PARTS REFERENCE

Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
Type of fi lter medium:
Synthetic cartridge #29000
10
8
7
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
REF. NO.
1
THREADED FILTER HOUSING COLLAR
2 AIR RELEASE VALVE/SEDIMENT RELEASE VALVE
3 VALVE O-RING
4
FILTER HOUSING COVER
5 FILTER HOUSING O-RING
6 FILTER CARTRIDGE
7 PUMP HOSE WITH NUTS
8 TRANSFORMER
18
16
17
13
12
SAVE THESE INSTRUCTIONS
(108GS) MODEL 636G FILTER PUMP ENGLISH 7.5" X 10.3" PANTONE 295U 08/20/2020
10
DESCRIPTION
INLET
15
If the pump was purchased individually,
only these inlet fitting parts are included.
No tools are required for the assembly.
English
1
2
3
4
5
6
3
2
QTY. SPARE PART NO.
10749
1
10460
2
10264
2
10750
1
10325
1
29000
1
11009
2
10985
1
