I N S T R U CT I O N M A N UA L
DHP Series
High Pressure Refrigerated Type Compressed Air Dryer
Models: DHP130, DHP200, DHP300, DHP500, DHP750, DHP1000
F O R M N O . : 5 0 0 3 9 7 1
R E V I S I O N : 0 7 / 2 0 1 6
R E A D A N D U N D E R S TA N D T H I S M A N UA L P R I O R TO O P E R AT I N G O R S E R V I C I N G T H I S P R O D U CT.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPX FLOW DHP Series and is the answer not in the manual?

Questions and answers

Related Manuals for Gardner Denver SPX FLOW DHP Series

Summary of Contents for Gardner Denver SPX FLOW DHP Series

  • Page 1 I N S T R U CT I O N M A N UA L DHP Series High Pressure Refrigerated Type Compressed Air Dryer Models: DHP130, DHP200, DHP300, DHP500, DHP750, DHP1000 F O R M N O . : 5 0 0 3 9 7 1 R E V I S I O N : 0 7 / 2 0 1 6 R E A D A N D U N D E R S TA N D T H I S M A N UA L P R I O R TO O P E R AT I N G O R S E R V I C I N G T H I S P R O D U CT.

  • Page 2: Table Of Contents

    CONTENTS GENERAL SAFETY INFORMATION ....................1 RECEIVING, MOVING, AND UNPACKING ..................1 1.0 INSTALLATION .......................... 2 1.1 Location ..............................2 1.2 Mounting ..............................3 1.3 Piping Connections ............................. 3 1.4 Electrical Connections ..........................3 1.5 Moisture Separator ............................. 3 2.0 OPERATION ..........................4 2.1 Minimum/Maximum Operating Conditions ....................

  • Page 3: General Safety Information

    GENERAL SAFETY INFORMATION RECEIVING, MOVING, AND UNPACKING PRESSURIZED DEVICES: A. RECEIVING This equipment is a pressure containing This shipment has been thoroughly checked, packed and device. inspected before leaving our plant. It was received in good condition by the carrier and was so acknowledged. • Do not exceed maximum operating pressure as shown on equipment Check for Visible Loss or Damage. If this shipment shows serial number tag.

  • Page 4: Installation

    IMPORTANT: READ PRIOR TO STARTING THIS EQUIPMENT 1.0 INSTALLATION 1.1 Location For typical placement in a compressed air system, see drawing. Air compressor intake – Locate air compressor so that Aftercooler Dryer contaminants potentially harmful to the dryer (e.g. ammo- nia) are not drawn into the air system. Compressor Oil Removal Separator...

  • Page 5: Mounting

    1.2 Mounting C. Electrical entry on larger dryers is through a hole in the cabinet. It is located on the right side panel when facing Mount the dryer on a level solid surface. Holes are provided in the front of the unit. Connect power source to terminal the dryer base to permanently mount the dryer to the floor. strip in electrical enclosure as shown on the wiring dia- gram included with the dryer.

  • Page 6: Operation

    2.0 OPERATION If water is present downstream of the dryer, always verify that any condensate drains installed upstream of 2.1 Minimum/Maximum Operating Conditions the dryer are draining properly before attempting to readjust Maximum inlet air pressure: 725 psig (50 barg) the LED setting. Minimum inlet air pressure: 15 psig (1.0 barg) For minimum inlet air pressures that fall between column values, the setting for the lower pressure is recommended.

  • Page 7: Timer Drain Programming Mode

    2.4 Timer Drain Programming Mode Dew Point Drain Interval Temperature Selector Indicator Condensate Draining (Flashes in programming mode) (LED illuminated Drain Interval indicates drain Program cycle setting) 1. Press the “Drain Interval Program” button. The “Conden- sate Draining” LED will start to flash, and the illuminated LED on the “Dew Point Temperature Indicator” will identify the factory setting for “Minutes Between Drain Cycles.” (See Table 1) 2. Press and release the “Drain Interval Selector” button to sequence the “Minutes Between Drain Cycle LED’s” from left to right until reaching your selection. The “Red” LED is not used (Reference Table 2 for “Drain Cycle Intervals”) 3. To initiate the new setting, press the “Drain Interval Pro- gram” button (this will store the new setting and exit the program).

  • Page 8: Maintenance

    3.0 MAINTENANCE f) Remove and replace complete element. 1) Unscrew the old filter element and discard. 3.1 Daily Also, discard the small o-ring that seals the filter Check separator daily to be sure automatic drain is dis- to the filter assembly head. charging. g) Install new filter element and bowl with new o-rings properly seated to head or bowl (dependent upon 3.2 Weekly dryer size). Blow down separator weekly by pushing test button on h) Connect drain line and replace panel.

  • Page 9: Troubleshooting Guide

    4.0 TROUBLESHOOTING GUIDE SYMPTOM POSSIBLE CAUSE(S) CORRECTIVE ACTION A) Water downstream of dryer 1. Residual free moisture remaining in Blow out system with dry air downstream pipelines 2. Air bypass system is open Check valve positions 3. Inlet and Outlet connections are reversed Check for correct connection 4.

  • Page 10: Reference

    5.0 REFERENCE 5.1 Sizing Determining dryer capacity at actual operating conditions To determine the maximum inlet flow capacity of a dryer at vari- ous operating conditions, multiply the rated capacity from Table 1 by the multipliers shown in Table 2. Example: How many scfm can an air-cooled model DHP300 handle when compressed air to be dried is at 350 psig and 90°F;...

  • Page 11: Engineering Data

    5.2 Engineering Data Models DHP130 DHP200 DHP300 DHP500 DHP750 DHP1000 Air System Data Maximum / Minimum Inlet Air Pressure (compressed air at inlet to dryer) 725 psig (50 barg) / 15 psig (1.0 barg) Maximum / Minimum Inlet Air Temperature (compressed air at inlet to dryer) 120°F (49°C) / 40°F (4°C) Maximum / Minimum Ambient Temperature Air-cooled: 110°F (43°C) / 40°F (4°C), Water-cooled: 130°F (54°C) / 40°F (4°C)

  • Page 12: Dimensions / Weights

    6.0 DIMENSIONS / WEIGHTS Dimensions, inches (mm) Model DHP130 DHP200 DHP300 DHP500 DHP750 DHP1000 37.56 (954) 37.56 (954) 38.60 (980) 38.60 (980) 58.06 (1475) 58.06 (1475) 25.62 (651) 25.62 (651) 32.15 (817) 32.15 (817) 32.15 (817) 32.15 (817) 2.50 (63.5) 2.50 (63.5) 2.50 (63.5) 2.50 (63.5)

  • Page 13: Drawings

    7.0 DRAWINGS 7.1 Process Gas / Refrigeration Flow Diagram: Models DHP130 and DHP200...

  • Page 14: Process Gas / Refrigeration Flow Diagram: Models Dhp300 Through Dhp1000

    7.2 Process Gas / Refrigeration Flow Diagram: Models DHP300 through DHP1000...

  • Page 15: Wiring Diagram: Models Dhp130 And Dhp200 (115 Or 208-230V/60 Hz, 100 Or 240V/50 Hz)

    7.3 Wiring Diagram: Models DHP130 and DHP200 (115 or 208-230V/60 Hz, 100 or 240V/50 Hz)

  • Page 16: Wiring Diagram: Models Dhp300 Through Dhp750 (230-400-460V/3/50-60 Hz)

    7.4 Wiring Diagram: Models DHP300 through DHP750 (230-400-460V/3/50-60 Hz) (Page 1 of 2)
  • Page 17 Wiring Diagram: Models DHP300 through DHP750 (230-400-460V/3/50-60 Hz) (Page 2 of 2)

  • Page 18: Wiring Diagram: Model Dhp1000 (230-400-460V/3/50-60 Hz)

    7.5 Wiring Diagram: Model DHP1000 (230-400-460V/3/50-60 Hz) (Page 1 of 2)
  • Page 19 Wiring Diagram: Model DHP1000 (230-400-460V/3/50-60 Hz) (Page 2 of 2)

  • Page 20: Wiring Diagram: Models Dhp300 Through Dhp1000 (575-460/3/60 Transformer Pack)

    7.6 Wiring Diagram: Models DHP300 through DHP1000 (575-460/3/60 Transformer Pack)

  • Page 21: Replacement Parts List

    8.0 REPLACEMENT PARTS LIST 8.1 Replacement Parts DHP130 DHP200 115/1/60 115/1/60 PARTS DESCRIPTION 208-230/1/60 220-240/1/50 208-230/1/60 220-240/1/50 100/1/60 100/1/60 Condensing Unit Assembly 5002001 5002002 5002003 7427771 7427772 7427773 Compressor (Only) 5002243 5002250 5002256 7427777 7427778 7427779 Overload 5002244 5002251 5002257 3233219 3233220 3252935...
  • Page 22 NOTES...

  • Page 23: Warranty

    WARRANTY The manufacturer warrants the product manufactured by it, when properly installed, operated, applied, and maintained in accor- dance with procedures and recommendations outlined in manufacturer’s instruction manuals, to be free from defects in material or workmanship for a period as specified below, provided such defect is discovered and brought to the manufacturer’s attention within the aforesaid warranty period. The manufacturer will repair or replace any product or part determined to be defective by the manufacturer within the warranty period, provided such defect occurred in normal service and not as a result of misuse, abuse, neglect or accident. Normal mainte- nance items requiring routine replacement are not warranted.
  • Page 24 DHP SERIES High Pressure Refrigerated Type Compressed Air Dryer Models: DHP130, DHP200, DHP300, DHP500, DHP750, DHP1000 SPX FLOW 4647 S.W. 40th Avenue Ocala, Florida 34474-5788 U.S.A. P: (724) 745-8647 F: (724) 745-4967 E: deltech.americas@spxflow.com www.spxflow.com/deltech Improvements and research are continuous at SPX FLOW, Inc. Specifications may change without notice.
