- Page 1 (English) UM-0NM0A-000 User's Manual Switch Unit https://si.shimano.com...
-
Page 2: Table Of Contents
Contents IMPORTANT NOTICE..................3 Important safety information ................ 4 Notice....................... 5 FCC ........................6 Regular inspections before riding the bicycle ..........7 Names of parts ....................8 LED display ...................... 9 LED1 ........................9 LED2 ........................9 Wireless functions..................10 Function......................10 Connection method ...................10 E-TUBE application.....................10 Wireless system specifications .............. -
Page 3: Important Notice
A dealer's manual for professional and experienced bicycle mechanics is available on our website ( https://si.shimano.com For safety, be sure to read this user's manual thoroughly before use, follow it for correct use, and store it so that it can be referenced at any time. -
Page 4: Important Safety Information
Important safety information Important safety information Do not disassemble or modify the product. This may cause the product to not operate correctly, and you may suddenly fall and be seriously injured. Do not pay excessive attention to the display while riding. Doing so may result in an accident. Ensure that head and tail lights can turn on before riding the bicycle. -
Page 5: Notice
SHIMANO product website ( https://productinfo.shimano.com/#/com SHIMANO STEPS user's manuals are split among several booklets. Please view the “SHIMANO STEPS User's Manual”, “SHIMANO STEPS Special Battery and Parts User's Manual”, and “SHIMANO STEPS Cycle Computer User's Manual” as well, according to the components you are using. -
Page 6: Fcc
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 7: Regular Inspections Before Riding The Bicycle
Regular inspections before riding the bicycle Regular inspections before riding the bicycle Before riding the bicycle, check the following items. If any problems are found, consult your place of purchase or a distributor. Does the drivetrain perform gear shifting smoothly? Is there any looseness or damage in the component parts? Are the components securely installed to the frame/handlebar/stem, etc.? Do any abnormal noises occur while riding? -
Page 8: Names Of Parts
Names of parts Names of parts Power button Turns the main power of the bicycle ON/OFF. X button Increases a level of assistance each time pressed. LED1 LED2 Y button Decreases a level of assistance each time pressed. Light button Turns the light connected to the drive unit ON/OFF. -
Page 9: Led Display
Mainly used to display the current assist mode. The assist mode returns to OFF when the power is turned OFF. * Refer to the “SHIMANO STEPS User's Manual” for details on the assist mode and walk assist mode operations. Display State The assist mode is OFF. -
Page 10: Wireless Functions
RIDE can be used to check traveling data on a smartphone connected over Bluetooth E-TUBE PROJECT is needed to change the setting of the SHIMANO STEPS and to update firmware. For information on how to install E-TUBE PROJECT, check the support website ( https://bike.shimano.com/e-tube/... -
Page 11: Wireless System Specifications
TVs, PCs, radios, motors/engines, or inside vehicles or trains Near railroad crossings and tracks, television stations, and radar stations Other wireless computers or digital control lights Model name SW-EN600-L Frequency band 2,402 - 2,480 MHz Maximum high-frequency output +4 dBm Firmware version 4.0.0 or later... -
Page 12: When A Problem Occurs
If the error persists, contact your place of purchase or a distributor for assistance. When using a cycle computer, refer to the “SHIMANO STEPS Cycle Computer User's Manual” for information on the display. For details on error/warning codes, check the latest versions below: https://si.shimano.com/error... - Page 13 High Tech Campus 92, 5656 AG Eindhoven, The Netherlands Phone: +31-402-612222 Roebuck Way, Knowlhill, Milton Keynes, Buckinghamshire, MK5 8HL, United Kingdom 3-77 Oimatsu-cho, Sakai-ku, Sakai City, Osaka 590-8577, Japan Please note: specifications are subject to change for improvement without notice. (English) © Aug. 2022 by SHIMANO INC. ITP...
