OUTDOOR COOKERS
ASSEMBLY INSTRUCTIONS
AND
USE AND CARE MANUAL
__________
MODEL/SERIAL #
READ OPERATING INSTRUCTIONS BEFORE USING YOUR COOKER.
RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
METAL FUSION, INC.
712 St. George Avenue.
Jefferson, LA 70121
For Questions and Information
Call Us Toll Free at
1-800-783-3885
8:00 AM to 3:30 P.M. CST • Monday through Friday
(504) 736-0201
WARNING
FAILURE TO FOLLOW THESE INSTRUCTIONS
AND WARNINGS COULD RESULT IN FIRE OR EXPLOSION WHICH
COULD CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR
DEATH.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OUTDOOR COOKERS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for King Kooker OUTDOOR COOKERS

Summary of Contents for King Kooker OUTDOOR COOKERS

  • Page 1 ® OUTDOOR COOKERS ASSEMBLY INSTRUCTIONS USE AND CARE MANUAL __________ MODEL/SERIAL # READ OPERATING INSTRUCTIONS BEFORE USING YOUR COOKER. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE. METAL FUSION, INC. 712 St. George Avenue. Jefferson, LA 70121 For Questions and Information Call Us Toll Free at 1-800-783-3885 8:00 AM to 3:30 P.M.

  • Page 2: Warnings

    FOR YOUR SAFETY If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. Open lid if applicable. 4. If odor continues, keep away from appliance, and immediately call your gas supplier or your fire department. WARNING Do not store spare LP cylinder within 10 feet (3.05 m) of this appliance.
  • Page 3 WARNING READ AND UNDERSTAND BEFORE USING THIS PRODUCT (Throughout this manual the words appliance, cooker, burner and stove will be used This is an ATTENDED appliance. Do NOT leave this appliance unattended while heating oil, grease or water, cooking food or when hot after use [oil, grease or water above 100˚...
  • Page 4 18) This appliance is not intended for commercial use. 19) Use King Kooker appliances only in accordance with state and local ordinances, or in the absence of local codes, with the National Fuel Gas Code, ANSIZ223.1/NFPA 54, Storage and Handling of Liquefied Petroleum Gases, ANSI/NFPA 58 or CSA B149.1, Natural Gas and...

  • Page 5: Table Of Contents

    11” Cast Cooker Assembly ..............14 Directions for Using the King Kooker Steamer/Fryer Stand and Steamer Plate and Lifting Handle ..... . . 14 Special Leg and Shelf Assembly Instructions For Specific Models: 95 PKP Leg Assembly.

  • Page 6: Warranty

    METAL FUSION, INC. LIMITED ONE-YEAR WARRANTY WHAT THIS WARRANTY COVERS This warranty covers all components of this outdoor cooker to be free from defects in materials and workmanship, with the exceptions stated below. HOW LONG COVERAGE LASTS This warranty runs for one year from the date of purchase. WHAT IS NOT COVERED This warranty does not cover the following: Incidental and Consequential Damages.

  • Page 7: Owners Registration

    OWNER’S REGISTRATION ® Dear Customer, Thank you for purchasing a King Kooker ! Please take a moment to fill out ® your registration form and return it to us. We are always happy to hear suggestions and comments from our customers about our products. Completion of this registration allows us to contact you if the need arises.
  • Page 8 TAPE HERE FOLD ________________________ ________________________ Place Stamp ________________________ Here METAL FUSION, INC. 712 St. George Avenue Jefferson, LA 70121 FOLD...

  • Page 9: Outdoor Cooker Assembly

    THE USE AND CARE MANUAL MUST BE READ AND UNDERSTOOD BEFORE USING THE APPLIANCE (Throughout this manual the words appliance, cooker, burner and stove will be used interchangeably to refer to the King Kooker Outdoor Cooker.) ASSEMBLY INSTRUCTIONS FOR COOKERS WITH CAST IRON BURNERS NOTE: The following are general instructions for 5-6”...
  • Page 10 Figure 2 HOSE WITH FEMALE FITTING AND ADJUSTABLE REGULATOR. COOKING POT ADJUSTABLE REGULATOR TYPE 1 CONNECTION VENTURI TUBE HALF UNION SHUTTER BURNER 20 lb. LP Gas Cylinder 3/8 FEMALE FLARE SWIVEL The air shutter and half union as pictured should already be assembled to the casting. Check that fitting is tightened to the venturi tube and that the elbow points downward.

  • Page 11: Jet Burner Assembly Instructions

    JET BURNER ASSEMBLY INSTRUCTIONS TOOLS REQUIRED: ADJUSTABLE WRENCH, LEAK TESTING SOLUTION Before assembling, check that all cooker components are included in the shipping carton, as per Figure 4. Read and understand assembly instructions. Figure 4 Jet Burner Assembly ADJUSTABLE REGULATOR TYPE 1 CONNECTION BRASS ADAPTER 3/8 FEMALE...

  • Page 12: Camp Stove Assembly Instructions

    CAMP STOVE ASSEMBLY INSTRUCTIONS TOOLS REQUIRED: ADJUSTABLE WRENCH LEAK TESTING SOLUTION Procedures for assembly of all Camp Stoves is the same, only the number of burners vary. Place burner frame on side so that the CASTING VENTURI casting ends are turned upward. TUBES AIR SHUTTERS Loosen nuts on bottoms of castings and...

  • Page 13: 101 Pk Assembly Instructions

    101 PK ASSEMBLY INSTRUCTIONS WARNING The following warnings are to be followed when using the 101 PK in addition to all other warnings listed in this manual. Observe these safety precautions when using a 14.1 or 16.4 oz. portable propane cylinder. Always inspect appliance, propane cylinder and propane connections for damage, dirt or debris before attaching...

  • Page 14: 11" Cast Cooker Assembly

    See leak test instructions before use. Go to the Use and Care Section of this manual for further instructions. KING KOOKER STEAMER/FRYER STAND WITH STEAMER PLATE AND LIFTING HANDLE Directions for using the Lifting Handle: The Lifting Handle is a rectangular shaped chrome accessory.

  • Page 15: Special Leg And Shelf Assembly Instructions For Specific Models

    SPECIAL LEG AND SHELF ASSEMBLY INSTRUCTIONS FOR SPECIFIC MODELS Actual 95 PKP LEG ASSEMBLY Size Required Tools: Adjustable Wrench Match the holes in each leg with the corresponding holes in the cooker. Slide one 1/4” x 1” bolt through each of the twelve holes.

  • Page 16: Camp Stove Leg Assembly

    CAMP STOVE LEG ASSEMBLY Required Tools: Adjustable Wrench Match the holes in each leg with corresponding holes in cooker. Slide 1/4” x 1” bolt through each of the twelve holes. These should be directed inward as in the illustration so 1/4"x1"...

  • Page 17: Cs 5 Leg Assembly

    CS 5 LEG ASSEMBLY Required Tools: Adjustable Wrench Match the holes in each leg with corresponding holes in cooker. Slide 1/4” x 1” bolt through each of the twelve holes. These should be directed inward as in the illustration so that the nuts will be on the inside of the assembly.

  • Page 18: 106 Pk & 106 Pkpt Extension Leg Assembly

    106 PK AND 106 PKPT EXTENSION LEGS ASSEMBLY INSTRUCTIONS Required Tools: Adjustable Wrench Match the holes in each leg with corresponding holes in cooker. Slide one 1/4” x 1” bolt through each of the three holes in each extension leg and cooker leg. These should be directed inward so that the nuts will be on the inside of the assembly.

  • Page 19: Model #Twt Worktable Assembly

    MODEL #TWT WORKTABLE ASSEMBLY Required Tools: Adjustable Wrench This unit is designed to be used as a worktable for the preparation of turkeys for frying and for draining afterwards. It is not intended for any other use. It is to be used only with Deep Fryer Turkey Packages.

  • Page 20: Section Ii - Use And Care Of King Kooker Outdoor Cookers And Accessories

    USE AND CARE (Throughout this manual the words appliance, cooker, burner and stove will be used interchangeably to refer to the King Kooker Outdoor Cooker.) CONNECTION INSTRUCTIONS Check that your 20 lb. LP gas cylinder is not over-filled. The maximum weight of a properly filled cylinder is approximately 38 lbs.

  • Page 21: Placement Instructions

    LP GAS CYLINDER INFORMATION ® King Kooker Outdoor Cookers are manufactured for use with LP Gas Cylinders. Important Information to remember about LP Gas cylinders include: Always read and follow the cylinder manufacturer’s instructions. Make sure that the gas cylinder is not overfilled. The maximum weight of a properly filled 20 lb.

  • Page 22: Lighting Instructions

    212˚F. The temperature of hot oil should never be allowed to exceed 350˚F. IMPORTANT: Oil can ignite at high temperatures. Most King Kooker thermometers have a Red Zone above 350˚F to signify Danger. Never allow the temperature to exceed 350˚F. If the temperature goes above 350˚...
  • Page 23 (Figure 2) (Figure 1) Paper Book Match Paper Book Match Air Shutter (Figure 4) (Figure 3) (Figure 5) WARNING NEVER PUT HANDS OR FACE DIRECTLY OVER BURNER WHILE LIGHTING. FOR MODELS WITH NEEDLE VALVE CONTROLS (Figure 6) Check the casting to make sure that it is set up as per the diagram (Figure 1).

  • Page 24: Special Precautions For Using Outdoor Cookers For Deep Frying

    SPECIAL PRECAUTIONS FOR USING OUTDOOR COOKERS FOR DEEP FRYING Always use a deep fry thermometer when frying and refer to the Instructions for using a Deep Fry Thermometer, page 22. Never cover the pot when cooking with oil. Never fill a fry pan more than half way with oil to prevent overboil.

  • Page 25: Caring For Aluminum And Cast Iron Cookware

    Follow all Lighting Instructions in the Use and Care Manual each time the cooker is used. Check the flame for proper color and appearance. The flame should burn with a primarily blue color. If a strong yellow flame is present, this could indicate an obstruction in the burner/venturi tube. If there is any obstruction or a yellow flame, and the air shutter adjustment has not solved the problem, turn off the cooker and allow time for it to cool.

  • Page 26: Section Iii - Cooking Specialties

    Discoloration, scratching, and dimpling may occur with the use of pots on outdoor cookers. This does not affect the performance of the pot. Do not store used oil inside your aluminum pot. The salt used in cooking can corrode the pot causing the pot to leak.

  • Page 27: Information Regarding Cooking Oil

    Light the cooker as per the instruction manual. Never allow temperature of oil to exceed 350˚F. Always use a deep fry thermometer to monitor the temperature of the oil. Never leave the cooker unattended! Thaw, thowel dry the turkey completely. Coat the turkey inside and out with King Kooker Cajun ®...

  • Page 28: Injecting Techniques

    (breast, thigh, leg). Inject marinade slowly while pulling needle out of meat. This gives even distribution of seasoning. (For best results, insert needle at different angles through the same hole when injecting marinade.) Sprinkle outside of chicken generously with King Kooker® Cajun THIGH Seasoning, rubbing in well.

  • Page 29: King Kooker ® Steamer Package Instructions

    KING KOOKER ® STEAMER PACKAGE INSTRUCTIONS ® The following directions apply specifically to the King Kooker Outdoor Cooker Steamer Packages. ® If you have purchased a King Kooker Steamer Package, read all the following directions and those found previously regarding assembling your cooker before using the product.

  • Page 30: Section Iv - Recipes

    ® Boiled Seafood The King Kooker Way! For a 60 to 100 quart pot, fill 1/2 full of water. Add 4 to 6, 16 ounce King Kooker Crab Boil ® (complete, nothing to add). Bring water to a rolling boil. Add seafood. Gently stir.

  • Page 31: Barbecued Shrimp

    Directions: Brown off the ground meat. Drain off and dispose of the fat. Set aside the ground meat. Cut the bacon into thirds. Fry the bacon. Drain off and dispose of the fat. Set aside the bacon. Pour a few ounces of olive oil into a King Kooker ®...

  • Page 32: Deep Fried Turkey

    King Kooker Injectable Marinade as per the instructions ® on the bottle. Cover the carcass inside and out with King Kooker ® Cajun Seasoning. Pour peanut oil into pot and make sure there is enough oil to cover the turkey, but not enough to overflow when the bird is immersed.

  • Page 33: Deep Fried Boston Butt

    1 gallon will half fill our KK2 Fry Pan, King Kooker Wing ® Sauce of flavor of choice. Heat the cooking oil to 325˚ F. Coat the wings with King Kooker ® Cajun Seasoning. Place some of the wings carefully into the heated cooking oil.
  • Page 34 NOTES...
  • Page 35 NOTES...
  • Page 36 KING GRILLERDINE, KING KOOKER, the KING KOOKER logo, THE KING, THE KING OF OUTDOOR COOKING, and MR. OUTDOORS are trademarks of Metal Fusion, Inc., 712 St. George Avenue, Jefferson, LA 70121 Rev. 10/2002...
