Installation.

It is essential to follow these three steps
to achieve a correct assembly:
1. Section pieces must only be placed on
the curve area located at the lower part
of the pool (semi-circumferences), sec-
tion pieces must not to be placed on the
straight parts. The lower section pieces
are curve (PI) and they have a flap (page
16). Flexible section parts (PCF) are to be
placed on the upper part of the pool in
both curve and straight parts (page 21).
1 4
2. When closing the pool plate (CH) us-
ing the screws (TC), make sure the screw
heads are facing inwards and the wash-
er and the blind nut outwards (page 19).
Tighten the screws without distorting
the plate.
2 -3
Important: The liner used in the
manufacturing of all our pools, is
developed for exposition to heat
and ultraviolet rays for long pe-
riods. Therefore, under certain
weather and usage conditions,
the liner qualities can vary slight-
ly. The interior liner of the pool is
manufactured from flexible PVC
(thermoplastic). The properties of
this material allow optimal insta-
llations conditions when the out-
side temperature is between 20
°C and 25 °C.
Note: Temperature too low: hard
and rigid liner; later, too small.
Temperature too high: flexible
and elastic liner; later, too big.
