Assembly (continued)
3
Installing support bars
□ Measure the height (H1) at where the vanity will be
located, as illustrated.
□ Add 15-13/16" (401mm) to the height (H1), this
calculated measure is the distance of the bottom of
the 2 support bars to the floor, as illustrated below.
Mark the bottom position of the 2 support bar (D) on
the wall.
H1
D
Support
bar
4
Installing support bars
□ Using a stud finder or equivalent tool, locate at least
1 wall stud and mark its positions on the wall for
each support bar (D). While holding the support bar
(D) in its position against the wall, check that it is
level, then mark 3 positions for 3 holes for each
support bar (D) as indicated. One of the holes must
be right over the wall stud.
□ Note: make sure the distance between the 2 bar is
smaller than 1-9/16'' [40mm].
7 HOMEDEPOT.COM/HOMEDEPOT.CA/HOMEDECORATORS
Please contact 1-800-986-3460 for further assistance.
Proper height of the
holes to be drilled on
the Support Bar.
D
