Order of Hard Drive Slots
Remember the order of hard drive slots on the storage system. When you see the "Failure"
health status on Web UI (select Volume Configuration / Physical Disks) or the warning
message from Email notification, remove the failed hard drive in the correct slot.
If you remove the hard drive in the wrong slot, you could suffer data loss.
• Maximum Recording Channels
The maximum number of channels supported by GV-Storage System V2 varies with the
resolution, as listed below. It's highly suggested to keep the total bitrates under 2700 Mbps
for better recording performance.
Video Streaming
Resolution Frame rate
1.3 MP 30 fps
2 MP 30 fps
3 MP 20 fps
4 MP 15 fps
5 MP 10 fps
Complex Scenes
Record
Bitrate
Channels
5 Mbps 534 ch
7 Mbps 385 ch
10.48 Mbps 257 ch
11.65 Mbps 231 ch
16.48 Mbps 163 ch
6
Normal Scenes
Record
Bitrate
Channels
1.73 Mbps 1560 ch
3.86 Mbps 699 ch
3.38 Mbps 798 ch
8.93 Mbps 302 ch
3.16 Mbps 854 ch
