Instruction booklet
GB
English
FTCL 87
TUMBLE DRYER
This symbol reminds you to read this
booklet.
! Keep this instruction booklet on hand in order to refer
to it when necessary. Take it with you when you
move, and should you sell this appliance or pass it
on to another party, make sure that this booklet is
supplied along with the dryer so that the new owner
may be informed about warnings and suggestions on
how the appliance works.
! Read these instructions carefully; the following
pages contain important information on installation
and suggestions on how the appliance works.
To activate your free* 10 Year Parts Guarantee
*Labour charges not included. Terms and conditions apply. Lines open 364 days a year.
Calls are free from a BT landline. Charges from other providers and mobiles may apply.
www.hotpoint.co.uk
Contents
Call free on 0800 597 8557
Levelling
To minimise the risk of fire
Programmes Table
GB
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FTCL 87 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hotpoint FTCL 87

Summary of Contents for Hotpoint FTCL 87

  • Page 1: Table Of Contents

    Maintenance and Care, 6-7 Switching off the electricity Cleaning the filter after each cycle Cleaning the heat pump filter unit Empty the water container after each cycle FTCL 87 Check the drum after each cycle Cleaning the dryer Dryer description, 8 The features...

  • Page 2: Installation

    Installation Where to put your dryer Water drain Place your dryer at a distance from gas If your dryer is installed next to a drain the water can be ● ranges, stoves, heaters, or cook tops plumbed into this drain. This does away with the need to because flames can damage the empty the water container.

  • Page 3: Electrical Connection

    Installation Electrical connections Before you start using your dryer Make sure of the following before you Once you have installed your dryer and before you insert the plug into the the electrical socket: use it, clean the inside of the drum to remove any dust Make sure your hands are dry.

  • Page 4: Warnings

    Warnings ! The appliance has been designed and Check to see if the dryer is empty before ● loading it. built according to international safety The back of the dryer could standards. ● become very hot. Never touch it These warnings are given for safety while in use.
  • Page 5 Warnings To minimise the risk of fire in your or explosive substances. Highly flammable tumble dryer, the following should be substances commonly used in domestic observed: environments including cooking oil, Tumble dry items only if they have been acetone, denatured alcohol, kerosene, ●...

  • Page 6: Maintenance And Care

    Maintenance and Care Switching off the electricity Cleaning the heat pump filter unit ! Unplug your dryer when not using it, Periodically (every 5 drying cycles) remove when cleaning it and during all the heat pump filter unit and clean any maintenance operations.

  • Page 7: Empty The Water Container After Each Cycle

    Maintenance and Care Water container Filter Heat pump filter unit Heat pump filter unit cover Clips Empty the water container after each Cleaning the dryer cycle External parts in metal or plastic and rubber parts ● Pull the container out of the can be cleaned with a damp cloth.

  • Page 8: Dryer Description

    Dryer Description The features Water container Rating plate Model & Serial numbers Filter Heat pump filter unit cover handle (Pull to open) Air intake grille Heat pump filter unit cover Adjustable feet Control panel Empty Water Clean Filter TIMED Light DRYING LEVELS Light Clean Condenser...

  • Page 9: Start And Programmes

    Start and Programmes Dryness Sensing Levels After selecting a programme that has a Sensor Dry option, turn the selection knob to the required dryness sensing level. If the sensing option is not available with your selected programme, the buzzer will beep three times. ! Some sensing programmes do not have all seven dryness level options available.
  • Page 10 Start and Programmes Programmes Table ESSENTIAL PROGRAMMES - Programme Options available Dryness Levels available ✓ (default AUTO highlighted ✓ ✓ ✗ ✗ ✗ ✗ ✓ ✗ ✗ ✗ ✗ ✗ Timed Drying ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ High ✓...
  • Page 11 Start and Programmes Programmes Table EXCLUSIVE PROGRAMMES - Programme Options available Dryness Levels available ✓ (default AUTO highlighted ✓ ✓ ✓ ✓ ✗ ✓ ✓ ✓ ✓ ✗ ✓ ✓ Jeans ✓ ✗ ✓ ✓ ✓ ✗ ✗ ✓ ✓ ✓...
  • Page 12 Start and Programmes Silk This is a programme for drying your delicate silk. ● It can be used for load sizes up to 0.5kg. ● This programme will take about 50 minutes, but may take longer depending on the size and density of the load ●...

  • Page 13: The Controls

    Start and Programmes The Controls PROGRAMMES knob High Heat ● Press this button and a high heat setting is selected and ! Warning, if after pressing the start button, the the light next to the button comes on. If the light programmes knob position is changed, the new position will NOT change the programme selected.

  • Page 14: Laundry

    Laundry Sorting your laundry Drying times Check symbols on clothing labels to make sure The table (see below) presents APPROXIMATE drying ● that the articles can be tumble dried. times in Minutes. Weights refer to dry garments. Sort laundry by fabric type. ●...

  • Page 15: Troubleshooting

    Troubleshooting One day your dryer seems not to be working. Before you call your Service Centre (see Service), go through the following troubleshooting suggestions: Problem: Possible causes / Solution: The tumble dryer won’t start. The plug is not plugged into the socket, or not making contact. ●...

  • Page 16: Assistance And Guarantee

    - in the United Kingdom: 03448 111 606 standard local rate applies - in the Republic of Ireland: 0818 313 413 local Irish rate applies For parts and accessories visit : parts.hotpoint.co.uk/shop Please remember to register your appliance at : www.hotpointservice.co.uk to activate your 10 year parts guarantee.

  • Page 17: Product Data

    Product Data... (EU Regulation 392/2012) Brand Hotpoint Models FTCL87 Rated capacity of Cotton laundry for the standard programme at full load 8 kg Energy efficiency class A+ The weighted Annual Energy Consumption (AE ) 305.4 kWh Consumption per year, based on 160 drying cycles of the standard cotton programme at full and partial load, and the consumption of the low-power modes.
  • Page 20 1 9 5 1 3 3 9 2 9 . 0 0 N 04/2015 - LION fpg . Four Ashes, Wolverhampton...
