instructions.
•
Open the packaging and take out the equip-
ment with care.
•
Remove the packaging material and any
packaging and/or transportation braces (if
available).
•
Check to see if all items are supplied.
•
Inspect the equipment and accessories for
transport damage.
•
If possible, please keep the packaging until
the end of the guarantee period.
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suff ocating!
•
Original operating instructions
3. Proper use
The equipment you have purchased is designed
to pump water with a maximum temperature of
35 °C. This equipment must never be used for
other liquids, especially engine fuels, cleaning
agents and other chemically-based products!
Installed in a shaft, the equipment provides pro-
tection from fl ooding. However, it can be used
wherever you want to move water, e.g. in the
house, in the garden, and for many other applica-
tions. The equipment must not be used to operate
swimming pools!
If you want to use the equipment in bodies of wa-
ter with a natural, muddy bottom, place the equip-
ment in a slightly elevated position, e.g. on bricks.
The equipment is not designed for continuous
operation, e.g. as a circulating pump in a pond. In
this case the equipment's anticipated life will be
greatly shortened because the equipment was
not designed for continuous loading.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
Anl_GE_SP_750_LL_SPK7.indb 15
Anl_GE_SP_750_LL_SPK7.indb 15
GB
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
Mains connection ...........................230V ~ 50 Hz
Power rating .............................................. 750 W
Max. pumping rate ...............................15,000 l/h
Max. delivery head ...................................... 10 m
Max. immersion depth ................................... 5 m
Max. water temperature ............................. 35 °C
Hose connection ............. ca. 42 mm (G 11/4) AG
Max. size of foreign bodies: .....................Ø 5 mm
Switching point height: ON ....max. approx. 12 cm
Switching point height: OFF .....min. approx. 3 cm
Min. extraction height: ................................. 2 mm
Protection type: ............................................IPX8
5. Before starting the equipment
5.1 Fitting the carry handle (Fig. 2/3)
•
Connect the carry handle (1) to the pump
(Fig. 2)
•
Secure the carry handle (1) with the fastening
nut (3) (Fig. 3).
5.2 Installation
The equipment can be installed either:
•
Stationary with rigid tubing
or
•
Stationary with a flexible hose line
Note!
When installing, never hang the equipment by the
discharge line or by the power cable. The equip-
ment must be hung up with the provided carry
handle or it must rest on the bottom of the shaft.
To ensure that the equipment works properly, the
bottom of the shaft always must be free of sludge
and other accumulations of dirt. If the water level
is too low, the sludge in the shaft can quickly dry
out and hinder the equipment from starting. It is
necessary therefore to check the equipment regu-
larly (carry out trial start-ups).
Note:
The pump shaft should measure at least
40 x 40 x 50 cm so that the fl oating switch can
move freely.
- 15 -
