4.3.10 Glass Plate
1. Refer to figures "Glass plate" below.
2. Remove T10 Parker screws [1] along the side of the glass
plate, and remove the metal fixation brackets.
3. Lift the glass plate form the set.
Figure 4-15 Glass plate
4.4 Set Re-assembly
To re-assemble the whole set, execute all processes in reverse
order.
Notes:
• While re-assembling, make sure that all cables are placed
and connected in their original position. See figure "Cable
dressing".
• Pay special attention not to damage the EMC foams.
Ensure that EMC foams are mounted correctly.
All manuals and user guides at all-guides.com
Mechanical Instructions
1
H_17000_016.eps
280207
LC7.2E PA 4. EN 11
