accordance with state and local ordinances, ®...

  • Page 5: Table Of Contents

    Additional Suggested Recipes for Model 94/90TKD and 94/602 (Cast Burner) .......

  • Page 6: Warranty

    METAL FUSION, INC. LIMITED ONE-YEAR WARRANTY WHAT THIS WARRANTY COVERS This warranty covers all components of this outdoor cooker to be free from defects in materials and workmanship, with the exceptions stated below. HOW LONG COVERAGE LASTS This warranty runs for one year from the date of purchase. Please keep your receipt with this manual for future reference.

  • Page 7: Owners Registration

    OWNER’S REGISTRATION Dear Customer, Thank you for purchasing a King Kooker ! Please take a moment to fill ® out your registration form and return it to us. We are always happy to hear suggestions and comments from our customers about our products. Completion of this registration allows us to contact you if the need arises.
  • Page 8 TAPE HERE FOLD ________________________ ________________________ Place Stamp ________________________ Here METAL FUSION, INC. 712 St. George Avenue Jefferson, LA 70121 FOLD...

  • Page 9: Section I - Outdoor Cooker Assembly

    THE USE AND CARE MANUAL MUST BE READ AND UNDERSTOOD BEFORE USING THE APPLIANCE Throughout this manual the words appliance, cooker, fryer/boiler, burner and stove will be used interchangeably to refer to the King Kooker Outdoor Cooker. ® TOOLS REQUIRED: SCREWDRIVER, TORQUE WRENCH or ADJUSTABLE WRENCH, LEAK TESTING SOLUTION Before assembling, check that all cooker components are included in the shipping carton.

  • Page 10: Assembly Instructions

    ASSEMBLY INSTRUCTIONS See below illustration for part identification. Also included - 6 bolts, 8 Lockwasher and 8 Nuts Lighting Hole Windshroud Top Frame Figure 1 Jet Pipe Cylinder Collar Cylinder Heat Shield Bottom Frame Wheels, Axles, Lockwashers Tank Ring and Nuts 1.
  • Page 11 6. Locate the three separate heat plate pieces. Lay the plates on a flat surface as shown in Figure 3. Place the rounded inner edge of one plate against the vertical jet pipe located on the bottom frame. The bottom of the plate should be located above the the “bent” prongs when installed (3 “bent” prongs welded to side of jet pipe.) The plate will fit around the “bent” area of the prong using the cutouts provided on the plate. Repeat procedure with the second plate. Align the bolt holes of the first and second plates and attach with bolt, lock washer and nut.

  • Page 12: Hose Assembly Instructions

    HOSE ASSEMBLY INSTRUCTIONS 1. Wrench tighten the 3/8” female flare swivel to the brass adapter. If assembling a hose to a cast burner, determine if your hose has a 3/8” female flare swivel end or a 1/8” male pipe thread end. If your cooker has a 3/8” female flare end, wrench tighten it to the pre-installed half union located on the cast burner. If it has a 1/8” male pipe thread end, tighten the hose fitting into the venturi with a torque wrench, up to a torque of 95 to 105 lb./in. Alternatively, hand tighten securely and then, using a wrench, tighten an additional 1-1 1/2 turns. 2. The hose to burner (brass adapter) connections must be tightened and leak tested. 3.

  • Page 13: Section Ii - Use And Care

    212°F(100°C). The temperature of hot oil should never be allowed to exceed 350°F(177°C). IMPORTANT: Oil can ignite at high temperatures. Most King Kooker ® thermometers have a Red Zone above 350°F(177°C) to signify Danger. Never allow the temperature to exceed 350°F(177°C).

  • Page 14: Determining Proper Fill Levels For Cooking Vessels

    This is the amount of cooking liquid the vessel is to be filled with to cook the food product. LP GAS CYLINDER INFORMATION King Kooker ® Outdoor Cookers are manufactured for use with 20lb. (9 kg) LP Gas Cylinders. Important information to remember about LP Gas cylinders include: Always read and follow the cylinder manufacturer’s instructions.

  • Page 15: Connection Instructions

    CONNECTION INSTRUCTIONS Check that your hose assembly valve is set to not allow gas flow. Turn the manual valve(s) clockwise until it stops. This is the OFF position. Attach the regulator to the cylinder valve by turning the Type 1 fitting clockwise. Hand tighten with the regulator positioned upright.

  • Page 16: Placement Instructions

    PLACEMENT INSTRUCTIONS 1. Never operate this appliance within 10ft. (3.05m) of any structure, combustible material or other gas cylinder. Never operate this appliance within 25ft. (7.5m) of any flammable liquids or vapors 2. There must be no combustibles or roof overhead. 3.

  • Page 17: Lighting And Operating Instructions

    LIGHTING AND OPERATING INSTRUCTIONS THE COOKER MUST NOT BE LIT UNTIL THE PRECEDING PLACEMENT INSTRUCTIONS HAVE BEEN COMPLETELY FOLLOWED. 1. Check that the casting is properly located Turn triangle handle toward ON (Counterclockwise) as per the diagram and that the orifice is VIEW FROM TOP OF properly located in respect to the jet pipe.

  • Page 18: Turning Off And Storing The Cooker After Use

    F(38 C)]. ® After each use turn OFF the King Kooker at the manual valve(s) first, then at the gas cylinder valve. Check to make sure there is no flame and all valves are off. Do not leave the cooker until it has cooled completely.

  • Page 19: Caring For Aluminum And Cast Iron Cookware

    Cleaning of the appliance: Cooker and LP Hose/Regulator: If necessary, remove any oil or liquid which has spilled onto the unit during cooking with mild soapy water on a rag and towel dry. Do not immerse the burner unit or hose and regulator into water as this will cause rust.

  • Page 20: Section Iii - Recipes

    Boiled Seafood! The King Kooker® Way! For a 60 to 100 quart pot, fill 1/2 full of water. Add 4 to 6, 16 ounce King Kooker ® Complete Crab, Shrimp, Crawfish Boil (complete, nothing to add). Bring water to a rolling boil. Add seafood. Gently stir. Cover the pot and return to boil.

  • Page 21: Additional Suggested Recipes For Model 94/90Tkd And 94/602 (Cast Burner)

    94/90TKD or 94/602 with a large pot, see boiling and steaming recipes located on page 20. Blackened Fish Heat a cast iron skillet for at least ten minutes on your King Kooker ® . Allow the skillet to get almost white hot -- hot enough to see the “flame circle” in the center of the skillet. This recipe produces lots of smoke.

  • Page 22: Section Iv - Frequently Asked Questions And Answers

    SECTION IV READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE USING YOUR KING KOOKER ® PRODUCT FREQUENTLY ASKED QUESTIONS AND ANSWERS What is the problem if the cooker takes too long or will not heat oil or cooking ingredients to desired temperature? My cooker’s flame appearance is very weak.
  • Page 23 NOTES...
  • Page 24 KING GRILLERDINE ® , KING KOOKER ® , the KING KOOKER ® logo, THE KING ® THE KING OF OUTDOOR COOKING ® , MR. OUTDOORS ®...

This manual is also suitable for:

94/602
