Summary of Contents for LaserLine 211UK
- Page 1 ISUT211/211BUK-UK FILENAME:ISUT211/211BUK-UK.P65 211UK -211BUK MODULAR ALARM SYSTEMS USER GUIDE ® C A R A L A R M S Y S T E M S...
- Page 2 THE SYSTEM IS MANUFACTURED FROM THE HIGHEST QUALITY COMPONENTS TO ENSURE A LONG TROUBLE FREE OPERATING LIFE. THESE INSTRUCTIONS ARE INTENDED TO FAMILIARISE YOU WITH THEIR VERY SIMPLE OPERATION. * Optional. ** Vehicle dependent. *** 211BUK only NO DANGER FOR USER DUE TO THE RADIOFREQUENCY EXPOSURE! WARNING ALARMS MUST NOT BE STEAM CLEANED OR PRESSURE WASHED.
- Page 3 OPERATING INSTRUCTIONS You would have received from your installer, two remote controls (see fig. 1) and have been shown the location of the Status LED (fig. 2). FUNCTIONS Button A: arming/disarming of the alarm and immobiliser*; Button B: panic, ultrasonic exclusion function; Button C: special programmable functions;...
-
Page 4: Alarm Condition
DISARMING THE ALARM SYSTEM Press button A (arm/disarm), located on the right of the remote control (see fig. 1). The direction indicator lights will flash once and the alarm may give one audible tone (programmable function) generated at the same time to indicate that the alarm system has been disarmed. The power locks* will open and, if button C* is activated, all the courtesy lights will turn on for 10 seconds. -
Page 5: Passive Immobilisation
BUTTON ‘B’ FUNCTIONS (Panic and Excluding the ultrasonic sensors and electric power window* module) Panic function: Pressing this button twice within a maximum of 3 seconds activates the siren for 10 seconds and the additional siren*. To stop the sound prior to the 10 seconds, press button ‘B’ on the remote control. - Page 6 DISARMING USING THE EMERGENCY PIN CODE This function only applies if there is no optional electronic key. If all the remote controls have been lost or are malfunctioning, you can disarm the alarm system using the “emergency pin code”. HOW TO KNOW YOUR EMERGENCY PIN CODE To display the emergency pin code (Pin Code), wait 10 seconds after the memorisation of the last remote control or just follow points 1,2,3 of the “Auto-learning”...
- Page 7 HOW TO DISARM THE ALARM USING THE EMERGENCY PIN CODE If your transmitter does not work correctly or has been lost, to disarm the alarm system you must insert the “emergency pin code” by doing the following: With the alarm armed, activate the siren by opening the door on the driver’s side; Enter the vehicle.
- Page 8 EXAMPLE: the code to be inserted is 5 6 0 5 4. First digit 5 - Wait 5 flashes for the first digit. After the fifth flash has been completed and the LED has turned OFF, immediately turn ON the ignition key for 1 second.
- Page 9 then will begin flashing in a regular pattern. Activating the system with the electronic key disables the SENSOR SELF-TESTING functions (see the SENSOR SELF-TESTING paragraph). DISARMING THE ALARM SYSTEM If the alarm system was previously armed using the electronic key, you will have 10 seconds to enter the vehicle before an alarm condition occurs.
- Page 10 ALARM AUTO-DIAGNOSTICS If an alarm was generated while the system was armed, when the system is disarmed the direction indicator lights will flash briefly (½ second) and an audible tone will be produced to indicate that an alarm condition has occurred. At any time while the system is disarmed and the ignition key is off, you can check the alarm memory by pressing buttons A and B on the remote control at the same time.
-
Page 11: Problem Solving
" The memory of the last five alarm conditions will be cleared when the alarm power supply is disconnected. PROBLEM SOLVING If your alarm sounds for no apparent reason, please refer to the DIAGNOSTICS FLASH CODES for possible condition. Possible causes of the alarm condition could be: Vehicle has been tampered with. -
Page 12: Comfort Function
courtesy lights or the external sidelights, illuminating the area near the car. Pressing button “C” again prior to the 10 seconds causes the lighting to switch off (vehicle with courtesy lights delay system may take longer to switch off). COMFORT FUNCTION* (only for vehicle equipped with Comfort Closing of locking/ windows/roof**) For cars equipped with Comfort Closing function, the windows can be closed just by pressing and holding button ‘A’... -
Page 13: Important Note
Only to be used if the car is equipped with an original “crash sensor” (inertia switch) power locking system that is activated if an accident occurs. If not, a similar one available on the market must be installed. Laserline S.p.A. will be not be held responsible if users do not comply with this note. -
Page 14: Garage Function
GARAGE FUNCTION This function allows the vehicle to be left in attended car parks or for vehicle servicing, without having to leave the remote controls or electronic keys*. The procedure to activate the GARAGE FUNCTION is described below: With the alarm disarmed, and all doors closed, turn the ignition key ON; Within 5 seconds press button ‘A’... - Page 15 AUTO-LEARNING Auto-learning function allows you to program new remote controls/electronic keys or cancel lost remote controls/electronic keys. To carry out the auto-learning procedure, at least one functioning remote control or electric key must be available. Then do the following: Open the door on the driver’s side; Turn the ignition key ON;...
-
Page 16: Battery Replacement
REMOTE CONTROL SPECIAL FEATURE FLAT REMOTE CONTROL BATTERY SIGNAL By using the “ALARM AUTO-DIAGNOSTICS” function, tells you that the remote control battery is almost dead. When the alarm memory is checked, the LED on the dashboard will flash 9 times. This means that the alarm has detected that the remote control battery is almost dead. - Page 17 TECHNICAL DATA POWER SUPPLY……………………......……………....9-15V negative ground CURRENT ABSORBED WITH ALARM ARMED (with ultrasonic)…........<12 mA CURRENT ABSORBED WITH ALARM DISARMED (with ultrasonic)........<4 mA PRE-ALARM TIME ......................30 sec. PRE-ALARM TIME (armed using electronic key) ............... 30 sec. ENTRY DELAY TIME (after arming using electronic key) ........... 7 sec. ALARM CYCLE PERIOD ....................
-
Page 18: Lifetime Warranty
LIFETIME WARRANTY Product warranty covers units to be free from defects in manufacture for the lifetime ownership of the original vehicle, in accordance with the terms and conditions of this warranty document. Any product, which is deemed to be defective, will be replaced or repaired. Accessories including remote controls, touch keys and additional modules are guaranteed for a period of 12 months from date of installation. -
Page 19: Exclusions From Warranty
NOTE Manufacturer declines any responsibility for damage of the alarm/immobiliser and the vehicle electrical system due to WRONG INSTALLATION OR TAMPERING. LASERLINE SpA RESERVES THE RIGHT TO EFFECT CHANGES OF THE PRODUCT WITHOUT FURTHER NOTICE. - Page 20 Service Inspection 1 YRS 2 YRS 3 YRS 4 YRS Installer’s Stamp Installer’s Stamp Installer’s Stamp Installer’s Stamp Cert. No. Cert. No. Cert. No. Cert. No. Reg. No. Reg. No. Reg. No. Reg. No. Date. Date. Date. Date. Signature Signature Signature Signature 5 YRS...
- Page 21 CUSTOMER LIFETIME WARRANTY REGISTRATION Alarm/Immobiliser Model No. ………...…………….....Make………………………....……. Accessories Fitted …………………………......Model………………….....…… Date of Installation……………………………….....Reg.No. ……….…..………..……. Customer Name………………………………......Year of Manufacture…………....Address………………………………......………………………………....……………................................... Postcode ………………………......…...Tel No....……….....…………… Installer Name …………………..……………..Account No. …....……………..…….. Address…………………………………………………………………………………..………………... Postcode ……………………………………………..Tel No. ……....…....………… I have read and understood the terms and conditions of the Customer Lifetime Warranty. Customer Signature...............
- Page 22 Return to: LSp Agencies 33, Craven Court Winwick Quay Warrington Cheshire WA2 8QU...
-
Page 23: Emergency Pin Code
EMERGENCY PIN CODE YOUR PIN CODE IS: Note: If your pin code has not been completed by your installer please follow “AUTO-LEARNING” procedure to obtain your pin code. - Page 24 Dealer Stamp Our commissioned Sales and Support Agents in the UK are Our commissioned Sales and Support Agents in the UK are Our commissioned Sales and Support Agents in the UK are Our commissioned Sales and Support Agents in the UK are Our commissioned Sales and Support Agents in the UK are LSp Agencies 33, Craven Court - Winwick Quay - Warrington - Cheshire WA2 8QU...
