BEFORE YOU BEGIN
BEFORE YOU BEGIN
·
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
·
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China. reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
·
These instructions contain important care, cleaning, and
warranty information-
please leave instructions for the
consumer.
·
POPLIN
bathroom cabinet adopts
E1 grade birch
wood-based panel
further processing, its harmful emissions will be less than
1.5mg/L.
·
Turn off the water supply.
·
The pluming installation must comply with Water Supply
Regulations/Bye-laws, Building Regulations or any
particular regulations and practices, specified by the local
water company or water undertakers. The installation
should be carried out by a plumber.
·
Before installation carefully inspect the new fixture for any
signs of damage.
·
This product complies with GB 24977-2010.
ORDERING INFORMATION
This installation covers the following products in the POPLIN
range:
POPLIN Cabinet 914mm....................................K-75881T
POPLIN Cabinet 1220mm..................................K-75854T
SAFETY WARNINGS
Kohler products are precision-engineered and should give
continued superior and safe performance, provided:
1. They are installed, commissioned, operated and
maintained in accordance with the recommendations given
in this Manual.
2. Periodic attention is given, as necessary, to maintain the
product in good functional order. Recommended
guidelines are given in the
Carefully inspect the new fixture for any signs of damage.
When installing Kohler Products, manufacturers guidelines for
power tool safety should be followed.
KOHLER CHINA INVESTMENT CO., LTD
1261214-T01-B
natural birch wood and
of high quality, and with
MAINTENANCE
section.
JING'AN DISTRICT, SHANGHAI, PRC
(
)
·
·
·
·
·
·
·
·
GB 24977-2010
1.
2.
NO.158, JIANG CHANG SAN ROAD,
POST CODE: 200436
158
©
Copyright Kohler China Investment Co., Ltd. 2017
-1-
©
POPLIN
Installation INSTRUCTIONS
CABINET
K-75881T/K-75854T
E1
1.5mg/L
200436
-
2017
